Formal Metaethics and Metasemantics for AI Alignment

? Abstract
We construct a fully technical ethical goal function for AI by directly tackling the philosophical problems of metaethics and mental content. To simplify our reduction of these philosophical challenges into "merely" engineering ones, we suppose that unlimited computation and a complete low-level causal model of the world and the adult human brains in it are available.

Given such a model, the AI attributes beliefs and values to a brain in two stages. First, it identifies the syntax of a brain's mental content by selecting a decision algorithm which is i) isomorphic to the brain's causal processes and ii) best compresses its behavior while iii) maximizing charity. The semantics of that content then consists first in sense data that primitively refer to their own occurrence and then in logical and causal structural combinations of such content.

The resulting decision algorithm can capture how we decide what to do, but it can also identify the ethical factors that we seek to determine when we decide what to value or even how to decide. Unfolding the implications of those factors, we arrive at what we should do. All together, this allows us to imbue the AI with the necessary concepts to determine and do what we should program it to do.
 1 /* MetaEthical.AI
 2    ==============
 3    Read the Introduction at:
 4    https://medium.com/@june_ku/formal-metaethics-and-metasemantics-for-ai-alignment-2e72533cad6d
 5
 6    Developed by June Ku in the set theoretic programming language setlX v2.2.0
 7    and interspersed with considerable non-technical philosophical commentary.
 8      https://randoom.org/Software/SetlX/
 9      https://download.randoom.org/setlX/pc/archive/setlX_v2-2-0.binary_only.zip
10        - contains among other things, tutorial.pdf introduction and reference
11
12    I am very grateful to Howard Nye for our work together on metaethics as well
13    as many helpful comments and conversations during much of this development.
14    I also appreciate helpful discussions with Mahendra Prasad, Jessica Taylor,
15    Anna Salamon and Nate Soares.
16 */
17 load('lib.stlx');
18 load('causal_model.stlx');
19 load('causal_markov_model.stlx');
20 load('decision_algorithm.stlx');
21
22 /* MetaEthical.AI Utility Function
23    ===============================
24    Takes a causal markov model of the world w and set of brains bs in w and
25    returns a metaethical.ai utility function.
26
27    Abstract: We construct a fully technical ethical goal function for AI by
28    directly tackling the philosophical problems of metaethics and mental
29    content. To simplify our reduction of these philosophical challenges into
30    "merely" engineering ones, we suppose that unlimited computation and a
31    complete low-level causal model of the world and the adult human brains in
32    it are available.
33
34    Given such a model, the AI attributes beliefs and values to a brain in two
35    stages. First, it identifies the syntax of a brain’s mental content by
36    selecting a decision algorithm which is i) isomorphic to the brain’s causal
37    processes and ii) best compresses its behavior while iii) maximizing charity.
38    The semantics of that content then consists first in sense data that
39    primitively refer to their own occurrence and then in logical and causal
40    structural combinations of such content.
41
42    The resulting decision algorithm can capture how we decide what to *do*, but
43    it can also identify the ethical factors that we seek to determine when we
44    decide what to *value* or even how to *decide*. Unfolding the implications
45    of those factors, we arrive at what we should do. All together, this allows
46    us to imbue the AI with the necessary concepts to determine and do what we
47    should want it to do.
48 */
49 metaethical_ai_u := procedure(w, bs) {
50   /* Given a set of brain models, associate them with the decision algorithms
51      they implement.  */
52   d := { [b, decision_algorithm.implemented_by(b, {})] : b in bs };
53   /* Then map each brain to its rational self's values (understood extensionally
54      i.e. cashing out the meaning of their mental concepts in terms of the
55      world events they refer to).  */
56   ext_rufs := { [b, d[b].ext_ruf(w,b)] : b in bs };
57
58   state_space := w.cm().poss_states();
59   b := first(bs);
60   probs := b.r[first(b.p)];
61   // Possible social choice utility functions
62   psc_us := choices({ {[state, r_i] : r_i in [1..#state_space] }
63                       : state in state_space });
64   sc_u := sort_set(psc_us, procedure(psc_u1, psc_u2) {
65                     return meai_psc_dist(psc_u1, ext_rufs, state_space, probs) <
66                            meai_psc_dist(psc_u2, ext_rufs, state_space, probs);
67                    })[1];
68   return sc_u;
69 };
70
71   meai_psc_dist := procedure(psc_u, ext_rufs, state_space, probs) {
72     return +/ { ord_u_dist(card_u_to_ord_u(ext_ruf, state_space, probs),
73                            card_u_to_ord_u(psc_u,   state_space, probs) ) ** 2
74                 : ext_ruf in ext_rufs };
75   };
76
77 /* MIT License
78    -----------
79    Copyright 2019 June Ku
80
81    Permission is hereby granted, free of charge, to any person obtaining a copy
82    of this software and associated documentation files (the "Software"), to deal
83    in the Software without restriction, including without limitation the rights
84    to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
85    copies of the Software, and to permit persons to whom the Software is
86    furnished to do so, subject to the following conditions:
87
88    The above copyright notice and this permission notice shall be included in
89    all copies or substantial portions of the Software.
90
91    THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
92    IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
93    FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
94    AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
95    LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING
96    FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS
97    IN THE SOFTWARE.
98 */
   1 class decision_algorithm(i, o, p, cp, u, m, m2, n, r, t_s, t_o,
   2                          cached_f, cached_lf, cached_ref) {
   3 // Definition and Structure of Decision Algorithms
   4 // ===============================================
   5
   6   i := i; /* Set of input variables (or technically names, ie strings)
   7                which are a subset of range(p)
   8              e.g. { 'P(I_1)', 'P(I_2)', 'P(I_3)' }
   9              i.e. the agent's sense data.
  10              Generally, p should include it, e.g. { ['I_1', 'P(I_1)'], ... }
  11   Technical footnote: There's some abuse of notation here. Each string like
  12   'I_1' can depending on context be treated as:
  13     i) an individual constant term / object. A predicate expression in the
  14        domain of p that has this string as an argument would be the
  15        prototypical context illustrating this usage. Semantically, these would
  16        refer to the brain events that implement them.
  17     ii) a couple possibilities for this option:
  18       a) a 0-ary predicate or sentential expression. It takes no inputs and
  19          forms a proposition on its own.
  20       b) shorthand for a 1-place predicate that takes the constant in ii and
  21          simply asserts its existence, perhaps loosely inspired by Free Logic's
  22          E!.
  23       In either case, its truth-maker/referent would be the same as option i's.
  24       Treating the string as a sentential expression or forming an expression
  25       with it as the argument of a connective would indicate this usage.
  26     All of these possibilities are expressions, or terms that could figure in an
  27     expression, i.e. the sort of thing that would be in the domain of p. They
  28     should be distinguished from the set i, which would be a subset of the range
  29     of p. These would be names of a decision algorithm variable, e.g. parents()
  30     of other variables. Assignments of value to this variable would be a
  31     subjective probability 0-1. That would form a local/partial decision state,
  32     which could get mapped to by a local/partial implementation functor lf()
  33     from a local brain state.  */
  34
  35   o := o; /* Set of output variables
  36              e.g. { 'O_1', 'O_2', 'O_3' }
  37              i.e. the agent's motor output.
  38              See also the technical note for i.  */
  39
  40   /* Function from logical formulas (setlx functors/strings/terms) to
  41        probability variables
  42      e.g. { ['A', 'P(A)'], ['B', 'P(B)'], [And('A', 'B'), 'P(A & B)'],
  43             [BoxArrow('A', 'B'), 'P(A []-> B)'] }  */
  44   p := p;
  45
  46   /* Function from ordered pairs [x, y] to conditional probability variables
  47      e.g. { [[x, y], 'P(x|y)'], ... }
  48      or more concretely: { [['C', And('A', 'B')], 'P(C|A,B)'], ... }  */
  49   cp := cp;
  50
  51   /* Function from logical formulas to utility variables
  52        e.g. { ['A', 'U(A)'], ... }
  53      u has the same structure as p above.
  54      See also accepted norms / higher-order utilities a few lines below. */
  55   u := u;
  56
  57   /* Set of memory variables
  58      This is a catch-all for other cognitive states that don't fit into the
  59      other sets of variables yet may be important to model, e.g. intermediate
  60      states in a calculation performing inference or decision. One can think of
  61      it as roughly analogous to a computer's RAM.  */
  62   m := m;
  63
  64   /* Set of memory variables for t_o
  65      Same idea as m above but these only mediate between p + cp + u and o.
  66      This helps ensure it is a genuinely decision algorithmic explanation.  */
  67   m2 := m2;
  68
  69   /* List of accepted norms / higher-order utilities
  70      [ n_1, n_2, ... ]
  71      each n_i == { ['e', e_n_i], ['m2', m2_n_i], ['o', o_n_i] }
  72        e_n_i is a function from logical formulas to evaluation variables
  73          e.g. { ['A', 'E_n_i(A)'], ... }
  74          They are basically utility function variables but since they are
  75          higher-order, i.e. they influence normative judgments or prescriptions
  76          rather than motor output, we call them evaluation variables instead
  77          when we want to emphasize that they don't directly govern action.
  78        m2_n_i is a set of memory variables that only moderate p + e_n_i to
  79          o_n_i
  80        o_n_i is a set of output variables that causally influence various u or
  81          e_n_j. In simplified models, we can make o_n_i trivially cause u or
  82          e_n_i states by just being identical to them
  83
  84      These are essentially decision criteria that govern how we change our
  85      preferences or other higher-order norms. The way in which they govern is
  86      analogous and mathematically isomorphic to how first-order utility
  87      functions or preferences govern action. There, beliefs that some motor
  88      output would cause some preferred state to be achieved will tend to cause
  89      such output and therefore the desired state. In the case of these accepted
  90      norms, beliefs that the output variables (which we can also understand as
  91      normative judgments or prescriptions) will cause or constitute a change
  92      in values (which is what the exprs of the domain of e_n_i would refer to)
  93      will tend to cause such outputs and therefore changes in value.
  94
  95      It is very important to note that what makes these preferences / utilities
  96      higher-order is their causal or functional roles and not the content of
  97      the expressions associated with the evaluation variables. One can have, in
  98      our sense, first-order preferences which prefer states involving other
  99      preferences. Those might be referentially "higher-order" in some sense but
 100      they would still be first-order in our sense so long as they govern
 101      actions rather than normative judgments or prescriptions.
 102
 103      See http://www.metaethical.ai/norm_descriptivism.pdf for more.
 104
 105      One might object that introducing these higher-order utility functions
 106      invalidates what was supposed to be the utility function of the decision
 107      algorithm. Since a utility function is supposed to encompass any factors
 108      explaining behavior, wouldn't it already include these allegedly
 109      higher-order factors? Strictly speaking, that may be correct, but that kind
 110      of utility function is not the most useful for our purposes.
 111
 112      It may be better to think in terms of modeling a decision algorithm as a
 113      society of subagents. The first-order utility function then is the utility
 114      function of the subagent whose outputs are the decision algorithm's actions
 115      rather than prescriptions that directly influence other subagents'
 116      utilities. When we speak of the utility function of the decision algorithm,
 117      this should just be understood as shorthand for this first-order utility
 118      function.
 119   */
 120   n := n;
 121
 122   // Internal states
 123   s := procedure() {
 124     if (n == {} || n == [] || n == om) {
 125       n_vs := {};
 126     } else {
 127       n_vs := +/ { range(n_i['e']) + n_i['m2'] + n_i['o'] : n_i in n };
 128     }
 129     return range(p) + range(cp) + range(u) + m + m2 + n_vs - i;
 130   };
 131
 132   // Function from i + s() + o to ranges of values for those variables
 133   r := r;
 134
 135   /* Higher order function from a function assigning values to all input and
 136      internal states to a function assigning values to all next internal states
 137        is -> s
 138   */
 139   t_s := t_s;
 140
 141   /* Higher order function from a function assigning values to all probability
 142      and utility variables as well as m2 to a function assigning values to
 143      outputs
 144        p u m2 -> o
 145   */
 146   t_o := t_o;
 147
 148   /* State transitions
 149      Returns a higher-order function from functions assigning values to i + s
 150      to functions assigning values to s + o. This is the intuitive combination
 151      of t_s and t_o. */
 152   t := procedure() {
 153     return { [    // a higher-order function which takes
 154               is, // a function assigning values to i + s and returns a function
 155               t_s[is] + t_o[just_p_u_m2(is)]
 156                   // composed of the union of a func assigning values to s and
 157                   // a func assigning values to o
 158              ] : is in domain(t_s) };
 159   };
 160
 161   /* We explicitly cache f after computing it. This allows us to directly set
 162      its value when testing or when performing the brute force search would be
 163      prohibitively costly.  */
 164   cached_f := cached_f;
 165   cached_lf := cached_lf;
 166
 167   /* ns as in the plural of n.
 168      Takes 'e', 'm2' or 'o' and returns the corresponding variables from all n.
 169      e.g. ns('e') would return all e_n_i */
 170   ns := procedure(str) {
 171     if (str == 'e') {
 172       return +/ { range(n_i[str]) : n_i in n };
 173     } else {
 174       return +/ { n_i[str] : n_i in n };
 175     }
 176   };
 177
 178   p_vars := procedure() {
 179     return range(p) + range(cp);
 180   };
 181
 182   p_u_vars := procedure() {
 183     return p_vars() + range(u);
 184   };
 185
 186   /* Takes a function (is) assigning values to input and internal state vars
 187      and returns its partial function with only vars in p, u and m2  */
 188   just_p_u_m2 := procedure(is) {
 189     return { [var, val] : [var, val] in is | var in p_u_vars() + m2 };
 190   };
 191
 192 // Variable Relationships
 193 // ----------------------
 194
 195   /* Takes a variable and returns its parents, i.e. the variables that
 196      are necessary to determine its next state in the state transition t(). */
 197   parents := procedure(y) {
 198     result := { z : z in (i + s()) | is_necessary_parent_of(z, y) };
 199     return result;
 200   };
 201
 202     is_necessary_parent_of := procedure(z, y) {
 203       vs := {v : v in i + s() | v != z}; // all other variables but z
 204       f_vs := possible_states(vs, r);
 205       bool := exists(f_v in f_vs | vals_diff(f_v, y, z));
 206       return bool;
 207     };
 208
 209     /* Check whether there exists an assignment of values to the other
 210        variables such that there are still different values of y depending
 211        on values of z.  */
 212     vals_diff := procedure(f_v, y, z) {
 213       vals := { t_s[ f_v + {[z,r_i]} ][y] : r_i in r[z] };
 214       return #vals > 1;
 215     };
 216
 217   // Takes a variable and returns its children
 218   children := procedure(y) {
 219     return { v : v in s() + o | y in parents(v) };
 220   };
 221
 222   /* Takes a variable v and a set of variables vs (with v usually in vs)
 223      and returns the first ancestors within any given branch of v's ancestors
 224      that are not in vs */
 225   non_shared_ancestors := procedure(v, vs) {
 226     result := {};
 227     for (parent in parents(v)) {
 228       if (parent in vs) {
 229         result := result + non_shared_ancestors(parent, vs);
 230       } else {
 231         result := result + { parent };
 232       }
 233     }
 234     return result;
 235   };
 236
 237   /* Takes a variable v and a set of variables vs (with v usually in vs)
 238      and returns the first descendants within any given branch of v's
 239      descendants that are not in vs */
 240   non_shared_descendants := procedure(v, vs) {
 241     result := {};
 242     for (child in children(v)) {
 243       if (child in vs) {
 244         result := result + non_shared_descendants(child, vs);
 245       } else {
 246         result := result + { child };
 247       }
 248     }
 249     return result;
 250   };
 251
 252
 253 // Syntax and Implementation
 254 // =========================
 255 // See also better_explanation and the section starting with complexity.
 256
 257   /* Function from a causal_markov_moodel of a brain to an implementation
 258      mapping f which is a higher-order function from a function assigning
 259      states to the brain's variables to a function assigning states to internal
 260      state variables s() meeting certain criteria.
 261   */
 262   f := procedure(b) {
 263     if (cached_f == om) {
 264       cached_f := compute_f(b);
 265     }
 266     return cached_f;
 267   };
 268
 269   compute_f := cachedProcedure(b) {
 270     fs := { pf : pf in possible_fs(b) | commutes(pf, b) };
 271     /* Todo: Sort by complexity and return the simplest?
 272        Or also factor in ambitiousness? Coverage of more states?  */
 273     if (#fs > 0) {
 274       return first(fs);
 275     } else {
 276       return {};
 277     }
 278   };
 279
 280   /* Function from a causal_markov_model of a brain to the possible
 281      implementation mappings f which map from a function assigning values to
 282      the exogenous and endogenous variables of the causal_markov_model to
 283      functions assigning values to the input, internal state, and output
 284      variables. */
 285   possible_fs := procedure(b) {
 286     return function_space( b.poss_states(), poss_states() );
 287   };
 288
 289   poss_states := cachedProcedure() {
 290     return possible_states(i + s() + o, r);
 291   };
 292
 293   is_implemented_by := procedure(b) {
 294     return !(f(b) == {});
 295   };
 296
 297   /* Implementation Functor
 298      ----------------------
 299      Check whether a possible implementation functor pf commutes. See f.
 300
 301      This basically implements Chalmers' criterion for when some causal system
 302      implements a computation: http://consc.net/papers/rock.html
 303
 304      In category theory terms, we can say that f is an implementation functor.
 305      Given a category of brain states and the causal relations between them
 306      and another of decision states and cognitive state transitions between
 307      them, f would be a functor mapping i) brain states to decision states and
 308      ii) causal transitions to decision state transitions such that it doesn't
 309      matter whether one goes from a) a brain state to the brain state it causes
 310      and then to the decision state f maps that brain state to or b) first from
 311      the same original brain state to the decision state f says it implements
 312      and then to the next decision state this decision algorithm transitions to.
 313      Either way, you would end up at the same final decision state.
 314   */
 315   commutes := procedure(pf, b) {
 316     /*                 pf
 317       bs_{b.uv_t_i-1} ------> ds_iso_t_i-1
 318        |                       |
 319        | b.response            | restrict_domain
 320        |                       | t()
 321        v                       v
 322       bs_{b.v_ti} ----------> ds_so_t_i
 323            +u  pf  restrict_domain
 324
 325       Roughly check that t( pf ) == pf( b.response )
 326     */
 327     return forall(bs in domain(pf) |
 328        t()[restrict_domain(pf[bs], i + s())] ==
 329        restrict_domain(pf[
 330          b.response(b.v, bs) + { [u_var, first(b.r[u_var])] : u_var in b.u }
 331        ], s() + o)
 332      );
 333   };
 334   /* Technical footnote: The above is almost true, but causal response and
 335      decision state transitions don't quite take brain states to entire brain
 336      states or entire decision states to entire decision states. The causal
 337      response only specifies the endogenous variables on the next time step. So
 338      in order to have a full brain state for pf, we just fill in the exogenous
 339      variables with their first values, only to drop those values anyway after
 340      obtaining the decision state it implements. Similarly, with the decision
 341      state, the previous outputs are irrelevant to the state transition to the
 342      next decision state so we drop those before finding the next decision
 343      state which is almost full with the exception of the (exogenous) inputs.
 344
 345      The code should be correct and this only affects the intuitive explanation.
 346      If we had used lf which is defined below, I think we could truly say it is
 347      a functor. Since it maps partial brain states to (sets of) partial
 348      decision states, it wouldn't need to make the aforementioned adjustments
 349      which prevent it from quite being a functor. However, lf is defined in
 350      terms of f, so we'd still need to understand f first and for now,
 351      almost-a-functor might have to do.
 352   */
 353
 354   /* Takes a decision state assigning values to i + s() + o and returns a
 355      function assigning values to just s() + o  */
 356   drop_i := procedure(ds) {
 357     return { [var, val] : [var, val] in ds | !(var in i) };
 358   };
 359
 360   /* Local / partial f
 361      Returns a function mapping partial causal states to partial decision states
 362      which commutes, i.e. it maps partial causal states to the partial decision
 363      state which is forced by the complete mapping f.  */
 364   lf := procedure(b) {
 365     if (cached_lf == om) {
 366       cached_lf := compute_lf(b);
 367     }
 368     return cached_lf;
 369   };
 370
 371   compute_lf := cachedProcedure(b) {
 372     /* Possible local fs
 373        Function space from union of partial causal states to the union of
 374        partial decision states.  */
 375     plfs := function_space(
 376       +/ { partial_functions(cs) : cs in b.poss_states() }, // causal states
 377       +/ { partial_functions(ds) : ds in poss_states() } // decision states
 378     );
 379     lfs := [ plf : plf in plfs | lf_commutes(plf, b) ];
 380     lfs := sort_list(lfs, procedure(plf1, plf2) { return #plf1 > #plf2; });
 381     return lfs[1];
 382   };
 383
 384   /* Function from possible local function plf and a causal model of brain b
 385      to boolean value whether it commutes. */
 386   lf_commutes := procedure(plf, b) {
 387     return forall(pcs in domain(plf) |  // pcs = partial causal state
 388       /* The set of complete decision states that is mapped by f from each
 389          complete causal state compatible with the partial causal state is
 390          equal to the set of complete decision states compatible with
 391          the partial decision states mapped by the possible lf from the partial
 392          causal state. */
 393       { f(b)[ccs] : ccs in compatible_complete_states(pcs, b.poss_states()) } ==
 394       compatible_complete_states(plf[pcs], poss_states())
 395     );
 396   };
 397
 398   /* Local / partial f inverse
 399   /* Returns a "function" from local / partial decision states to a set of
 400      local / partial causal states, namely the inverse of lf.  */
 401   lf_inv := cachedProcedure(b) {
 402     return { [ds, { cs : cs in domain(lf(b)) | lf(b)[cs] == ds} ] :
 403              ds in range(lf(b)) };
 404   };
 405
 406   // Helper function. Same as lf_inv but time subscripts are added to the b vars
 407   lf_inv_at := procedure(b, t_i) {
 408     return { [ds, { assign_time(cs, t_i) : cs in css }]
 409              : [ds, css] in lf_inv(b) };
 410   };
 411
 412   /* Takes an event in b.cm() and returns the local decision state that the
 413      brain state implements.  */
 414   lf_cm := procedure(b, b_event) {
 415     return lf(b)[drop_time(b_event)];
 416   };
 417
 418   // Returns the decision state variables implemented by a local brain state.
 419   lf_cm_vs := procedure(b, b_event) {
 420     d_event := lf_cm(b, b_event);
 421     if (d_event == om) {
 422       return {};
 423     } else {
 424       return domain(d_event);
 425     }
 426   };
 427
 428   /* Similar to above but returns the formula in the domain(p) that gets
 429      mapped to the p var.  */
 430   lf_cm_p_inv := procedure(b, b_event) {
 431     vs := lf_cm_vs(b, b_event);
 432     if (#vs == 1) {
 433       return p_inv(first(vs));
 434     } else {
 435       return om;
 436     }
 437   };
 438
 439   plf_to_pf := procedure(b, plf) {
 440     /* For each decision state var, construct the function from complete
 441        causal states to the state of that variable. */
 442     pf_var := {
 443       [var, +/ { { [ccs, pds]
 444                    : ccs in compatible_complete_states(pcs, b.poss_states())
 445                  } : [pcs, pds] in plf | first(first(pds)) == var }
 446       ] : var in i + s() + o
 447     };
 448     return { [bs, +/ { (pf_var[var])[bs] : var in i + s() + o }]
 449              : bs in b.poss_states() };
 450   };
 451
 452
 453   // This is mostly just checking for syntactic validity or well-formedness.
 454   // See also all_lte.
 455   is_valid := procedure() {
 456     return m2s_are_valid() && no_e_in_u();
 457   };
 458
 459   /* Ensures that m2s merely moderate between p + u and o.
 460      I'm no longer sure if this is necessary since we measure and punish
 461      attributing irrationality but it also doesn't seem too bad of a
 462      simplifying assumption for now.  */
 463   m2s_are_valid := procedure() {
 464     return forall (m2_i in m2 |
 465       forall (v in non_shared_ancestors(m2_i, m2) | v in p_u_vars()) &&
 466       forall (v in non_shared_descendants(m2_i, m2) | v in o)
 467     ) && forall (n_i in n |
 468       forall (m2_j_n_i in n_i['m2'] |
 469         forall (v in non_shared_ancestors(m2_j_n_i, n_i['m2']) |
 470                 v in p_vars() + range(n_i['e']) ) &&
 471         forall (v in non_shared_descendants(m2_j_n_i, n_i['m2']) |
 472                 v in n_i['o'])
 473       )
 474     );
 475   };
 476
 477   /* This helps ensure higher-order ambitiousness by preventing the smuggling
 478      of evaluation functions within u. For each p expr of the form x []-> y,
 479      make sure it does not take the form that x-ing would bring about y which
 480      the agent values (but x is not in the normal outputs o) and this
 481      recognition causes x-ing. If it is of that form, we want a decision
 482      algorithm that includes that explicitly within n.
 483      Todo: Generalize to no_e_in_e and cover more cases, e.g. indirect
 484      reference or equivalent expressions or influencing as grandparents.  */
 485   no_e_in_u := procedure() {
 486     return forall(expr in domain(p) | fct(expr) != "BoxArrow" || !e_in_u(expr));
 487   };
 488
 489     e_in_u := procedure(expr) {
 490       x := args(expr)[1]; // like an n[i]['o']
 491       y := args(expr)[2];
 492       return y in domain(u) && !(x in o) && p[expr] in parents(x);
 493     };
 494
 495 // Semantics of Mental Content
 496 // ===========================
 497
 498   /* Takes a set of pairs [w, b] and returns a function from possible worlds
 499      to extensions / referents.
 500        See: https://plato.stanford.edu/entries/two-dimensional-semantics/
 501   */
 502   intension := procedure(poss_wbs) {
 503     return { [wb[1], ref(wb[1], wb[2])] : wb in poss_wbs };
 504   };
 505
 506   /* Reference
 507      ---------
 508      Reference function from causal markov model of world w and brain b
 509      to a function which takes a brain and returns its set of truth-makers if
 510      any, i.e. a set of poss events in the world or equivalently, functions
 511      assigning values to vars in the world.
 512
 513      There are a few ways that reference is grounded.
 514
 515        1. Input variable states refer to the brain states implementing them.
 516           You can think of their content as something like "this sense datum
 517           is occurring" or perhaps even as just the pure demonstrative "this".
 518           It seems intuitive that these states can represent themselves since
 519           everything trivially carries information about itself.
 520
 521        2. The meanings of logical connectives (e.g. And, Or, Implies) and the
 522           causal connective BoxArrow are grounded by the axioms that define
 523           them. These meanings are enforced by punishing any attributions of
 524           these connectives into credences that violate their axioms. See
 525           incoherence. Cf inferential / conceptual role semantics:
 526             https://plato.stanford.edu/entries/content-narrow/#rol
 527
 528        3. The rest can be understood as a kind of ramsification. Other posited
 529           objects/events, predicates and relations refer to those things
 530           (if any) which play the roles posited for them.
 531              https://en.wikipedia.org/wiki/Ramsey%E2%80%93Lewis_method
 532              http://www.jimpryor.net/teaching/courses/mind/notes/ramseylewis.html
 533           We soften the requirement of strict truth by scoring by squared error.
 534           This amounts to a principle of charity favoring interpretations
 535           that make more beliefs turn out to be true (while also adhering to
 536           the constraints above).
 537   */
 538   ref := procedure(w, b) {
 539     if (cached_ref == om) {
 540       cached_ref := compute_ref(w, b);
 541     }
 542     return cached_ref;
 543   };
 544
 545   compute_ref := cachedProcedure(w, b) {
 546     /* Base expressions are strings or predicates. We'll build composite
 547        expressions together with corresponding references out of combinations of
 548        these and logical / causal connectives. */
 549     base_exprs := { [expr, e_arity] : [expr, e_arity] in str_exprs() + preds()
 550                                     | !(p[expr] in i) };
 551     pbers := poss_base_expr_refs(w, base_exprs);
 552     poss_atom_refs := { i_ref(w, b) + base_ref
 553                         : base_ref in poss_base_refs(w, b, pbers) };
 554     poss_refs := [ full_ref(w, b, poss_atom_ref)
 555                    : poss_atom_ref in poss_atom_refs ];
 556     return sort_list(poss_refs, less_sq_err)[1];
 557   };
 558
 559     /* Input vars refer to their own brain-state implementors. */
 560     i_ref := procedure(w, b) {
 561       return {
 562         [b_event, compatible_complete_states(b_event, w.cm().poss_states())]
 563         : b_event in b.actual_sync_events()
 564         | #lf_cm(b, b_event) == 1 && lf_cm(b, b_event) in poss_i_events()
 565       };
 566     };
 567
 568     str_exprs := procedure() {
 569       return { [expr, 0] : expr in domain(p)
 570                          | !(p[expr] in i) && isString(expr) };
 571     };
 572
 573     preds := procedure() {
 574       return { [fct(expr), arity(expr)]
 575                : expr in domain(p)
 576                | isTerm(expr) && !(fct(expr) in connectives()) };
 577     };
 578
 579     // Set of choices of poss assignments of world w states/sets/tuples to expr
 580     poss_base_expr_refs := procedure(w, base_exprs) {
 581       return choices({ {expr} >< range_for_arity(e_arity, w.cm().poss_states())
 582                        : [expr, e_arity] in base_exprs });
 583     };
 584
 585     /* Use poss_base_expr_refs to construct poss reference functions assigning
 586        reference to brain events rather than exprs.  */
 587     poss_base_refs := procedure(w, b, pbers) {
 588       return {
 589         +/ {
 590           // For each brain event that represents the given expr
 591           // Assign to it the reference of that expr according to pber
 592           { [b_event, pber[expr]] : b_event in b.actual_sync_events()
 593                                   | lf_cm_p_inv(b, b_event) == expr }
 594           // Do that for each base expr and collect them into a single function
 595           : expr in domain(pber) }
 596         // for each poss base expr reference func
 597         : pber in pbers
 598       };
 599     };
 600
 601     // Full Reference
 602     // Much of the below builds on fairly standard first-order structures or
 603     // models, e.g., https://en.wikipedia.org/wiki/First-order_logic#Semantics
 604     full_ref := procedure(w, b, atom_ref) {
 605       /* Full ref maps each brain event which implements a credence to the
 606          result of reducing the reference of the corresponding expression. */
 607       return { [b_event, rr(
 608                             lf_cm_p_inv(b, b_event), // expr it is credence in
 609                             [ w, b, atom_ref,
 610                               // vars are all the same time so just take 1st
 611                               var_time(first(first(b_event))),
 612                               {} ] // empty context
 613                          ) ]
 614                : b_event in actual_p_events(b) };
 615     }; // end full_ref
 616
 617       /* Reduce reference, takes an expression and an array of further
 618          parameters consisting of a world, brain, atomic reference function,
 619          time and context and returns a set of truth-making w events or the set
 620          of w events the expression is true in. The set of truthmakers is our
 621          way of enforcing a canonical boolean algebraic form. The different
 622          elements act as disjuncts of events and combining assignments of vals
 623          to vars into a map acts as conjunction. It may seem counterintuitive
 624          and take some getting used to but we use this canonical form even when
 625          there there is only one disjunct. */
 626       rr := procedure(expr, arr) {
 627         w := arr[1]; b := arr[2]; atom_ref := arr[3]; ti := arr[4];
 628         context := arr[5];  // context is for binding of variables, see Exists
 629         if (isTerm(expr)) {
 630           if (#args(expr) >= 1) { a1 := args(expr)[1]; }
 631           if (#args(expr) >= 2) { a2 := args(expr)[2]; }
 632         }
 633         switch {
 634           case expr in domain(context) :
 635             return context[expr];
 636           case p[expr] in i :
 637             return compatible_complete_states(
 638                      first({ b_event : b_event in pow(b.a[ti])
 639                                      | lf_cm_p_inv(b, b_event) == expr }),
 640                      w.cm().poss_states()
 641                    );
 642           case isString(expr) :
 643             return atom_ref[expr];
 644           case isSet(expr) :
 645             /* This shouldn't happen but just in case, return the set.
 646                Maybe throw an error instead? Or it's probably just rr(rr(.. */
 647             print('Warning: Expected an expr but received a set: ' + expr);
 648             return expr;
 649           case fct(expr) == 'At_t' :
 650             if (ti + a2 >= 0) { // a2 should already be negative
 651               return rr(a1, [w, b, atom_ref, ti + a2, context]);
 652             } else {
 653               return {};
 654             }
 655           case fct(expr) == 'And' :
 656             return rr(a1, arr) * rr(a2, arr);
 657           case fct(expr) == 'Or' :
 658             return rr(a1, arr) + rr(a2, arr);
 659           case fct(expr) == 'Not' :
 660             return w.cm().poss_states() - rr(a1, arr);
 661           case fct(expr) == 'Implies' :
 662             return rr( Or(Not(a1), a2), arr );
 663           case fct(expr) == 'Forall' :
 664             // Vx Px = ~Ex ~Px
 665             return rr(Not(Exists(a1, Not(a2))), arr);
 666           case fct(expr) == 'Exists' :
 667             // Set of truth-makers for a2 when any {w_event} is subbed for a1
 668             return +/ { rr(a2, [ w, b, atom_ref, ti,
 669                                  context + { [a1, {w_event}] } ])
 670                         : w_event in range_for_arity(0, w.cm().poss_states()) };
 671           case fct(expr) == 'BoxArrow' : // A []-> B, subjunctive conditional
 672             // Antecedent
 673             if (isSet(a1)) {
 674               ant := a1;
 675             } else {
 676               ant := states2events(rr(a1, arr));
 677             }
 678             // Consequent
 679             if (isSet(a2)) {
 680               cons := a2;
 681             } else {
 682               cons := states2events(rr(a2, arr));
 683             }
 684             if (#ant > 1) { // Antecedent has disjuncts.
 685               // This or that causes the effect if this does or that does.
 686               return +/ { rr(BoxArrow(disjunct, cons), arr) : disjunct in ant };
 687             } else if (#ant == 1) {
 688               if (#cons > 1) {
 689                 // A thing causes this or that if it causes this or causes that.
 690                 return +/ { rr(BoxArrow(ant, disjunct), arr) : disjunct in cons };
 691               } else if (#cons == 1) {
 692                 if ( w.cm().response( domain(cons[1]), ant[1] ) == cons[1] ) {
 693                   /* If this aspect of the causal model is true, it's true in
 694                      all states. Fire causes smoke can be true even in a
 695                      possible world where all fire is prevented. A more
 696                      expressive language could substitute a more meaningful
 697                      truthmaker here. */
 698                   return w.cm().poss_states();
 699                 } else {
 700                   return {};
 701                 }
 702               } else {
 703                 // Trivially true because everything causes the empty effect?
 704                 return w.cm().poss_states();
 705               }
 706             } else {
 707               return {}; // Nothing is caused by nothingness?
 708             }
 709             return om;
 710           default : // Predicate or Relation
 711             tuple := [rr(arg, arr) : arg in args(expr)];
 712             if (tuple in atom_ref[fct(expr)]) {
 713               // If a predication is true, it's true in all states.
 714               return w.cm().poss_states();
 715             } else {
 716               return {};
 717             }
 718         } // end switch
 719       }; // end rr
 720
 721     less_sq_err := procedure(w, b, ref_1, ref_2) {
 722       return sq_err(w, b, ref_1) < sq_err(w, b, ref_2);
 723     };
 724
 725     sq_err := procedure(w, b, ref_i) {
 726       return +/ {
 727         ( true_p(w, ref_i, b_event) - first(range(lf_cm(b, b_event))) ) ** 2
 728         : b_event in actual_p_events(b)
 729       };
 730     };
 731
 732     true_p := procedure(w, ref_i, b_event) {
 733       if (w.actual_state() in ref_i[b_event]) {
 734         return 1;
 735       } else {
 736         return 0;
 737       }
 738     };
 739
 740   // Takes an expression (in a world, brain and time) and returns its referent.
 741   ref_expr := procedure(w, b, t_i, expr) {
 742     p_var := p[expr];
 743     ds := f(b)[drop_time(b.a[t_i])]; // decision state
 744     p_event := { [p_var, ds[p_var]] };
 745     b_event := first( lf_inv_at(b, t_i)[p_event] );
 746     return ref(w, b)[b_event];
 747   };
 748
 749   // Returns the brain events that implement a placement of probabibility.
 750   actual_p_events := procedure(b) {
 751     return { b_event : b_event in b.actual_sync_events()
 752              |      #lf_cm_vs(b, b_event) == 1 &&         // just one var
 753                first(lf_cm_vs(b, b_event)) in range(p) }; // and it's a p_var
 754   };
 755
 756   /* Function from causal_markov_model b to a function from times to
 757      probability states, i.e. assignments of values to range(p) + range(cp).
 758      At each time, use f(b) to see what decision state it maps the
 759      brain state to and collect the states for range(p) + range(cp).
 760
 761      Actual world b.a is a function from times to assignments of values to
 762      variables at that time.
 763         e.g. b.a := { [1, assign_time({ [y, true] : y in b.uv() }, 1)], ...} */
 764   prob_states := procedure(b) {
 765     return { [ti, prob_states_t(b, ti) ] : ti in [1..b.n] };
 766   };
 767
 768   /* Probability States at Time ti
 769      Takes a brain b at a time ti and returns the decision state that is
 770      implemented by that brain state but restricted to just the probability
 771      variables.  */
 772   prob_states_t := procedure(b, ti) {
 773     bs := { [var, val] : [var, val] in drop_time(b.a[ti]) | var in b.uv() };
 774     ds := f(b)[bs];
 775     return { [var, val] : [var, val] in ds | var in p_vars() };
 776   };
 777
 778
 779 // Utility / Evaluation Functions
 780 // ==============================
 781
 782   // Collect all utility/evaluation function vars with their output vars
 783   eo := procedure() {
 784     return {[u, o]} + { [n_i['e'], n_i['o']] : n_i in n };
 785   };
 786
 787   /* Instrumental irrationality, including of evaluation as well as utility
 788      functions. */
 789   instr_irrat := procedure(w, b) {
 790     return +/ { e_dist(w, b, ti) : ti in [1..(b.n - 1)] } / (b.n - 1);
 791   };
 792
 793     /* Takes a brain b and time ti and returns the distance between the actual
 794        outputs and the optimal outputs according to the utility / evaluation
 795        functions and []-> beliefs.  */
 796     e_dist := procedure(w, b, ti) {
 797       /* These are all weighted equally right now, but we may want to
 798          consider different weights. Should first-order utility be treated
 799          differently? What about highest order? Does complexity matter?  */
 800       return +/ { e_i_dist(w, b, ti, e_i, o_i) : [e_i, o_i] in eo() } / #eo();
 801     }; // end e_dist
 802
 803     // Similar to above but for a specific util/eval function and output vars
 804     e_i_dist := procedure(w, b, ti, e_i, o_i) {
 805       poss_o_i_states := possible_states(o_i, r);
 806       actual_d_st0 := f(b)[ drop_time(b.a[ti]  ) ];
 807       actual_d_st1 := f(b)[ drop_time(b.a[ti+1]) ];
 808       actual_o_i_state := { [o_i_j, actual_d_st1[o_i_j]] : o_i_j in o_i };
 809       sorted_o_i_states := sort_list( [x : x in poss_o_i_states],
 810         procedure(x, y) {
 811           return exp_u(w, b, ti, actual_d_st0, e_i, x) >
 812                  exp_u(w, b, ti, actual_d_st0, e_i, y);
 813         } );
 814       ix := index_of(actual_o_i_state, sorted_o_i_states);
 815       /* Cardinal measures seem too easy to abuse so we convert them to an
 816          ordinal measure. */
 817       return ix / #sorted_o_i_states;
 818     }; // end e_i_dist
 819
 820     // Expected Utility
 821     exp_u := procedure(w, b, ti, actual_d_st, e_i, o_i_state) {
 822       /* Using our reference function, find an expression that refers to
 823          the given output state. */
 824       o_expr_b_events := {
 825         b_event : b_event in actual_p_events(b)
 826                 | var_time(first(b_event)) == ti &&
 827                   ref(w, b)[b_event] != om &&
 828                   exists(w_state in ref(w, b)[b_event] |
 829                     exists(b_ev in lf_inv(b)[o_i_state] |
 830                       restricted_eq(w_state, assign_time(b_ev, ti+1))
 831                     )
 832                   )
 833       };
 834       assert(o_expr_b_events != {}, "No o_expr_b_events found");
 835       o_expr := lf_cm_p_inv(b, first(o_expr_b_events));
 836       // Todo: Handle multiple exprs referring to o_i_state
 837       /* Is the above too indirect and complicated? There may be worries of
 838          not capturing the correct mode of presentation? Could we "hardcode"
 839          something into the language instead? Like with input vars or
 840          memories using At_t. Or the simplest may be to allow it to overlap
 841          with input vars. That is actually still allowed by the above.
 842            Is this not so easy though since it needs to refer to a *future* o
 843          state?
 844
 845          Add up the expectations of utility. Here we are interpreting our
 846          utility vars as additive values. U(x & y) = U(x) + U(y). If,
 847          however, there are exceptions, they can still be encoded by
 848          having a util var associated with the conjunction. Then, if U(x)
 849          and U(y) are still defined, you may need to be careful to encode
 850          only the intended difference from additive in the conjunction
 851          rather than doubly counting its full value.
 852            Here, we are assuming the P(o []-> u) beliefs reflect the agent's
 853          judgment of overall utility. If the agent is poor at aggregating
 854          utilities, their final judgment might come apart from these
 855          credences. There may also be issues with the timing of these
 856          and any aggregated judgments. While this may require much
 857          technical work to thoroughly address, we hope it is at least
 858          conceptually and philosophical clear what is to be done. */
 859       return +/ {  actual_d_st[ p[BoxArrow(o_expr, u_expr)] ] // P(o []-> u)
 860                  * actual_d_st[e_i_j] : [u_expr, e_i_j] in e_i }; // * u
 861     }; // end exp_u
 862
 863 // Probabilistic Coherence
 864 // =======================
 865
 866   incoherence := procedure(b) {
 867     /* Synchronic irrationality
 868        Avg of distances to the closest coherent probability distribution
 869        at each time normalized by max distance. */
 870     sync_irrat := avg({ p_dist(b, ti) / max_p_dist(b, ti) : ti in [1..b.n] });
 871     /* Diachronic irrationality
 872        Probabilities either stay the same or get updated to be close to what
 873        a (locally) ideally rational inference would result in.  */
 874     dia_irrat := 1 - p_conn_continuity([ f(b)[drop_time(b.a[ti])]
 875                                          : ti in [1..b.n] ]);
 876     return avg([sync_irrat, dia_irrat]);
 877   };
 878
 879   /* Maximum Probability Distance
 880      Find the probability distribution that is the farthest distance from the
 881      given brain's probability distribution and return that distance.
 882      This is used to normalize probability distance scores.  */
 883   max_p_dist := procedure(b, ti) {
 884     poss_p_states := [poss_p : poss_p in possible_states(p_vars(), r)];
 885     p_states := prob_states_t(b, ti);
 886     farthest_pp := sort_list(poss_p_states, procedure(pp1,pp2) {
 887                                return prob_distance(p, cp, p_states, pp1) >
 888                                       prob_distance(p, cp, p_states, pp2);
 889                              })[1];
 890     return prob_distance(p, cp, p_states, farthest_pp);
 891   };
 892
 893   /* Returns the set of possible causal models formed from the base variables
 894      in the domain of p. */
 895   poss_cms := procedure() {
 896     base_vars := [ p[expr] : expr in domain(p) |
 897                    isString(expr) || (isTerm(expr) && fct(expr) == 'At_t') ];
 898     vs := { v : v in base_vars };
 899     orderings := permutations(base_vars);
 900     return +/ { poss_cms_from_l(l, vs) : l in orderings };
 901   };
 902
 903     poss_cms_from_l := procedure(l, vs) { // l is an ordering (list)
 904       // Each var's poss parents are sets containing the preceding vars in l.
 905       poss_v_parents := { [l[j], pow({ v : v in l[1..j-1] })] : j in [2..#l] };
 906       poss_v_parents[l[1]] := {{}};
 907       poss_parents := possible_states(vs, poss_v_parents);
 908
 909       return +/ { poss_cms_from_p_pars(vs, poss_parents, p_pars)
 910                   : p_pars in poss_parents };
 911     };
 912
 913     /* Given a set of parenthood relations, construct its set of possible
 914        causal models. For each variable, construct the set of possible
 915        functions from its parents. */
 916     poss_cms_from_p_pars := procedure(vs, poss_parents, p_pars) {
 917       cm_u := { v : v in vs | p_pars[v] == {} };
 918       cm_v := vs - cm_u;
 919       cm_r := { [v, {true, false}] : v in vs };
 920       poss_v_cm_fs := {
 921         [v, function_space(possible_states(p_pars[v], cm_r), {true, false})]
 922         : v in cm_v };
 923       poss_cm_fs := possible_states(cm_v, poss_v_cm_fs);
 924       return { causal_model(cm_u, cm_v, cm_r, cm_f, om) : cm_f in poss_cm_fs };
 925     };
 926
 927   /* Takes a causal_model and returns a set of coherent probability
 928      distributions compatible with the cm. Each distribution is given by
 929      a pair of assignments of values to p and cp.  */
 930   coh_pcms := procedure(cm) {
 931     // Coherent probability distributions for exogenous variables u
 932     coh_u_probs := { p_u : p_u in poss_p_us(cm.u)
 933                          | p_u_is_coherent(p_u, cm.u) };
 934     return { [probs(cm, p_u) + subj_conds(cm, p_u), cond_probs(cm, p_u)]
 935              : p_u in coh_u_probs };
 936   };
 937
 938     poss_p_us := procedure(us) {
 939       return choices({ {state} >< p_range() : state in state_space(us) });
 940     };
 941
 942       p_range := procedure() {
 943         return r[first(range(p))]; // assume all probs share the same range
 944       };
 945
 946       /* For each prob variable, choose either it being true or false */
 947       state_space := procedure(vs) {
 948         return choices({ {[v, true], [v, false]} : v in vs });
 949       };
 950
 951     p_u_is_coherent := procedure(p_u, base_vars) {
 952       poss_exprs := da().add_up_to(base_vars, 2 ** #base_vars);
 953       poss_probs := possible_states(poss_exprs,
 954                                     { [expr, p_range()] : expr in poss_exprs });
 955       poss_ord_pairs := poss_exprs >< poss_exprs;
 956       poss_cond_probs := possible_states(poss_ord_pairs,
 957                                 { [pair, p_range()] : pair in poss_ord_pairs });
 958       poss_p_cps := poss_probs >< poss_cond_probs;
 959       return exists(p_cp in poss_p_cps
 960                     | is_superset_of(p_cp, p_u) && superset_is_coherent(p_cp) );
 961     };
 962
 963       is_superset_of := procedure(p_cp, p_u) {
 964         return { [p_var, p_val] : [p_var, p_val] in p_u | p_val != om }
 965                < first(p_cp);
 966       };
 967
 968       superset_is_coherent := procedure(p_cp) {
 969         d := decision_algorithm.new();
 970         d.p := { [expr, 'P(' + str(expr) + ')']
 971                  : [expr, p_val] in first(p_cp) };
 972         d.cp := { [l, 'P(' + str(l[1]) + '|' + str(l[2]) + ')']
 973                   : [l, p_val] in last(p_cp) };
 974         pp := { ['P(' + str(expr) + ')',                   p_val]
 975                 : [expr, p_val] in first(p_cp) } +
 976               { ['P(' + str(l[1]) + '|' + str(l[2]) + ')', p_val]
 977                 : [l, p_val] in last(p_cp) };
 978         return d.is_coherent(pp);
 979       };
 980
 981     /* Given p_u, a prob distr over states of the exogenous variables u, use
 982        the causal_model to calculate the probabilities of endogenous vars vs. */
 983     probs := procedure(cm, p_u) {
 984       // For each state of exogenous vars u, use the causal model to fill in
 985       // what the state of endogenous vars v would be.
 986       p_uv := { [u_state + cm.response(cm.v, u_state), p_val]
 987                 : [u_state, p_val] in p_u };
 988       // For each poss event of the causal model, turn the event into an expr
 989       // and assign it probability equal to the sum of the probabilities of
 990       // uv states in which the event is realized.
 991       return { [ func_to_expr(g_vs),
 992                  +/ { p_val : [uv_state, p_val] in p_uv | g_vs < uv_state }]
 993                : g_vs in cm.poss_events() };
 994     };
 995
 996     /* Next we calculate the conditional probabilities for a given p_u */
 997     cond_probs := procedure(cm, p_u) {
 998       return +/ { calc_cond_prob(g, h) : [g,h] in cm.poss_events() ** 2 };
 999     };
1000
1001       calc_cond_prob := procedure(cm, p_u, g, h) {
1002         if (compatible_values(g, h)) {
1003           a := func_to_expr(g);
1004           b := func_to_expr(h);
1005           c := func_to_expr(g + h);
1006           /* Using P(A|B) == P(And(A,B)) / P(B)  (Kolmogorov definition) */
1007           return { [ cp[[a,b]], probs(cm, p_u)[c] / probs(cm, p_u)[b] ] };
1008         } else {
1009           return 0;
1010         }
1011       };
1012
1013     // Just set to 100% if the subjunctive conditional is true in cm
1014     subj_conds := procedure(cm, p_u) {
1015       return { [p[BoxArrow(func_to_expr(g), func_to_expr(h))], 1.0]
1016                 : [g,h] in cm.poss_events() ** 2
1017                 | cm.response(domain(h), g) == h };
1018     };
1019
1020   // Note that the function it returns assigns true/false to prob vars and not
1021   // atomic expressions. You may want expr_to_events instead.
1022   expr_to_p_funcs := procedure(expr, dom) {
1023     return { { [p[term], bool] : [term, bool] in event }
1024              : event in expr_to_events(expr, dom) };
1025   };
1026
1027   /* Coherent Causal Model Probabilities
1028      Coherent probability distributions over p and cp, including the
1029      subjunctive conditionals, which can be seen as pieces of causal models.
1030      We start with probability distributions over all causal models (from
1031      the set of base variables in p). Collecting the coherent distributions
1032      over p and cp within each model, we then distribute the probability of
1033      the causal model to those distributions and sum them all up again. */
1034   coh_cm_ps := procedure() {
1035     // Possible probabilities of causal models
1036     poss_p_cms := choices({ {poss_cm} >< p_range : poss_cm in poss_cms() });
1037     /* The probabilities within any distribution must sum to 1.
1038        (Each causal model considered is global and includes all base vars so
1039        there is no worries of overlapping by one cm being a "superset" of
1040        another.) */
1041     coh_p_cms := { p_cms : p_cms in poss_p_cms | +/ range(p_cms) == 1.0 };
1042
1043     // Collect from each coherent probability distribution over causal models
1044     // the coherent probability distributions over p and cp that are allowed.
1045     return +/ { sum_p_cms(p_cms) : p_cms in coh_p_cms };
1046
1047     /* Todo: Double-check whether it's necessary to expand the probability
1048        distributions to non-canonical expressions in p? Now that prob_distance
1049        handles logical equivalences, it seems unnecessary.  */
1050   };
1051
1052     /* Given a coherent probability distribution over causal models... */
1053     sum_p_cms := procedure(p_cms) {
1054       /* For each causal model and its probability, collect the possible
1055          choices of a coherent probability distribution from each, where
1056          those probability distributions have had the probability of the
1057          causal model distributed over them.  */
1058       sets_of_p_cps := choices({
1059         { distr_p_cm(p_cp, p_cm) : p_cp in coh_pcms(cm) }
1060         : [cm, p_cm] in p_cms
1061       });
1062
1063       /* ... For each choice of p_cps from each causal model, sum them up. */
1064       return { foldr(add_p_distr, {}, [p_cp : p_cp in p_cps])
1065                : p_cps in sets_of_p_cps };
1066     };
1067
1068       /* Distribute probability of causal model.
1069          Takes p_cp, a set of pairs of coherent probability distributions over p
1070          and cp, and a probability of the causal model p_cm and then
1071          distributes the probability of the causal model so that the probability
1072          of each expression is reduced by multiplying the p_cm. */
1073       distr_p_cm := procedure(p_cp, p_cm) {
1074         // p_cp == [cm_p, cm_cp]
1075         cm_p := p_cp[1];
1076         cm_cp := p_cp[2];
1077         return [{ [p_var, p_val * p_cm] : [p_var, p_val] in cm_p },
1078                 { [cp_l, cp_val * p_cm] : [cp_l, cp_val] in cm_cp }];
1079       };
1080
1081       /* Given two pairs of probability distributions over p_vars
1082          add up the probabilities of expressions. */
1083       add_p_distr := procedure(p_cp1, p_cp2) {
1084         p1  := p_cp1[1];
1085         cp1 := p_cp1[2];
1086         p2  := p_cp2[1];
1087         cp2 := p_cp2[2];
1088         return [sum_p(p1, p2), sum_p(cp1, cp2)];
1089       };
1090
1091         sum_p := procedure(p1, p2) {
1092           /* If one has a variable where the other does not have any variable
1093              with an equivalent expression, just go with the probability
1094              defined by the one. */
1095           return { [v1, p1[v1]] : v1 in domain(p1)
1096                    | !exists(v2 in domain(p2) | equiv_p_expr(p, cp, v1, v2)) } +
1097                  { [v2, p2[v2]] : v2 in domain(p2)
1098                    | !exists(v1 in domain(p1) | equiv_p_expr(p, cp, v1, v2)) } +
1099           /* Otherwise, for any variables that have equivalent expressions,
1100              add up the probabilities for those variables. (Since they've
1101              already been reduced in distr_p_cm, we don't need to average
1102              the sum.)  */
1103                  +/ { { [v1, p1[v1] + p2[v2]],[v2, p1[v1] + p2[v2]]  }
1104                       : [v1, v2] in domain(p1) >< domain(p2)
1105                       | equiv_p_expr(p, cp, v1, v2) };
1106         };
1107
1108           equiv_p_expr := procedure(p, cp, v1, v2) {
1109             e1 := p_cp_inv(p, cp, v1);
1110             e2 := p_cp_inv(p, cp, v2);
1111             return equiv_expr(e1, e2, all_atomic_formulas(domain(p)));
1112           };
1113
1114   /* Takes a brain and time and finds the closest perfectly coherent
1115      probability distribution and returns the distance to it. */
1116   p_dist := procedure(b, ti) {
1117     p_states := prob_states_t(b, ti);
1118     return prob_distance(p, cp, sorted_rat(p_states)[1], p_states);
1119   };
1120
1121   /* Takes a prob state and returns a list of coherent probability
1122      distributions sorted by how close they are to p_states, closer ones first.
1123   */
1124   sorted_rat := procedure(p_states) {
1125     return sort_list( [ coh_p + coh_cp : [coh_p, coh_cp] in coh_cm_ps() ],
1126       /* A procedure measuring which of two probability states is closer to
1127          the original one given.  */
1128       procedure(pp1, pp2) {
1129         return prob_distance(p, cp, pp1, p_states) <
1130                prob_distance(p, cp, pp2, p_states);
1131       }
1132     );
1133   };
1134
1135   /* Takes a p or cp var in range(p) + range(cp) and returns its preimage
1136      formula(s) */
1137   p_inv := procedure(v) {
1138     if (v in range(p)) {
1139       return inv(p)[v];
1140     } else {
1141       return inv(cp)[v];
1142     }
1143   };
1144
1145   // Same as p_inv but with p and cp explicitly passed in due to setlx bug
1146   p_cp_inv := procedure(p, cp, v) {
1147     if (v in range(p)) {
1148       return inv(p)[v];
1149     } else {
1150       return inv(cp)[v];
1151     }
1152   };
1153
1154   // Same as p_inv but if in cp, it returns the first expr instead of the pair
1155   p_var_inv := procedure(v) {
1156     if (v in range(p)) {
1157       return inv(p)[v];
1158     } else {
1159       return first(inv(cp)[v]);
1160     }
1161   };
1162
1163
1164   /* Obeys the axioms of probability.
1165        See especially p 45 (or 64 in pdf) of E.T. Jaynes, Probability Theory:
1166        The Logic of Science. https://bayes.wustl.edu/etj/prob/book.pdf  */
1167   old_is_coherent := procedure(pp) {
1168     /* For easier handling, turn domain(p) into a datatype like domain(cp)
1169        so that e.g. P(A) looks more like P(A|om) */
1170     force_list := procedure(v) {
1171       if (isList(p_inv(v))) {
1172         return p_inv(v);
1173       } else {
1174         return [p_inv(v), om];
1175       }
1176     };
1177     pp := { [force_list(v), num] : [v,num] in pp };
1178     obeys_axiom_3 := procedure(l) {
1179       if (isTerm(l[1]) && fct(l[1]) == "And") { // [And(a,b), c]
1180         [a,b] := args(l[1]);
1181         c := l[2];
1182         // P(a,b|c) = P(a|b,c) * P(b|c)
1183         return pp[l] == pp[ [a, And(b,c)] ] * pp[ [b,c] ];
1184       } else {
1185         return true;
1186       }
1187     };
1188     return forall(l in domain(pp) | pp[l] >= 0) &&
1189            // P(A|x) + P(~A|x) = 1
1190            // Todo: Simplify double negation to avoid infinite NOT() regression?
1191            forall(l in domain(pp) | pp[l] == 1 - pp[ [Not(l[1]), l[2]] ]) &&
1192            forall(l in domain(pp) | obeys_axiom_3(l));
1193   }; // end old_is_coherent
1194
1195   /* From Lasky, Kathryn. "Axiomatic First-Order Probability"
1196      http://ceur-ws.org/Vol-527/paper5.pdf
1197
1198       Laskey axioms
1199         P1. probabilities are between 0 and 1
1200         P2. probabilities in tautologies are 1
1201               or just logical truths
1202         P3. if probability in two statements both being true are 0, then
1203               probability of one or the other is equal to adding probability
1204               in each
1205         P4. Bayesian conditioning
1206         P5. interchangeability of logically equivalent statements
1207
1208      Todo: Double-check if it's necessary to handle undefined/om probability
1209            values. It seems p_u_is_coherent checks its coherence by seeing if
1210            a superset is perfectly coherent so I think that strategy should
1211            work. But there may be some slight technical issues making sure
1212            we're allowing or disallowing om in the right places there.
1213   */
1214   is_coherent := procedure(pp) {
1215     pp := { [force_list(v), num] : [v,num] in pp };
1216     return forall(l in domain(pp) |
1217       // P1: Probabilities are between 0 and 1.
1218       0 <= pp[l] && pp[l] <= 1 &&
1219       // P2: Logical truths have probability 1.
1220       (!is_logical_truth(l[1]) || pp[l] == 1) &&
1221       forall(l2 in domain(pp) |
1222         ( l[2] != l2[2] || (
1223           // z is shared in P(_|z) && P(_|z)
1224
1225           // P3: If P(x^y|z) = 0, then P(x v y|z) = P(x|z) + P(y|z)
1226           ( pp[[And(l[1], l2[1]), l[2]]] != 0 ||
1227             pp[[ Or(l[1], l2[1]), l[2]]] == pp[l] + pp[l2] ) &&
1228
1229           // P4: Bayesian conditioning. P(x^y|z) = P(y|z) * P(x|y,z)
1230           ( fct(l[1]) != "And" || !(l2[1] in args(l[1])) ||
1231             forall(l3 in domain(p) |
1232               !(l3[1] in args(l[1])) || l3[1] == l2[1] ||
1233               l3[2] != And(l2[1], l[2]) || pp[l] == pp[l2] * pp[l3]
1234             ) ) &&
1235
1236           // P5: Interchangeability of equivalent expressions. Part 1
1237           //     If x<->y, then Vz P(x|z) = P(y|z)
1238           ( !equiv_expr(l[1], l2[1], atomic_formulas(domain(p))) ||
1239             pp[l] == pp[l2] )
1240         ) ) /* end || */ && (
1241           // P5 Part 2: If x <-> y, then Vz P(z|x) = P(z|y)
1242           !equiv_expr(l[2], l2[2], atomic_formulas(domain(p))) ||
1243           l[1] != l2[1] || pp[l] == pp[l2]
1244         )
1245       ) // end forall l2
1246     ); // end forall l
1247   }; // end is_coherent
1248
1249     /* For easier handling, turn domain(p) into a datatype like domain(cp)
1250        so that e.g. P(A) looks more like P(A|om) */
1251     force_list := procedure(v) {
1252       if (isList(p_inv(v))) {
1253         return p_inv(v);
1254       } else {
1255         return [p_inv(v), om];
1256       }
1257     };
1258
1259   /* Takes two functions mapping p & cp vars to probabilities and computes
1260      the difference. See Staffel, Julia. Measuring the Overall Incoherence of
1261      Credence Functions. Synthese, 2015. DOI 10.1007/s11229-014-0640-x
1262
1263      Technical Note: Takes p and cp (which should just be the usual this.p and
1264      this.cp) but needs to be passed explicitly because of a setlx bug: The
1265      second and subsequent calls to an instance procedure within a nested
1266      procedure is not able to access instance variables / procedures.
1267
1268      See ambitiousness for a more general workaround. There and elsewhere we
1269      assign *this* (the decision algorithm instance) to *self* and then pass
1270      in self as the first parameter. The receiving instance procedure then
1271      makes sure to call any instance variables and procedures on self rather
1272      than their implicit and buggy this. The result may be likened to Python's
1273      way of handling instance methods.
1274   */
1275   prob_distance := procedure(p, cp, pp1, pp2) {
1276     /* First pass: (but doesn't handle undefineds and logical equivalents)
1277     return +/ { abs(pp1[v] - pp2[v]) : v in domain(pp1) | v in domain(pp2) };
1278     // Second pass: (but doesn't handle double-counting)
1279     return +/ { abs(pp1[v] - pp2[v2]) : [v, v2] in domain(pp1) >< domain(pp2)
1280                                       | v == v2 || equiv_p_expr(v, v2) };
1281        Consider three people where the "true" probability is 90%
1282          Person 1: A & B 80%, B & A 70%
1283          Person 2: A & B 80%
1284          Person 3: A & B 80%, B & A 80%
1285        Averaging probabilities in logical equivalents favors person 2 and 3
1286        over 1 but not 2 over 3.
1287     */
1288     return +/ { abs( pp_equiv(p, cp, pp1)[p_class] -
1289                      pp_equiv(p, cp, pp2)[p_class] )
1290                 : p_class in p_equiv_classes(p, cp)
1291                 | pp_equiv(p, cp, pp1)[p_class] != om &&
1292                   pp_equiv(p, cp, pp2)[p_class] != om };
1293   };
1294
1295     // Equivalence classes of probability variables based on logical equivalence
1296     p_equiv_classes := procedure(p, cp) {
1297       return { { x : x in range(p) + range(cp)
1298                    | equiv_p_expr(p, cp, p_var, x) }
1299                : p_var in range(p) + range(cp) };
1300     };
1301
1302     // Converts a possibility probability distribution pp to one that ranges
1303     // over equivalence classes of logically equivalent p vars instead of
1304     // directly over the p vars.
1305     pp_equiv := procedure(p, cp, pp) {
1306       return { [p_class, avg_p_class(pp, p_class)]
1307                : p_class in p_equiv_classes(p, cp)
1308                | avg_p_class(pp, p_class) != om };
1309     };
1310
1311       // Return the average of the values pp assigns to the p vars in p_subset
1312       avg_p_class := procedure(pp, p_subset) {
1313         p_vals := [ pp[p_var] : p_var in domain(pp) | p_var in p_subset ];
1314         if (#p_vals == 0) {
1315           return om;
1316         } else {
1317           return avg(p_vals);
1318         }
1319       };
1320
1321 // Helpers
1322 // -------
1323
1324   poss_io_states := cachedProcedure() {
1325     return possible_states(i + o, r);
1326   };
1327
1328   poss_s_states := cachedProcedure() {
1329     return possible_states(s(), r);
1330   };
1331
1332   poss_m_states := cachedProcedure() {
1333     return possible_states(m, r);
1334   };
1335
1336   poss_m2_states := cachedProcedure() {
1337     return possible_states(m2, r);
1338   };
1339
1340   poss_ms_states := cachedProcedure() {
1341     return possible_states(m + m2, r);
1342   };
1343
1344   poss_i_states := cachedProcedure() {
1345     return possible_states(i, r);
1346   };
1347
1348   poss_is_states := cachedProcedure() {
1349     return possible_states(i + s(), r);
1350   };
1351
1352   poss_o_states := cachedProcedure() {
1353     return possible_states(o, r);
1354   };
1355
1356   poss_u_states := cachedProcedure() {
1357     return possible_states(range(u), r);
1358   };
1359
1360
1361 // Best Compression
1362 // ================
1363
1364   /* Complexity of Intentional Explanation
1365      -------------------------------------
1366      This can be seen as a more realist and more formal version of Dennett's
1367      Intentional Stance.
1368        See e.g. https://sites.google.com/site/minddict/intentional-stance-the
1369
1370      On a first pass, the best intentional explanation can be taken to be the
1371      one which best compresses the brain's behavior.
1372        See better_explanation for further considerations.
1373
1374      Also see https://en.wikipedia.org/wiki/Minimum_description_length:
1375        "The minimum description length (MDL) principle is a formalization of
1376         Occam's razor in which the best hypothesis (a model and its parameters)
1377         for a given set of data is the one that leads to the best compression
1378         of the data."
1379
1380      Since b and d already contain information on their transitions from any
1381      possible state, we don't need to run this for each time step.
1382   */
1383   complexity := cachedProcedure(b) {
1384     // Complexity of b given d and f + Complexity of d and f
1385     raw_score := k_given(b.t_to_str(), df_to_str(b)) + k(df_to_str(b));
1386     /* Now normalize. Worst case is it doesn't help encode b any better and
1387        it's just as complex as b. Best case is if it could take 0 bits.  */
1388     worst_score := 2 * k(b.t_to_str());
1389     return 1 - raw_score / worst_score;
1390   };
1391
1392   to_s := cachedProcedure() {
1393     return str([i, p, cp, u, m, m2, n, o, r, t()]);
1394   };
1395
1396   f_to_s := procedure(b) {
1397     return str(f(b));
1398   };
1399
1400   df_to_str := procedure(b) {
1401     return to_s() + "@" + f_to_s(b);
1402     // '@' is just a separator, an otherwise unused character
1403   };
1404
1405   /* Ambitiousness
1406      -------------
1407      If we only optimized for the best compression of the brain, we face the
1408      following problem. Suppose the syntax we use is somewhat inefficient.
1409      Then, the smallest K(b|df) + K(df) might be produced by an empty d with
1410      all the work being done by a turing machine which generates b using
1411      essentially the same decision algorithm we would have wanted to use as d
1412      but with a more efficient syntax. Or it may only put some into the
1413      official d and sneak in the rest in the turing machine. It seems what
1414      we'd need is something like a not-a-decision-algorithmic-explanation
1415      predicate to apply to the turing machine. Or we want d to be ambitious,
1416      ideally packing as much of a decision-algorithmic explanation as possible
1417      or at least positively weighing its ambitiousness against potential
1418      increases in complexity.
1419
1420      For a given d, we consider the auxiliary hypothesis h, which together w/
1421      d best explains b. We then look for a decomposition of h into [h_i, h_j]
1422      where [h_i, h_j] is similar to h, and [h_i, h_j] makes d least ambitious,
1423      meaning that the d* which is a superset of d and maximizes coherence and
1424      similarity to d + h_i, improves coherence the least with the greatest
1425      complexity cost. d's ambitiousness in the worst case decomposition is d's
1426      ambitiousness. In other words, the more there is a d* which is highly
1427      similar to d + some h_i and very coherent, the less ambitious d is. It
1428      would leave out too much that could and should be explained using a
1429      decision algorithmic explanation. If d is very ambitious, there's more
1430      like just noise left for the auxiliary hypothesis or you'd have to stray
1431      farther from the auxiliary hypothesis h to subsume it under a decision
1432      algorithmic explanation.
1433   */
1434   ambitiousness := procedure(b) {
1435     poss_hs := all_strs_lte(#b.t_to_str()) >< all_strs_lte(#b.t_to_str());
1436     self := this; // workaround for setlx bug described in prob_distance
1437     poss_hs := sort_set(poss_hs,
1438       /* Procedure for worse decomposition. Calling it worse rather than
1439          better because we want the [h1, h2] which represents the worst case
1440          scenario as far as ambitiousness goes.
1441       */
1442       procedure(hs_i, hs_j) {
1443         return hs_score(self, b, hs_i) > hs_score(self, b, hs_j);
1444       });
1445     hs := poss_hs[1];
1446     return ambitiousness_with_hs(b, hs);
1447   };
1448
1449     hs_score := procedure(self, b, hs_k) {
1450       return self.hs_similarity(b, hs_k) - self.ambitiousness_with_hs(b, hs_k);
1451     };
1452
1453     hs_similarity := procedure(b, hs_k) { // hs_k == [h1, h2]
1454       return ( k_given(h(b), str(hs_k)) + k_given(str(hs_k), h(b)) ) * -1;
1455       // or ** -1 ?
1456     };
1457
1458   // Stringified auxiliary hypothesis which together with d explains b.t_to_str
1459   h := procedure(b) {
1460     poss_hs := all_strs_lte(#b.t_to_str());
1461     self := this; // workaround for setlx bug described in prob_distance
1462     poss_hs := sort_set(poss_hs, procedure(h_i, h_j) { // better h explanation
1463                  return h_complexity(self, b, h_i) < h_complexity(self, b, h_j);
1464                });
1465     return poss_hs[1];
1466   };
1467
1468     h_complexity := procedure(self, b, h_k) {
1469       return k_given(b.t_to_str(), self.df_to_str(b) + "|" + h_k);
1470     };
1471
1472   ambitiousness_with_hs := procedure(b, hs_k) {
1473     poss_d_stars := { poss_d_star : poss_d_star in supersets_lte(b)
1474                       | poss_d_star.is_valid() &&
1475                         poss_d_star.is_implemented_by(b) };
1476     self := this; // workaround for setlx bug described in prob_distance
1477     poss_d_stars := sort_set(poss_d_stars,
1478       procedure(d_star_i, d_star_j) { // better_d_star
1479         return d_star_sim(self, b, hs_k, d_star_i) - d_star_i.incoherence(b) >
1480                d_star_sim(self, b, hs_k, d_star_j) - d_star_j.incoherence(b);
1481       });
1482     d_star := poss_d_stars[1];
1483
1484     delta_incoh := ( d_star.incoherence(b) - incoherence(b) ) / incoherence(b);
1485     delta_irrat := ( d_star.instr_irrat(b) - instr_irrat(b) ) / instr_irrat(b);
1486     delta_compl := (k(d_star.df_to_str(b)) - k(df_to_str(b))) / k(df_to_str(b));
1487     /* More incoherent and irrational -> more ambitious
1488          because it's like less of real Decision Algorithmic stuff left in h1
1489        Larger complexity -> less ambitious
1490          because there's more Decision Algorithmic stuff left in hs_1 & not in d
1491          but maybe replace complexity with more like raw size? #states?  */
1492     return delta_incoh + delta_irrat - delta_compl;
1493   };
1494
1495     d_star_sim := procedure(self, b, hs_k, d_star_k) {
1496       raw_sim := (  // roughly, K(d*|d,h1) + K(d,h1|d*_s)
1497         k_given( d_star_k.df_to_str(b), self.df_to_str(b) + "|" + hs_k[1]) +
1498         k_given( self.df_to_str(b) + "|" + hs_k[1],
1499                  d_star_k.simplest_version(b).df_to_str(b) )
1500       );
1501       /* Normalize. Best similarity is if 0 extra bits are required.
1502          Worst is K(d*) + K(d); the given bits didn't help at all. */
1503       worst_sim := k(d_star_k.df_to_str(b)) + k(self.df_to_str(b));
1504       return 1 - raw_sim / worst_sim;
1505     };
1506
1507   /* Returns decision algorithms with # of possible states <= #b.poss_states
1508      which are "supersets" of self. It has additional variables and therefore
1509      states, but when considering just the variables shared with self, it is
1510      isomorphic to self.  */
1511   supersets_lte := procedure(b) {
1512     return { d : d in decision_algorithm.all_lte(#b.poss_states())
1513                | is_subset_of(d) };
1514   };
1515
1516   // Returns whether this decision algorithm is a "subset" of the given d
1517   is_subset_of := procedure(d) {
1518     // i, o, p, cp, u, m, m2, n, r, t_s, t_o
1519     var_pairs := { [i, d.i], [o, d.o], [p, d.p], [cp, d.cp],
1520                    [u, d.u], [m, d.m], [m2, d.m2] };
1521     vars_are_subsets := forall([vs, d_vs] in var_pairs | vs < d_vs);
1522     if (!vars_are_subsets || #n > #d.n) { return false; }
1523
1524     n_are_subsets := forall(j in [1..#n] |
1525                        forall(ltr in {'e','m2','o'} |
1526                          n[j][ltr] < d.n[j][ltr] ));
1527     if (!n_are_subsets) { return false; }
1528
1529     /* For all transitions from a i+s state to a s+o state in self, it is the
1530        case that any transition in d starting from a superset of i+s ends in
1531        a d state that is a superset of the s+o state.  */
1532     return forall([is, so] in t() |
1533              forall(ccs in compatible_complete_states(is, d.poss_is_states()) |
1534                compat(so, d.t()[ccs])
1535              )
1536            );
1537   };
1538
1539   is_simplest_version := procedure(b) {
1540     return is_equal_to(simplest_version(b));
1541   };
1542
1543   /* Using simplest_version handles worries with using m as arbitrary data
1544      to smuggle in unlabelled decision algorithmic information. Only the
1545      decision algorithmic aspects of a decision algorithm should do the
1546      explaining. This should also handle worries of higher-order utility
1547      information being smuggled in within the memory variables.  */
1548   simplest_version := procedure(b) {
1549     alt_ds := [ d : d in decision_algorithm.all(b)
1550                   | is_isomorphic_to(d) && d.is_implemented_by(b) ];
1551     alt_ds := sort_list(alt_ds, decision_algorithm.simpler);
1552     return alt_ds[1];
1553   };
1554
1555   is_equal_to := procedure(d) {
1556     l1 := [  i,   o,   p,   cp,   u,   m,   m2,   n,   r,   t_s,   t_o];
1557     l2 := [d.i, d.o, d.p, d.cp, d.u, d.m, d.m2, d.n, d.r, d.t_s, d.t_o];
1558     return l1 == l2;
1559   };
1560
1561   is_isomorphic_to := procedure(d) {
1562     /* Everything but the memory variables is the same
1563        And there is an isomorphism between m+m2 states and d.m+d.m2 states
1564        Todo: Also add n minus m2s in n to simple equality comparison.
1565     */
1566     l1 := [  i,   o,   x,   p,   cp,   u,   r,   t_s,   t_o];
1567     l2 := [d.i, d.o, d.x, d.p, d.cp, d.u, d.r, d.t_s, d.t_o];
1568     return l1 == l2 && exists(fm in possible_fms(d) | fm_commutes(fm, d));
1569   };
1570
1571     // Todo: Also do higher-order m2s
1572     possible_fms := procedure(d) {
1573       /* Construct the space of functions from states of m+m2 to d.m+d.m2,
1574          respecting the m / m2 boundary */
1575       fm_ms  := {
1576         { [ m_st + m2_st,  fm_m[m_st] + fm_m2[m2_st] ]
1577           : [m_st, m2_st] in poss_m_states() >< poss_m2_states() }
1578         : [fm_m, fm_m2] in
1579           function_space(possible_states(m,  r), possible_states(d.m,  d.r)) ><
1580           function_space(possible_states(m2, r), possible_states(d.m2, d.r))
1581       };
1582
1583       // For convenience map everything else onto its counterpart in d
1584       fms := {
1585         { [iso, apply_fm_m(fm_m, iso) ] : iso in possible_states(i+s()+o, r) }
1586         : fm_m in fm_ms
1587       };
1588       return fms;
1589     };
1590
1591       // Todo: Also do higher-order m2s.
1592       apply_fm_m := procedure(fm_m, iso) {
1593         iso_m := { [var, val] : [var, val] in iso | var in m || var in m2 };
1594         return { [v, iso[v]] : v in i + s() + o - m - m2 } + fm_m[iso_m];
1595       };
1596
1597     fm_commutes := procedure(fm, d) {
1598       // Restrict fm to just i + s() variables
1599       fm_is := { [{ [var, val] : [var, val] in iso1 | var in i + s() },
1600                   { [var, val] : [var, val] in iso2 | var in d.i + d.s() }]
1601                     : [iso1, iso2] in fm };
1602       // Restrict fm to just s() + o variables
1603       fm_so := { [{ [var, val] : [var, val] in iso1 | var in s() + o },
1604                   { [var, val] : [var, val] in iso2 | var in d.s() + d.o }]
1605                     : [iso1, iso2] in fm };
1606       return { fm_so[ t()[g_is] ] == t()[ fm_is[g_is] ] : [g_is, h_so] in t()
1607              } == { true };
1608     };
1609
1610 // Rationality
1611 // ===========
1612
1613   /* Rational Utility Function
1614      -------------------------
1615      Takes the world w and brain b and collects all possible continuations of
1616      brain/decision states using bs_msr_paths. Then it weights them by
1617      agential_identity, optimal_rxs, and subjective likelihood and finds the
1618      center-of-mass / social-choice of the resulting first order utility
1619      functions.
1620
1621      This comes out of the metaethical view developed by Howard Nye and June
1622      Ku and written up at http://www.metaethical.ai/norm_descriptivism.pdf.
1623      There we focused on the simple case in which the norms we accept or our
1624      higher-order preferences formed a hierarchy with a single fundamental norm
1625      or highest-order utility function governing our lower-order norms /
1626      functions. (Also see the comments above n := n towards the top.) In that
1627      case, what we have most reason to do would be what that highest order
1628      utility function would prescribe, perhaps through the prescription of
1629      certain lower-level utilty functions.
1630
1631      Elsewhere, we have acknowledged that things might be more complicated. We
1632      might have a network of accepted norms / higher-order preferences in which
1633      they all influence one another rather than a strict top-down hierarchy.
1634      We have suggested that in that case, the weights of each accepted norm and
1635      the parameters governing the network behavior could be treated as the
1636      fundamental norm. Developing this further, we might model it as a markov
1637      model with states of norm acceptances influencing other acceptances and
1638      look for a stationary distribution, i.e. an equilibrium state in which the
1639      state it transitions to is the same state it started with.
1640
1641      However, even that makes a simplifying assumption that the network
1642      topology of which norms influence which others remains constant. But if
1643      we imagine a brain's behavior in response to varying inputs, it seems
1644      likely that sometimes, which higher-order preferences influence which
1645      others would also vary. To handle this, we implement a parliamentary model
1646      to aggregate the various influences across different possible
1647      continuations of the agent.
1648        This is inspired by Nick Bostrom and Toby Ord on Parliamentary Models
1649      for Moral Uncertainty. Although it's applied in a different context, it's
1650      similar in that both are aggregating many utility functions into one.
1651      http://www.overcomingbias.com/2009/01/moral-uncertainty-towards-a-solution.html
1652
1653      In the end, this does bring us closer to the ideal response / advisor
1654      family of metaethical theories but I think our focus on the influence of
1655      optimal normative judgments remains distinctive and arguably avoids some
1656      worries. We are reading off the first-order utility function from ideal
1657      selves rather than the actions so we have less distortion from the
1658      idealization process to worry about since there's less to change. We
1659      address remaining worries about distortion with agential identity to
1660      measure how much one remains the same agent.
1661
1662      The idealization is mostly done by weighting more heavily selves who are
1663      the result of normative judgments that best satisfy the decision criteria
1664      governing them. We also incorporate subjective likelihood of the inputs
1665      determining possible continuations to factor in normal operating
1666      conditions without letting in external factors and violating supervenience
1667      on just the brain.
1668   */
1669   ruf := procedure(w, b) {
1670     t_z := 10 ** 9; // Number of time steps of continuations to consider
1671     /* Todo: Find a more principled way
1672          * "Ask" each branch how much longer to continue?
1673          * Compute infinitely but in a way that asymptotes?
1674          * Keep computing until it converges, with minimum time?
1675              If it never converges? */
1676
1677     // Poss social choice utility functions
1678     psc_u_dom := domain(p) + domain(u);
1679     psc_u_rng := r[first(range(u))] + { om };
1680     psc_us := choices({ { [expr, r_i] : r_i in psc_u_rng }
1681                         : expr in psc_u_dom });
1682     psc_us := { { [expr, r_i] : [expr, r_i] in psc_u | r_i != om }
1683                 : psc_u in psc_us }; // filter out om
1684     state_space := exprs_to_state_space(psc_u_dom);
1685
1686     voter_wts := {};
1687     t_i := 1;
1688     bs1 := drop_time(b.a[b.n]);
1689     while (t_i <= t_z) {
1690       bmps := bs_msr_paths(w, b, bs1, t_i);
1691       voter_wts := voter_wts + {
1692         [ // voter util func
1693           additive_to_ordinal( f(b)[first(last(bmp))], 0, state_space),
1694           time_wt(t_i) * voter_weight(w, b, bmp) ] // voter weight
1695         : bmp in last(bmps)
1696       };
1697       t_i := t_i + 1;
1698     }
1699     return sort_set(psc_us,
1700                     procedure(psc_u1, psc_u2) {
1701                       return rat_psc_dist(voter_wts, psc_u1, state_space) <
1702                              rat_psc_dist(voter_wts, psc_u2, state_space);
1703                     })[1];
1704   };
1705
1706     time_wt := procedure(t_i) { return 1; }; // Placeholder constant function
1707
1708     voter_weight := procedure(w, b, bmp) {
1709       msr := last(last(bmp));
1710       bss := [ bs : [bs, msr] in bmp ]; // Brain StateS
1711
1712       cached_ref := om;
1713       wb := new_wb(w, b, bss);
1714       w2 := first(wb);
1715       b2 := last(wb);
1716
1717       dss := [ f(b2)[bs] : bs in bss ];
1718       agential_id := agential_identity(dss, w2, b2);
1719       return msr * agential_id * optimal_rxs(w2, b2, dss);
1720     };
1721
1722     // Possible Social Choice for Rationality (as opposed to in optimal_rxs)
1723     rat_psc_dist := procedure(voter_wts, psc_u, state_space) {
1724       card_u := add_u_to_card_u(psc_u, state_space);
1725       ord_u := card_u_to_ord_u( card_u, domain(card_u), r[first(p)] );
1726       return +/ { voter_wts[voter] * ord_u_dist(voter, ord_u) ** 2
1727                   : voter in domain(voter_wts) };
1728     };
1729
1730   new_wb := procedure(w, b, bss) {
1731     b2   := b;
1732     b2.a := b2.a + [assign_time(bss[t_j], b.n + t_j) : t_j in [1..#bss]];
1733     b2.n := #(b2.a);
1734
1735     w2   := w;
1736     w2.a := w2.a + [assign_time(bss[t_j], b.n + t_j) : t_j in [1..#bss]];
1737     w2.n := #(w2.a);
1738
1739     return [w, b];
1740   };
1741
1742   /* Optimal Normative Judgments / Prescriptions
1743      -------------------------------------------
1744      Returns a score for how much the list of decision states has had outputs
1745      of higher-order utility functions (i.e. normative judgments /
1746      prescriptions) that maximized higher-order utility. If the state space
1747      of prescriptions (n[j]['o']) overlap, we favor those states voted for by
1748      more accepted norms through a synchronic social choice function.
1749   */
1750   optimal_rxs := procedure(w, b, dss) {
1751     opts := [ optimality(w, b, dss[j], dss[j+1], b.n - (#dss - j) )
1752               : j in [1..(#dss - 1)] ];
1753     return 0.5 * min(opts) + 0.5 * avg(opts);
1754   };
1755
1756     ue_state_space := procedure() {
1757       base_exprs := +/ { ue_base_exprs(j) : j in [1..#n] };
1758       return choices({ { [subform, true], [subform, false] }
1759                        : subform in base_exprs });
1760     };
1761
1762     optimality := procedure(w, b, ds, ds2, t_i) {
1763       /* Social choice to balance multiple synchronic utility functions if
1764          they conflict.  */
1765       ord_us := { additive_to_ordinal(ds, j, ue_state_space()) : j in [1..#n] };
1766       sync_psc_us := choices({ { [state, r_i] : r_i in r[first(range(u))] }
1767                                : state in ue_state_space() });
1768       sc_u := sort_set(psc_us,
1769                        procedure(psc_u1, psc_u2) {
1770                          return sync_psc_dist(ord_us, psc_u1) <
1771                                 sync_psc_dist(ord_us, psc_u2);
1772                        })[1];
1773
1774       n_o_vars := +/ { n_i['o'] : n_i in n }; // Prescription vars
1775       // Observed state of those vars in ds2
1776       obs_rxs := { [n_o_var, ds2[n_o_var]] : n_o_var in n_o_vars };
1777
1778       // Collect all possible prescriptions along with their (higher) utilities.
1779       util_rxs := {
1780         [rxs, util_of_rxs(w, b, t_i, ds, ds2, psc_base_exprs, sc_u, rxs)]
1781         : rxs in poss_rx_states()
1782       };
1783       // Sort them by optimality.
1784       util_rxs := sort_set(util_rxs, procedure(rxs_u1, rxs_u2) {
1785                                        return last(rxs_u1) > last(rxs_u2);
1786                                      });
1787       // Return a normalized score for the obs_rxs by their percentile rank.
1788       return 1 - index_of(
1789         [ obs_rxs,
1790           util_of_rxs(w, b, t_i, ds, ds2, psc_base_exprs, sc_u, obs_rxs) ],
1791         util_rxs
1792       ) / #util_rxs;
1793     }; // end optimality
1794
1795       sync_psc_dist := procedure(ord_us, sync_psc_u) {
1796         ord_psc_u := card_u_to_ord_u(sync_psc_u, domain(sync_psc_u),
1797                                                  r[first(p)] );
1798         return +/ { ord_u_dist(ord_u, ord_psc_u) ** 2 : ord_u in ord_us };
1799       };
1800
1801       util_of_rxs := procedure(w, b, t_i, ds, ds2, psc_base_exprs, sc_u, rxs) {
1802         /* For the sake of simplicity, we assume that higher-order utilities
1803            depend on only intrinsic properties of brains / decision algorithms.
1804            This means that being given the future brain states bss is
1805            sufficient to tell us the utility of various prescriptions under
1806            this assumed future. This assumption can be quite plausible for
1807            higher-order utilities that enforce consistency, coherence or some
1808            form of reflective equilibrium. If we abandon this assumption, we
1809            may need to model a set of possible worlds and a probability
1810            distribution or measure over them.
1811
1812            We might typically expect higher-order utilities to be placed in
1813            some change in lower-order utility and then a recognition that some
1814            prescription would more-or-less immediately cause that change would
1815            cause the prescription and in turn, the intended change. But since
1816            we can neither assume that the higher-order utility is placed in
1817            a specific, concrete lower-order utility change in the near future as
1818            opposed to more open-ended properties nor assume the immediacy of the
1819            prescription's causation of a lower-order utility change, we just
1820            look very far into the future and sum up the utility of any events
1821            in that 4-dimensional space-time block that would be included in the
1822            reference of higher-order utility expressions. Since the network
1823            topology of the higher-order utility functions may be path dependent,
1824            we also use the bs_msr_paths to aggregate over the different futures
1825            made possible by various input states weighted by their subjective
1826            likelihood.
1827         */
1828         new_ds2 := rxs + { [var, val] : [var, val] in ds2
1829                                       | !(var in domain(rxs)) };
1830         bs := inv(f(b))[new_ds2];
1831         bmps := bs_msr_paths(w, b, bs, 10 ** 9);
1832         future_wts := {                      // collect a ...
1833           [ [first(bs_msr) : bs_msr in bmp], // list of brain states, bss,
1834             last(last(bmp)) ]                // & measure from the final state
1835           : bmp in last(bmps)                // for each bs_msr_path
1836         }; // to get { [bss, msr], ... }
1837
1838         return +/ {
1839           msr * util_of_future(w, b, t_i, ds, psc_base_exprs, sc_u, bss)
1840           : [bss, msr] in future_wts
1841         };
1842       }; // end util_of_rxs
1843
1844         util_of_future := procedure(w, b, t_i, ds, psc_base_exprs, sc_u, bss) {
1845           wb := new_wb(w, b, bss);
1846           w2 := first(wb);
1847           b2 := last(wb);
1848
1849           future_state := { [expr, eval_expr(w2, b2, t_i, ds, bss, expr)]
1850                             : expr in psc_base_exprs };
1851           return sc_u[future_state];
1852         };
1853
1854         // Returns a boolean for whether the expr is true in that future
1855         eval_expr := procedure(w, b, t_i, ds, bss, expr) {
1856           p_var := p[expr];
1857           p_event := { [p_var, ds[p_var]] };
1858           b_event := first( lf_inv_at(b,t_i)[p_event] );
1859           ref_b_event := ref(w,b)[b_event];
1860           disjuncts := { restricted_eq(w.actual_state(), disjunct)
1861                          : disjunct in ref_b_event };
1862           return #{ disj : disj in disjuncts | disj == true } > 0;
1863         };
1864
1865   /* Extensional rational utility */
1866   ext_ruf := procedure(w, b) {
1867     uf := ruf(w,b);
1868     // Map expressions to their referents.
1869     expr_ref := { [expr, ref_expr(w, b, b.n, expr)] : [expr, r_i] in uf };
1870     // Map every possible world state to its utility.
1871     return { [w_state, w_util(uf, expr_ref, w_state)]
1872              : w_state in w.cm().poss_states() };
1873   };
1874
1875     w_util := procedure(uf, expr_ref, w_state) {
1876       /* Truths, or utility relevant truths, I suppose. Collect the expressions
1877          in the rational utility function that had this w_state among its set of
1878          truthmakers / referents.  */
1879       truths := { expr : expr in domain(expr_ref) | w_state in expr_ref[expr] };
1880       // Sum the utilities
1881       return +/ { uf[expr] : expr in truths };
1882     };
1883
1884   /* Agential Identity
1885      -----------------
1886      Agential Identity is much like Personal Identity a la Derek Parfit's
1887      Reasons and Persons. But where personal identity roughly concerns when
1888      someone is the same person for the purposes of care, agential identity
1889      concerns when someone is the same agent for purposes of trusting their
1890      normative judgments.
1891
1892      If we are thinking in terms of ideal advisor / observer theories, we might
1893      be considering hypothetical versions of ourselves with more information
1894      or other qualities. But consider the full knowledge of what heroin feels
1895      like. If we had that information, we might become addicts and change our
1896      values. But this probably isn't a change that would make us want to defer
1897      to that self's values. We may protest that something in the process of
1898      adding this knowledge has changed our values, not illuminated them.
1899
1900      The concept of agential identity is meant to measure how much other
1901      possible selves truly reflect *our* values and agency. Generally, this
1902      will be measured either by similarity to our current selves or by
1903      identifying the changes as cognitive changes made through inference or
1904      applying higher-order decision criteria to values.
1905   */
1906   agential_identity := procedure(dss, w, b) { // dss : list of decision states
1907     return 0.5 * agential_continuity(dss, w, b) +
1908            // kinda like: 0.5 * agential_connection(dss[1], {}, dss[#dss])
1909            0.5 * (0.5 * p_conn(dss[1], last(dss)) +
1910                   0.5 * u_conn(dss[1], {}, last(#dss)));
1911   };
1912   agential_continuity := procedure(dss, w, b) {
1913     conns := [agential_connection(dss[j], dss[j+1], dss[j+2], w, b, j)
1914               : j in [1..(#dss - 2)] ];
1915     return 0.5 * min(conns) + 0.5 * avg(conns);
1916   };
1917   agential_connection := procedure(ds1, ds2, ds3, w, b, t_i) {
1918     return 0.5 * avg([p_conn(ds1, ds2), p_conn(ds2, ds3)]) +
1919            0.5 * u_conn(ds1, ds2, ds3, w, b, t_i);
1920   };
1921   /* Agential continuity restricted to p_conn.
1922      Used for measuring diachronic rationality in incoherence. */
1923   p_conn_continuity := procedure(dss) {
1924     return avg({ p_conn(dss[j], dss[j+1]) : j in [1..(#dss - 1)] });
1925   };
1926   /* Measures connectedness of credences between two decision states. They
1927      are connected by either having similar probability values or by reflecting
1928      cognitive changes, i.e. updating using conditional probabilities and
1929      resulting in probability values that are close to (locally) ideally
1930      rational inferences. */
1931   p_conn := procedure(ds1, ds2) {
1932     return avg({
1933       // Gain full credit of the higher of similarity or cognitive score and
1934       max( sim_cog_scores(ds1, ds2, p_i) ) +
1935         // Close the remaining distance proportional to
1936         (1 - max( sim_cog_scores(ds1, ds2, p_i) )) *
1937         // the other of the similarity or cognitive score
1938         min( sim_cog_scores(ds1, ds2, p_i) )
1939       // For every p var
1940       : p_i in p_vars()
1941     });
1942   };
1943
1944     sim_cog_scores := procedure(ds1, ds2, p_i) {
1945       return [p_i_sim(ds1, ds2, p_i), cog_change(ds1, ds2, p_i)];
1946     };
1947
1948     // Similarity / closeness. Returns 0-1.
1949     p_i_sim := procedure(ds1, ds2, p_i) {
1950       max_dist := max({ abs(ds1[p_i] - r_i) : r_i in r[p_i] });
1951       return 1 - abs(ds1[p_i] - ds2[id_var(p_i)]) / max_dist;
1952     };
1953
1954     // Cognitive change. Returns 0-1.
1955     cog_change := procedure(ds1, ds2, p_i) {
1956       if (p_i in range(p)) { // rather than range(cp)
1957         return 0;
1958       } else {
1959         arr := p_inv(p_i);
1960         hyp := arr[1];
1961         evd := arr[2];
1962         ancs := non_shared_ancestors(p_i, m);
1963         if (p[hyp] in ancs && p[evd] in ancs && cp[[evd, hyp]] in ancs) {
1964           /* For simplicity we just use the p vals in the immediate parent
1965              (ds1). Really we should construct and use
1966              non_shared_ancestors_with_depth and pull the p values from the
1967              correct time slice. Similarly for id_expr. */
1968
1969           // Rational P(H|E) = P(E|H) * P(H) / P(E)
1970           rat_h_e := ds1[cp[[evd, hyp]]] * ds1[p[hyp]] / ds1[p[evd]];
1971           // Distance from rational
1972           dist_rat := abs(rat_h_e - ds2[ cp[ [id_expr(hyp), id_expr(evd)] ] ]);
1973           // Maximum distance possible
1974           max_dist := max({ abs(rat_h_e - r_i) : r_i in r[p_i] });
1975           return 1 - dist_rat / max_dist;
1976         } else {
1977           return 0;
1978         }
1979       } // end else
1980     }; // end cog_change
1981
1982   /* Takes an expression e and returns the expression at the next time step
1983      that would be identical. In many cases, this is just the same expression e,
1984      but we define input variables as indexicals so the same expression next
1985      time step does not refer to the expression in this time step. So, we
1986      introduce a new term At(expr, -1) which at that time step, would refer to
1987      the same as this time's expr.
1988   */
1989   id_expr := procedure(expr) {
1990     if (isList(expr)) { // in case it's called on p_inv of cp var
1991       return [ id_expr(expr_i) : expr_i in expr ];
1992     } else {
1993       if (p[expr] in i) { // current input
1994         return At_t(expr, -1);
1995       } else if (isTerm(expr) && fct(expr) == "At_t") { // past, add 1 more step
1996         return At_t(args(expr)[1], args(expr)[2] - 1);
1997       } else {
1998         return expr;
1999       }
2000     }
2001   };
2002
2003   /* Takes a prob variable and finds its expr preimage, then finds the expr that
2004      in the next time would be identical to this expr. Returns that expr var. */
2005   id_var := procedure(p_var) {
2006     return p[id_expr(p_inv(p_var))];
2007   };
2008
2009   poss_i_events := procedure() {
2010     return +/ { possible_states(isub, r) : isub in ne_pow(i) };
2011   };
2012
2013   e_vars := procedure() {
2014     return +/ { range(n_i['e']) : n_i in n };
2015   };
2016
2017   poss_ue_events := procedure() {
2018     return +/ { possible_states(ue_sub, r)
2019                 : ue_sub in ne_pow(range(u) + e_vars()) };
2020   };
2021
2022   poss_p_i_events := procedure() {
2023     return +/ { { [p_i, r_i] : r_i in r[p_i] } : p_i in range(p) };
2024   };
2025
2026   poss_p_var_events := procedure() {
2027     return +/ { { [p_i, r_i] : r_i in r[p_i] } : p_i in p_vars() };
2028   };
2029
2030   // Possible states of all prescription vars
2031   poss_rx_states := procedure() {
2032     n_o_vars := +/ { n_i['o'] : n_i in n };
2033     return possible_states(n_o_vars, r);
2034   };
2035
2036   // Possible single prescriptions for some higher-order utility
2037   poss_rxs := procedure() {
2038     n_os := { n_i['o'] : n_i in n };
2039     return +/ { possible_states(n_o, r) : n_o in n_os };
2040   };
2041
2042   /* Utility Function Connectedness
2043      ------------------------------
2044      Measures how much the utility function has either remained similar or
2045      changed as the result of a cognitive process involving i) recognition that
2046      some prescription (rx) would cause a utility change, ii) that recognition
2047      in fact causes the prescription and iii) that prescription causes the
2048      utility change. These are to be contrasted with changes to utilities from
2049      mere noise, associations or biases.  */
2050   u_conn := procedure(w, b, t_i, ds1, ds2, ds3) {
2051     actual_rxs := { rx : rx in poss_rxs()
2052                        | rx_to_tuple(w, b, t_i, ds1, ds2, ds3, rx) != {} };
2053     rx_subsets := pow(actual_rxs);
2054
2055     dists := { dist_to(w, b, t_i, ds1, ds2, ds3, rx_subset)
2056                : rx_subset in rx_subsets };
2057     return 1 - min(dists);
2058   }; // end u_conn
2059
2060     /* Takes a prescription and returns the tuples if any which realize i, ii
2061        and iii above.  */
2062     rx_to_tuple := procedure(w, b, t_i, ds1, ds2, ds3, rx) {
2063       poss_tuples := poss_p_var_events() >< poss_i_events()  ><
2064                                p_range() >< poss_ue_events();
2065       return { tuple : tuple in poss_tuples
2066                      | observed(w, b, t_i, rx, ds1, ds2, ds3, tuple) };
2067     };
2068
2069       observed := procedure(w, b, t_i, rx, ds1, ds2, ds3, tuple) {
2070         f_p_i  := tuple[1]; // Assignment of value to p_i, rx []-> ue
2071         g_i_rx := tuple[2]; /* Assignment of value to a prescription which is
2072                                introspectively accessible as i vars */
2073         p_ue_val := tuple[3]; // Credence placed in ue (the consequent of []->)
2074         h_ue   := tuple[4]; // ue event
2075         return f_p_i != {} && g_i_rx != {} && h_ue != {} &&
2076           // g_i_rx and rx are implemented by the same brain event and
2077           // the decision events occur at the right times
2078           lf_inv(g_i_rx) == lf_inv(rx) && restricted_eq(ds2, g_i_rx) &&
2079           restricted_eq(ds2, rx) && restricted_eq(ds1, f_p_i) &&
2080           restricted_eq(ds3, h_ue) &&
2081           // first(domain(f_p_i)) is p_i and p_i is _ []-> _
2082           fct(p_var_inv(first(domain(f_p_i)))) == "BoxArrow" &&
2083           /* The ref of the brain event of ds1 implementing the placement of
2084              prob in the p_i expr == lf_inv h_ue in two time steps
2085              i.e. the consequent of []-> refers to the intended ue change */
2086           /* Todo: Allow for changes that had i, ii, and iii but only partially
2087              updated the utility / eval functions.  */
2088           ref(w,b)[lf_inv_at(b, t_i)[
2089             {[ p[args(p_var_inv(first(domain(f_p_i))))[2]], p_ue_val ]}
2090           ]] == lf_inv_at(b, t_i + 2)[h_ue] &&
2091           // p_i influences each var in rx
2092           first(domain(f_p_i)) in { parents(v) : v in domain(rx) } &&
2093           // each var in rx influences each var in the utility change
2094           forall(v in g_i_rx | v in { parents(ue) : ue in domain(h_ue) });
2095       };
2096
2097     /* Given a subset of observed prescriptions, we compare the resulting
2098        utility function to what was prescribed within that subset. The overall
2099        u_conn score will take the minimum distance seen this way.
2100          Todo: Allow for changes that had i, ii, and iii but only partially
2101        updated the utility / eval functions.  */
2102     dist_to := procedure(w, b, t_i, ds1, ds2, ds3, rx_subset) {
2103       u1 := { [u_i, ds1[u_i]] : u_i in u };
2104       e1 := { u1 } + { { [e_i, ds1[e_i]] : e_i in n_i['e'] } : n_i in n };
2105
2106       rxd := { [e_i, rx_e_i_val(w, b, t_i, ds1, ds2, ds3, rx_subset, e_i)]
2107                : e_i in domain(e1) };
2108       rxd_u := { [u_i, rxd[u_i]] : u_i in u };
2109       rxd_n := [ { [e_i, rxd[e_i]] : e_i in n_i['e'] } : n_i in n ];
2110       rxd_e := [ rxd_u ] + rxd_n;
2111       // The prescribed util / eval change
2112       ord_rxd_e := [ additive_to_ordinal(rxd_e[j], j, ue_state_space())
2113                      : j in [1..#rxd_e] ];
2114       // The actual change in ds3
2115       ord_e := [ additive_to_ordinal(e_func(ds3, j), j, ue_state_space())
2116                  : j in [1..#rxd_e] ];
2117
2118       e_dists := [ ord_u_dist(ord_e[j], ord_rxd_e[j]) : j in [1..#ord_e] ];
2119
2120       // Todo: Add weights?
2121       return avg(e_dists);
2122     }; // end dist_to
2123
2124       /* Given a subset of observed prescriptions and an e_i var, return the
2125          value prescribed for the e_i var.  */
2126       rx_e_i_val := procedure(w, b, t_i, ds1, ds2, ds3, rx_subset, e_i) {
2127         /* The prescribed values (rxds) are the values of the e_i var in the
2128            ue event from rx_to_tuple (for any rxs that prescribe for e_i). */
2129         rxds := { rx_to_tuple(w, b, t_i, ds1, ds2, ds3, rx_i)[4][e_i]
2130           : rx_i in rx_subset  // h_ue[e_i]
2131           | e_i in domain(rx_to_tuple(w, b, t_i, ds1, ds2, ds3, rx_i)[4]) };
2132             // e_i in domain(h_ue)
2133         if (#rxds > 0) {
2134           // If #rxds > 1, they should all be the same anyway bc it was observed
2135           return first(rxds);
2136           /* Todo: In later versions, we probably want to allow for non-exact
2137              changes and then choose the one closest to the observed.  */
2138         } else {
2139           return e1[e_i]; // No change
2140         }
2141       };
2142
2143   // Utility / Evaluation Function implemented in a given decision state ds
2144   e_func := procedure(ds, j) {
2145     if (j == 0) {
2146       return { [u_i, ds[u_i]] :  u_i in range(u) };
2147     } else {
2148       return { [e_i, ds[e_i]] : e_i in range(n[j]['e']) };
2149     }
2150   };
2151
2152   ue := procedure(j) {
2153     if (j == 0) {
2154       return u;
2155     } else {
2156       return n[j]['e'];
2157     }
2158   };
2159
2160   ue_base_exprs := procedure(j) {
2161     return +/ { subformulas(x_i) : x_i in domain(ue(j)) };
2162   };
2163
2164   /* Takes a decision state, i.e. a function from (among other things) utility
2165      variables to numbers (utilities), and an index j and returns a set of
2166      SuccEq (succeeds or equals) setlx functors. If j is 0, then u is converted
2167      to ordinal, otherwise, n[j]['e'] is. */
2168   additive_to_ordinal := procedure(ds, j, state_space) {
2169     card_u := add_u_to_card_u(e_func(ds,j), state_space);
2170     return card_u_to_ord_u( card_u, domain(card_u), r[first(p)] );
2171   };
2172
2173   /* Brain-State Measure Paths
2174      -------------------------
2175      Returns a list where for each future time, there is a set of
2176      bs_msr_paths, each of which in turn is a list of bs_msrs for each time
2177      from the first to the given time. A bs_msr is a pair [bs, msr].
2178
2179      One can think in terms of a tree. At the root is the given starting brain
2180      state. Each branch is a continuation with different inputs and a measure
2181      for that branch based on subjective likelihood. A path is a full branch
2182      line from root to leaf collecting pairs of brain states and measures along
2183      the way.
2184
2185      e.g. [bs_msr_paths_t1, ..., bs_msr_paths_tz]
2186        bs_msr_paths_tj := { bs_msrs_tj_1, bs_msr_tj_2, ... }
2187          bs_msrs_tj_k := [ bs_msr_t1, ..., bs_msr_tj ]
2188            bs_msr_tj := [bs_tj, msr]
2189
2190                      [ bs1, 1 ]
2191                     /   |      \
2192                is1 /    |is2    \  is3   (input states leading to continuations)
2193                   /     |        \
2194                  /      |         \
2195      [bs_t2a, 1/6]  [bs_t2b, 1/2]  [bs_t2c, 1/3]
2196       /    |    \     /   |   \      /   |   \
2197      ...
2198
2199      There's some duplication and space inefficiency in having the previous
2200      times' brain states and measures present both in the earlier elements of
2201      the top level list as well as within the set of paths for each element.
2202      We probably could do without it but it makes it a little more convenient
2203      when calculating the voter weights for each time's voters in computing
2204      the rational utility function. Some aspects of those weights like the
2205      agential identity depend on the entire path taken and not just the final
2206      brain state.
2207   */
2208   bs_msr_paths := procedure(w, b, bs1, t_j) {
2209     if (t_j == 1) {
2210       return [{[[bs1, 1]]}];
2211     } else {
2212       return bs_msr_paths(w, b, bs1, t_j - 1) +
2213         [+/ {
2214            { bmp + [bs_msr]
2215              : bs_msr in next_bs_msrs(w, b, last(bmp)[1], last(bmp)[2], t_j-1) }
2216            : bmp in last(bs_msr_paths(w, b, bs1, t_j - 1))
2217          }];
2218     }
2219   };
2220
2221   /* Takes a brain, brain state, measure and prev t_i and returns the possible
2222      continuations in the next time step together with their measure
2223      roughly proportional to the subjective likelihood.  */
2224   next_bs_msrs := procedure(w, b, bs_i, msr, t_j) {
2225     bs_j := b.response(bs_i);
2226     // Possible brain input states from each di possible decision input states.
2227     pbis := { [di, lf_inv(b)[di]] : di in poss_i_states() };
2228     /* Possibly empty brain input states since we now filter by compatibility
2229        with the brain response bs_j. (Recall that input vars may overlap with
2230        other vars that bs_j may dictate values for.) */
2231     pe_bis := { [di, { pbi : pbi in pbi_s | compat(pbi, bs_j) }]
2232                 : [di, pbi_s] in pbis };
2233     // pbi_s = possible brain input sets
2234     bis := { [di, pbi_s] : [di, pbi_s] in pe_bis | pbi_s != {} };
2235
2236     /* For each brain input state of each decision input state, map the total
2237        brain state including the response bs_j to its new measure.
2238
2239        Ideally, the new measure would be proportional to the brain input
2240        state's subjective probability. This was under development but doing it
2241        in a way that is biologically plausible presents a challenge. To avoid
2242        an implausible number of explicit probabilities, we'd probably have to
2243        look at the closest coherent extensions of the current probability
2244        distribution as well as allow for indirect reference, which introduces
2245        its own challenges in translating probabilities from direct to indirect.
2246
2247        Although I by no means think these challenges insurmountable, the
2248        technical complications involved seemed too great for a first version
2249        and not worth delaying the initial release over. As a placeholder here,
2250        we simply assume each possible decision input state is equally probable
2251        and each brain state implementing a given decision input state is
2252        similarly equally probable to other such implementations.
2253
2254        While incorporating the subjective probability seems preferable, it's
2255        also worth mentioning that it may not actually be necessary. The main
2256        motivation is to make continuations of the agent under very weird
2257        scenarios matter less. But if the worry there is that those
2258        circumstances are distorting the agent's values, we already have the
2259        agential_identity measure to discount them. In other words, agential
2260        identity may screen off a circumstance's weirdness from its relevance.
2261     */
2262     return +/ {
2263       { [ bi + bs_j, msr * (1 / #domain(bis)) * (1 / #bis[di]) ]
2264         : bi in bis[di] }
2265       : di in domain(bis)
2266     };
2267   };
2268
2269
2270 // Class Methods
2271 // =============
2272
2273   static {
2274     /* Function from a causal_model of a brain b and a set of decision
2275        algorithm candidates to the decision algorithm that is the best
2276        compression of the brain.  */
2277     implemented_by := cachedProcedure(b, ds) {
2278       if (ds == {}) {
2279         ds := decision_algorithm.all(b);
2280       }
2281       /* Requiring simplest version helps ensure higher-order ambitiousness,
2282          i.e. prevents smuggling in higher-order norms within the n[j]['m2']
2283          variables. In future iterations, this might be softened.  */
2284       ds := [d : d in ds | d.is_implemented_by(b) && d.is_simplest_version(b)];
2285       ds := sort_list(ds, decision_algorithm.better_explanation(b));
2286       return ds[1];
2287     };
2288
2289     /* Given a causal model of a brain, return the set of possible decision
2290        algorithms which could be implemented by it based simply on number of
2291        states. A decision algorithm can't be more fine-grained than its
2292        substrate.  */
2293     all := cachedProcedure(b) {
2294       return { d : d in decision_algorithm.all_lte(#b.poss_states()) };
2295     };
2296
2297     // All with #poss_states <= z
2298     // Todo: Add possible At_t exprs and predicates and quantifiers
2299     all_lte := cachedProcedure(z) {
2300       poss_i := da().ltr_up_to('I', z/2);
2301       var_ltrs := { 'A', 'B', 'C' };
2302       poss_base_vars := da().vars_up_to(var_ltrs, n);
2303       poss_exprs := { da().add_up_to(pbe, z/2)
2304                       : pbe in poss_base_vars };
2305       poss_p := da().poss_expr_to_ltr(poss_exprs, 'P');
2306       // e.g. { [[x, y], 'P(x|y)'], ... }
2307       poss_cp := pow({ [[x, y], 'P(' + str(x) + '|' + str(y) + ')']
2308                        : [x, y] in poss_exprs >< poss_exprs });
2309       poss_o := da().ltr_up_to('O', z/2);
2310       poss_u := da().poss_expr_to_ltr(poss_exprs, 'U');
2311       poss_m := da().ltr_up_to('M', z/2);
2312       poss_m2 := da().ltr_up_to('M2', z/2);
2313       poss_n := +/ { choices({ da().poss_nj(poss_exprs, z, j) : j in [1..x] })
2314                      : x in [1..z] };
2315       return +/ {
2316         +/ { da().poss_ds(d_i, d_o, d_p, d_cp, d_u, d_m, d_m2, d_n, poss_r)
2317              : poss_r in da().poss_rs(z, d_i, d_o, d_p, d_cp,
2318                                          d_u, d_m, d_m2, d_n) }
2319         : [d_i, d_o, d_p, d_cp, d_u, d_m, d_m2, d_n] in
2320           da().cart_prod(poss_i, poss_o, poss_p, poss_cp,
2321                          poss_u, poss_m, poss_m2, poss_n)
2322       };
2323     }; // end all_lte
2324
2325       ltr_up_to := procedure(ltr, j) {
2326         return { ltr + '_' + y : y in [1..j] };
2327       };
2328
2329       vars_up_to := procedure(ltrs, j) {
2330         return +/ { da().ltr_up_to(ltr, j) : ltr in ltrs };
2331       };
2332
2333       add_one := procedure(exprs) {
2334         unary := { 'Not' };
2335         binary := { 'And', 'Or', 'Implies', 'BoxArrow' };
2336         add_un := { makeTerm(op, [expr]) : [op, expr] in unary >< exprs };
2337         add_bi := { makeTerm(op, [expr1, expr2])
2338                     : [op, [expr1, expr2]] in binary >< (exprs >< exprs) };
2339         return exprs + add_un + add_bi;
2340       };
2341
2342       add_up_to := procedure(base_vars, j) {
2343         if (j == 0) {
2344           return base_vars;
2345         } else {
2346           return da().add_one( da().add_up_to(base_vars, j - 1) );
2347         }
2348       };
2349
2350       expr_to_ltr_var := procedure(expr, ltr) {
2351         return ltr + '(' + replace(str(expr), '"', '') + ')';
2352       };
2353
2354       poss_expr_to_ltr := procedure(poss_exprs, ltr) {
2355         return { { [expr, da().expr_to_ltr_var(expr, ltr)] : expr in subset }
2356                  : subset in pow(poss_exprs) };
2357       };
2358
2359       poss_nj := procedure(poss_exprs, z, j) {
2360         poss_e_nj := da().poss_expr_to_ltr(poss_exprs, 'E_n' + j);
2361         poss_m2_nj := da().ltr_up_to('M2_n' + j, z/2);
2362         poss_o_nj := da().ltr_up_to('O_n' + j, z/2);
2363         return { { ['e', e_n], ['m', m_n], ['o', o_n] }
2364           : [e_n, m_n, o_n] in cart_prod([poss_e_nj, poss_m2_nj, poss_o_nj]) };
2365       };
2366
2367       poss_rs := procedure(z, d_i, d_o, d_p, d_cp, d_u, d_m, d_m2, d_n) {
2368         poss_p_vals := { { j / x : j in [0..x] } : x in [1..z] };
2369         poss_ue_vals := ne_pow({ j : j in [1..2**z] });
2370         poss_z_vals := { { j : j in [1..x] } : x in [1..z] };
2371         poss_o_vals := poss_z_vals;
2372
2373         poss_r_ps := {
2374           { [i_var,  p_vals] : i_var  in d_i         } +
2375           { [p_var,  p_vals] : p_var  in range(d_p)  } +
2376           { [cp_var, p_vals] : cp_var in range(d_cp) }
2377           : p_vals in poss_p_vals
2378         };
2379
2380         return +/ choices(
2381           { poss_r_ps, da().poss_r_ue(poss_ue_vals, d_u) } +
2382           { da().poss_r_ue(poss_ue_vals, n_i['e']) : n_i in d_n } +
2383           { da().poss_r_z(poss_z_vals, d_z) : d_z in { d_o, d_m, d_m2 } }
2384         );
2385       }; // end poss_rs
2386
2387         poss_r_ue := procedure(poss_ue_vals, ue) {
2388           return { { [ue_var, ue_vals] : ue_var in range(ue) }
2389                    : ue_vals in poss_ue_vals };
2390         };
2391
2392         poss_r_z := procedure(poss_z_vals, d_z) {
2393           return choices({ {z_var} >< poss_z_vals : z_var in d_z });
2394         };
2395
2396       poss_ds := procedure(z, d_i, d_o, d_p, d_cp, d_u, d_m, d_m2, d_n, d_r) {
2397         poss_is_state := possible_states(d_i + d_p + d_cp +
2398                                          d_u + d_m + d_m2 + d_n, d_r);
2399         poss_s_state  := possible_states(d_p + d_cp + d_u +
2400                                          d_m + d_m2 + d_n, d_r);
2401         poss_t_s := function_space(poss_is_state, poss_s_state);
2402
2403         poss_p_u_m2 := possible_states(d_p + d_u + d_m2, d_r);
2404         poss_o_state := possible_states(d_o, d_r);
2405         poss_t_o := function_space(poss_p_u_m2, poss_o_state);
2406
2407         das := {
2408           decision_algorithm(d_i, d_o, d_p, d_cp, d_u, d_m, d_m2, d_n,
2409                              d_r, d_t_s, d_t_o, om, om, om)
2410           : [d_t_s, d_t_o] in poss_t_s >< poss_t_o
2411         };
2412         return { da : da in das | da.is_valid() && #da.poss_states() <= z};
2413       };
2414
2415     better_explanation := cachedProcedure(b) {
2416       return procedure(d1, d2) {
2417                return da().expl_score(b, d1) > da().expl_score(b, d2);
2418              };
2419     };
2420
2421       expl_score := procedure(b, d_i) {
2422         return d_i.ambitiousness(b) - d_i.complexity(b)
2423                - d_i.instr_irrat(b) - d_i.incoherence(b);
2424       };
2425
2426     simpler := cachedProcedure() {
2427       return procedure(d1, d2) {
2428                return k(d1.to_s) < k(d2.to_s);
2429              };
2430     };
2431
2432     new := procedure() {
2433       return decision_algorithm({}, {}, {}, {}, {}, {}, {}, [], {}, {}, {},
2434                                 om, om, om);
2435     };
2436
2437   }
2438 }
2439
2440 // alias
2441 da := procedure() { return decision_algorithm; };
   1 print("\nTesting Decision Algorithm");
   2 print(  "==========================");
   3
   4 test_s := procedure() {
   5   d := decision_algorithm({'I'}, {'O'}, { ['A', 'P(A)'] }, // i, o, p
   6     { [['A', 'A'], 'P(A|A)'] }, {['A','U(A)']}, {'M'}, {'M2'}, // cp, u, m, m2
   7     [{ ['e', {['B','E_n1(B)']}], ['m2', {'M2_n1'}], ['o', {'O_n1'}] }], // n
   8     {}, {}, {}, om, om, om); // r, t_s, t_o, cacheds
   9   assert(d.s() == { 'P(A)', 'P(A|A)', 'U(A)', 'M', 'M2',
  10                     'E_n1(B)', 'M2_n1', 'O_n1' },
  11          "Error: s is incorrect.");
  12   print('[ok] s');
  13 };
  14 test_s();
  15
  16 test_t := procedure() {
  17   d := decision_algorithm.new();
  18   d.i := { 'I' };
  19   d.o := { 'O' };
  20   d.p := { ['A', 'P'] };
  21   d.t_s := { // is                         -> s
  22              [{ ['I', false], ['P', false] }, { ['P', false] }],
  23              [{ ['I', false], ['P', true ] }, { ['P', true ] }],
  24              [{ ['I', true ], ['P', false] }, { ['P', true ] }],
  25              [{ ['I', true ], ['P', true ] }, { ['P', false] }]
  26            }; // xor
  27   d.t_o := { // p u m2       -> o
  28              [{ ['P', false] }, { ['O', false] }],
  29              [{ ['P', true ] }, { ['O', true ] }]
  30            }; // identity
  31   assert(d.t() == {
  32            // is                         ->  so
  33            [{["I", false], ["P", false]}, {["O", false], ["P", false]}],
  34            [{["I", false], ["P", true ]}, {["O", true ], ["P", true ]}],
  35            [{["I", true ], ["P", false]}, {["O", false], ["P", true ]}],
  36            [{["I", true ], ["P", true ]}, {["O", true ], ["P", false]}]
  37          },
  38          "Error: t is incorrect.");
  39   print('[ok] t');
  40 };
  41 test_t();
  42
  43 test_ns := procedure() {
  44   d := decision_algorithm.new();
  45   d.n := [{ ['e', {['A','E_n1(A)']}], ['m2', {'M2_n1'}], ['o', {'O_n1'}] },
  46           { ['e', {['B','E_n2(B)']}], ['m2', {'M2_n2'}], ['o', {'O_n2'}] } ];
  47   assert(d.ns( 'e') == { 'E_n1(A)', 'E_n2(B)' } &&
  48          d.ns('m2') == {   'M2_n1', 'M2_n2'   } &&
  49          d.ns( 'o') == {    'O_n1', 'O_n2'    },
  50          "Error: ns is incorrect.");
  51   print('[ok] ns');
  52 };
  53 test_ns();
  54
  55 test_new := procedure() {
  56   assert(decision_algorithm.new().t_o == {},
  57          "Error: new is incorrect.");
  58   print('[ok] new');
  59 };
  60 test_new();
  61
  62 test_p_u_vars := procedure() {
  63   d := decision_algorithm.new();
  64   d.p  := { [       'A',   'P(A)'] };
  65   d.cp := { [['A', 'A'], 'P(A|A)'] };
  66   d.u  := { [       'A',   'U(A)'] };
  67   assert(d.p_u_vars() == {'P(A)', 'P(A|A)', 'U(A)'},
  68          "Error: is incorrect.");
  69   print('[ok] p_u_vars');
  70 };
  71 test_p_u_vars();
  72 test_p_vars := procedure() { test_p_u_vars(); };
  73
  74 test_just_p_u_m2 := procedure() {
  75   d := decision_algorithm.new();
  76   d.i  := { 'I' };
  77   d.p  := { ['A', 'P(A)'] };
  78   d.u  := { ['A', 'U(A)'] };
  79   d.m2 := { 'M2' };
  80   assert(d.just_p_u_m2({ ['I', true],
  81                          ['P(A)', 0.3], ['U(A)', 4], ['M2', true] }) ==
  82                        { ['P(A)', 0.3], ['U(A)', 4], ['M2', true] },
  83          "Error: just_p_u_m2 is incorrect.");
  84   print('[ok] just_p_u_m2');
  85 };
  86 test_just_p_u_m2();
  87
  88 test_parents := procedure() {
  89   d := decision_algorithm.new();
  90   d.m := { 'M1', 'M2' };
  91   d.r := { ['M1', {true, false}], ['M2', {true,false}] };
  92   d.t_s := { // is                  -> s
  93     [{ ['M1', false], ['M2', false] }, { ['M1', true ], ['M2', true ] }],
  94     [{ ['M1', false], ['M2', true ] }, { ['M1', false], ['M2', true ] }],
  95     [{ ['M1', true ], ['M2', false] }, { ['M1', false], ['M2', false] }],
  96     [{ ['M1', true ], ['M2', true ] }, { ['M1', true ], ['M2', false] }]
  97   }; // M1 = ~xor; M2 = ~M1
  98   assert(d.parents('M1') == {'M1', 'M2'} && d.parents('M2') == {'M1'},
  99          "Error: parents is incorrect.");
 100   print('[ok] parents');
 101   assert(d.children('M1') == { 'M1', 'M2' } && d.children('M2') == {'M1'},
 102         "Error: children is incorrect.");
 103   print('[ok] children');
 104 };
 105 test_children               := procedure() { test_parents(); };
 106 test_is_necessary_parent_of := procedure() { test_parents(); };
 107 test_vals_diff              := procedure() { test_parents(); };
 108 test_parents();
 109
 110 /*   ,------.
 111     I--P--Y--X
 112      `--U-'
 113          `--Z
 114 */
 115 test_non_shared_ancestors := procedure() {
 116   d := decision_algorithm.new();
 117   d.i := {'I'};
 118   d.p := {['A', 'P']};
 119   d.u := {['B', 'U']};
 120   d.m2 := {'X', 'Y', 'Z'};
 121   d.r := { ['I', tf()], ['P', {0,1}], ['U', {0,1}],
 122            ['X', tf()], ['Y', tf()], ['Z', tf()] };
 123   ts_proc := procedure(is_state) {
 124     return { ['P', !is_state['I']], ['U', is_state['I']],
 125              ['X', !is_state['Y'] || is_state['I']],
 126              ['Y', is_state['P'] + is_state['U'] % 2],
 127              ['Z', is_state['U'] == 0] };
 128   };
 129   d.t_s := proc2func(ts_proc, d.poss_is_states());
 130   assert(d.non_shared_ancestors('X', d.m2) == { 'I', 'P', 'U' } &&
 131          d.non_shared_ancestors('Y', d.m2) == { 'P', 'U' } &&
 132          d.non_shared_ancestors('Z', d.m2) == { 'U' },
 133          "Error: non_shared_ancestors is incorrect.");
 134   print('[ok] non_shared_ancestors');
 135
 136   assert(d.poss_i_states() == { {['I', true]}, {['I', false]} },
 137          "Error: poss_i_states is incorrect.");
 138   print('[ok] poss_i_states');
 139
 140   assert({ {["P", 0], ["U", 0], ["X",  true], ["Y",  true], ["Z",  true]},
 141            {["P", 1], ["U", 1], ["X", false], ["Y", false], ["Z", false]}
 142          } < d.poss_s_states(),
 143          "Error: poss_s_states is incorrect");
 144   print('[ok] poss_s_states');
 145
 146   assert(d.poss_u_states() == { {['U', 0]}, {['U', 1]} },
 147          "Error: poss_u_states is incorrect.");
 148   print('[ok] poss_u_states');
 149
 150   assert(d.is_equal_to(d),
 151          "Error: is_equal_to is incorrect");
 152   print('[ok] is_equal_to true');
 153
 154   d2 := d;
 155   d2.i := d.i + { 'I2' };
 156   assert(!d2.is_equal_to(d),
 157          "Error: is_equal_to is incorrect");
 158   print('[ok] is_equal_to false');
 159 };
 160 test_non_shared_ancestors();
 161 test_poss_is_states := procedure() { test_non_shared_ancestors(); };
 162 test_poss_i_states  := procedure() { test_non_shared_ancestors(); };
 163 test_poss_s_states  := procedure() { test_non_shared_ancestors(); };
 164 test_poss_u_states  := procedure() { test_non_shared_ancestors(); };
 165 test_is_equal_to    := procedure() { test_non_shared_ancestors(); };
 166
 167
 168
 169 /* X--Y--O
 170     `--M--P
 171 */
 172 test_non_shared_descendants := procedure() {
 173   d := decision_algorithm.new();
 174   d.m2 := {'X', 'Y'};
 175   d.o := {'O'};
 176   d.m := {'M'};
 177   d.p := {['A','P']};
 178   d.r := { ['X', tf()], ['Y', tf()], ['O', tf()], ['M', tf()], ['P', {0,1}] };
 179   ts_proc := procedure(is_state) {
 180     return { ['X', true], ['Y', !is_state['X']], ['O', is_state['Y']],
 181              ['M', is_state['X']], ['P', #{ j : j in {1} | is_state['M']}] };
 182   };
 183   d.t_s := proc2func(ts_proc, d.poss_is_states());
 184   to_proc := procedure(p_u_m2) {
 185     return {[ 'O', p_u_m2['Y'] ]};
 186   };
 187   d.t_o := proc2func(to_proc, { d.just_p_u_m2(is) : is in d.poss_is_states() });
 188   assert(d.non_shared_descendants('X', d.m2) == {'M', 'O'} &&
 189          d.non_shared_descendants('Y', d.m2) == {'O'},
 190          "Error: non_shared_descendants is incorrect.");
 191   print('[ok] non_shared_descendants');
 192 };
 193 test_non_shared_descendants();
 194
 195 d1 := cachedProcedure() {
 196   d   := decision_algorithm.new();
 197   d.i := { 'I' };
 198   d.p := { ['A', 'P'] };
 199   d.o := { 'O' };
 200   d.r := { [var, tf()] : var in {'I','O'} } + { ['P', {0,1}] };
 201   d.t_s := { [{['I', false], ['P', 0]}, {['P', 1]}], // eg P_t2 = ~I xor P_t1
 202              [{['I', false], ['P', 1]}, {['P', 0]}],
 203              [{['I',  true], ['P', 0]}, {['P', 0]}],
 204              [{['I',  true], ['P', 1]}, {['P', 1]}]
 205            };
 206   d.t_o := { [ {['P', 0]}, {['O',  true]} ],  // O = ~P
 207              [ {['P', 1]}, {['O', false]} ] };
 208   return d;
 209 };
 210
 211 b1 := cachedProcedure() {
 212   b   := causal_markov_model.new();
 213   b.u := { 'U' };
 214   b.v := { 'V_P1', 'V_P2', 'O' };
 215   b.r := { [var, tf()] : var in {'V_P1', 'V_P2', 'O'} } + {['U',{1,2,3}]};
 216   /* P = V_P1 <-> V_P2
 217      O = ~ P
 218      O = ~ (V_P1 <-> V_P2)
 219   */
 220   b.f['O'] := proc2func(procedure(cmm_st) {
 221                           return !(cmm_st['V_P1'] == cmm_st['V_P2']);
 222                         }, b.poss_states());
 223   /* P_t2 = I xor P_t1
 224           = U xor (V_P1 <-> V_P2)
 225     t1  U V_P1 V_P2 P  ~I  t2  P  V_P1  V_P2
 226         1   F   F   T   T      F   T    F
 227         1   F   T   F   T      T   T    T
 228         1   T   F   F   T      T   F    F
 229         1   T   T   T   T      F   F    T
 230         2   F   F   T   T      F
 231         2   F   T   F   T      T
 232         2   T   F   F   T      T
 233         2   T   T   T   T      F
 234         3   F   F   T   F      T   F    F
 235         3   F   T   F   F      F   T    F
 236         3   T   F   F   F      F   F    T
 237         3   T   T   T   F      T   T    T
 238
 239     two ways for U to be false {1,2}. {3} is truth
 240   */
 241   b.f['V_P1'] := proc2func(procedure(cmm_st) {
 242                    if (cmm_st['U'] == 3) {
 243                      return cmm_st['V_P2'];
 244                    } else {
 245                      return !cmm_st['V_P1'];
 246                    }
 247                  }, b.poss_states());
 248   b.f['V_P2'] := proc2func(procedure(cmm_st) {
 249                    if (cmm_st['U'] == 3) {
 250                      return cmm_st['V_P1'];
 251                    } else {
 252                      return cmm_st['V_P2'];
 253                    }
 254                  }, b.poss_states());
 255   b.n := 3;
 256   return b;
 257 };
 258
 259 plf1 := cachedProcedure() {
 260   return { [{ ['U', 1]                         }, { ['I', false] }],
 261            [{ ['U', 2]                         }, { ['I', false] }],
 262            [{ ['U', 3]                         }, { ['I',  true] }],
 263            [{ ['V_P1', false], ['V_P2', false] }, { ['P',     1] }],
 264            [{ ['V_P1', false], ['V_P2',  true] }, { ['P',     0] }],
 265            [{ ['V_P1',  true], ['V_P2', false] }, { ['P',     0] }],
 266            [{ ['V_P1',  true], ['V_P2',  true] }, { ['P',     1] }],
 267            [{ ['O', false]                     }, { ['O', false] }],
 268            [{ ['O',  true]                     }, { ['O',  true] }]
 269          };
 270 };
 271
 272 pf1 := cachedProcedure() {
 273   return d1().plf_to_pf(b1(), plf1());
 274 };
 275
 276 test_poss_states := procedure() {
 277   assert(d1().poss_states() == {
 278            {["I", false], ["O", false], ["P", 0]},
 279            {["I", false], ["O", false], ["P", 1]},
 280            {["I", false], ["O",  true], ["P", 0]},
 281            {["I", false], ["O",  true], ["P", 1]},
 282            {["I",  true], ["O", false], ["P", 0]},
 283            {["I",  true], ["O", false], ["P", 1]},
 284            {["I",  true], ["O",  true], ["P", 0]},
 285            {["I",  true], ["O",  true], ["P", 1]}
 286          }, "Error: poss_states is incorrect.");
 287   print('[ok] poss_states');
 288 };
 289 test_poss_states();
 290
 291 test_commutes := procedure() {
 292   // print('pf ' + pf1());
 293
 294   // This may take a while so it's commented out but it worked last time.
 295   // assert(d1().commutes(pf1(), b1()) == true, "Error: commutes true is incorrect.");
 296   // print('[ok] commutes true');
 297   print('[..] commutes true');
 298 };
 299 test_commutes();
 300
 301 test_lf_commutes := procedure() {
 302   d := d1();
 303   d.cached_f := pf1();
 304   assert(d.lf_commutes(plf1(), b1()) == true,
 305          "Error: lf_commutes true is incorrect");
 306   print('[ok] lf_commutes true');
 307
 308   plf := plf1();
 309   plf[ {['O', false]} ] := { ['O', true] };
 310   assert(d.lf_commutes(plf, b1()) == false,
 311          "Error: lf_commutes false is incorrect");
 312   print('[ok] lf_commutes false');
 313 };
 314 test_lf_commutes();
 315
 316 d2 := procedure() {
 317   d := d1();
 318   d.cached_f  := pf1();
 319   d.cached_lf := plf1();
 320   return d;
 321 };
 322
 323 test_is_implemented_by := procedure() {
 324   assert(d2().is_implemented_by(b1()) == true,
 325          "Error: is_implemented_by is incorrect.");
 326   print('[ok] is_implemented_by');
 327 };
 328 test_is_implemented_by();
 329
 330 test_lf_inv := procedure() {
 331   assert(d2().lf_inv(b1())[ {['P',1]} ] == {
 332            { ['V_P1', false], ['V_P2', false] },
 333            { ['V_P1',  true], ['V_P2',  true] }
 334          }, "Error: lf_inv is incorrect");
 335   print('[ok] lf_inv');
 336 };
 337 test_lf_inv();
 338 test_plf_to_pf := procedure() { test_lf_inv(); };
 339
 340 test_lf_inv_at := procedure() {
 341   assert(d2().lf_inv_at(b1(), 2)[ {['P',1]} ] == {
 342            { ['V_P1_t2', false], ['V_P2_t2', false] },
 343            { ['V_P1_t2',  true], ['V_P2_t2',  true] }
 344          }, "Error: lf_inv_at is incorrect");
 345   print('[ok] lf_inv_at');
 346 };
 347 test_lf_inv_at();
 348
 349 test_lf_cm := procedure() {
 350   assert(d2().lf_cm(b1(), {['V_P1_t2',false],['V_P2_t2',false]}) == {['P',1]},
 351          "Error: lf_cm is incorrect");
 352   print('[ok] lf_cm');
 353 };
 354 test_lf_cm();
 355
 356 test_lf_cm_vs := procedure() {
 357   assert(d2().lf_cm_vs(b1(), {['V_P1_t2',false],['V_P2_t2',false] }) == {'P'},
 358          "Error: lf_cm_vs is incorrect");
 359   print('[ok] lf_cm_vs');
 360 };
 361 test_lf_cm_vs();
 362
 363 test_lf_cm_p_inv := procedure() {
 364   assert(d2().lf_cm_p_inv(b, { ['V_P1_t2', false], ['V_P2_t2', false] }) == 'A',
 365          "Error: lf_cm_p_inv is incorrect");
 366   print('[ok] p_inv');
 367   print('[ok] lf_cm_p_inv');
 368 };
 369 test_lf_cm_p_inv();
 370 test_p_inv := procedure() { test_lf_cm_p_inv(); };
 371
 372 test_commutes_f := procedure() {
 373   // print('b.f[O] ' + b.f['O']);
 374   b := b1();
 375   b.f['O'] := proc2func(procedure(cmm_st) {
 376                           return cmm_st['V_P1'] && cmm_st['V_P2'];
 377                         }, b.poss_states());
 378   // print('b.f[O] ' + b.f['O']);
 379   // bs := {["O", true], ["U", 3], ["V_P1", true], ["V_P2", true]};
 380   // print('pf[bs] ' + pf[bs]);
 381   // print('t()[pf[bs]] ' + d.t()[pf[bs]]);
 382   // print('b.resp ' + b.response(b.v, bs));
 383   // print('pf[b.resp] ' + pf[b.response(b.v, bs)]);
 384
 385   // assert(d1().commutes(pf1(), b) == false, "Error: commutes false is incorrect.");
 386   // print('[ok] commutes false');
 387   print('[..] commutes false');
 388 };
 389 test_commutes_f();
 390
 391 test_drop_i := procedure() {
 392   d := decision_algorithm.new();
 393   d.i := { 'P(I_1)', 'P(I_2)' };
 394   ds  := { ['P(A)', 1], ['P(I_1)', true], ['P(I_2)', false], ['M1', true] };
 395   assert(d.drop_i(ds) == { ['P(A)', 1], ['M1', true] },
 396          "Error: drop_i is incorrect.");
 397   print('[ok] drop_i');
 398 };
 399 test_drop_i();
 400
 401 /*
 402     I--P--Y--X--O
 403      `--U-'
 404          `--Z--W
 405 */
 406 test_m2s_are_valid := procedure() {
 407   d    := decision_algorithm.new();
 408   d.i  := { 'I' };
 409   d.p  := { ['A', 'P'] };
 410   d.u  := { ['B', 'U'] };
 411   d.m2 := { 'X', 'Y', 'Z' };
 412   d.o  := { 'W', 'O' };
 413   d.r  := { [var, tf()] : var in d.i + d.s() };
 414   ts_proc := procedure(is_state) {
 415     return { ['P', !is_state['I']], ['U', is_state['I']],
 416              ['X', !is_state['Y']],
 417              ['Y', is_state['P'] && is_state['U']],
 418              ['Z', is_state['U'] == 0] };
 419   };
 420   d.t_s := proc2func(ts_proc, d.poss_is_states());
 421   to_proc := procedure(p_u_m2) {
 422     return { ['O', p_u_m2['X']], ['W', p_u_m2['W']] };
 423   };
 424   d.t_o := proc2func(to_proc, { d.just_p_u_m2(is) : is in d.poss_is_states() });
 425   assert(d.m2s_are_valid() == true, "Error: is incorrect.");
 426   print('[ok] m2s_are_valid true');
 427
 428   // I------X
 429   ts_proc2 := procedure(is_state) {
 430     return { ['P', !is_state['I']], ['U', is_state['I']],
 431              ['X', !is_state['Y'] || is_state['I']],
 432              ['Y', is_state['P'] && is_state['U']],
 433              ['Z', is_state['U'] == 0] };
 434   };
 435   d.t_s := proc2func(ts_proc2, d.poss_is_states());
 436   assert(d.m2s_are_valid() == false, "Error: is incorrect.");
 437   print('[ok] m2s_are_valid false');
 438
 439   // W-----U
 440   ts_proc3 := procedure(is_state) {
 441     return { ['P', !is_state['I']], ['U', is_state['I'] && is_state['W']],
 442              ['X', !is_state['Y']],
 443              ['Y', is_state['P'] && is_state['U']],
 444              ['Z', is_state['U'] == 0] };
 445   };
 446   d.t_s := proc2func(ts_proc2, d.poss_is_states());
 447   assert(d.m2s_are_valid() == false, "Error: is incorrect.");
 448   print('[ok] m2s_are_valid false 2');
 449 };
 450 test_m2s_are_valid();
 451
 452 /*
 453 test_no_e_in_u := procedure() {
 454   d := decision_algorithm.new();
 455   assert(d.no_e_in_u() == ,
 456          "Error: no_e_in_u is incorrect.");
 457   print('[ok] no_e_in_u false');
 458
 459   assert(d.no_e_in_u() == ,
 460          "Error: no_e_in_u is incorrect.");
 461   print('[ok] no_e_in_u true');
 462 };
 463 test_no_e_in_u();
 464 */
 465
 466 /* test_i_ref := procedure() {
 467   print(d1().i_ref(b2(), b2())); // out of memory
 468 //  assert(d1().i_ref(b1(), b1()) ==
 469 //         "Error: i_ref is incorrect.");
 470   print('[  ] i_ref');
 471 };
 472 test_i_ref();
 473 */
 474
 475 test_str_exprs := procedure() {
 476   d := decision_algorithm.new();
 477   d.i := { 'P(I_1)' };
 478   d.p := { ['A', 'P(A)'], ['B', 'P(B)'], ['I_1', 'P(I_1)'],
 479            [And('A', 'B'), 'P(A^B)'],
 480            [BoxArrow('A', 'B'), 'P(A[]->B)'] };
 481   assert(d.str_exprs() == { ['A',0] , ['B',0] },
 482          "Error: is incorrect.");
 483   print('[ok] str_exprs');
 484 };
 485 test_str_exprs();
 486
 487 test_preds := procedure() {
 488   d := decision_algorithm.new();
 489   d.i := { 'P(I_1)' };
 490   d.p := { ['A', 'P(A)'], ['B', 'P(B)'], ['I_1', 'P(I_1)'],
 491            [And('A', 'B'), 'P(A^B)'], [Q('A'), 'P(Q(A))'],
 492            [R('A','B'), 'P(R(A,B))'],
 493            [BoxArrow('A', 'B'), 'P(A[]->B)'] };
 494   assert(d.preds() == { ['Q', 1], ['R', 2] },
 495          "Error: is incorrect.");
 496   print('[ok] preds arity');
 497 };
 498 test_preds();
 499
 500 w1 := procedure() {
 501   w := causal_markov_model.new();
 502   w.u := {};
 503   w.v := { 'X', 'Y' };
 504   w.n := 2;
 505   w.r := { ['X', tf()], ['Y', tf()] };
 506   w.f := { ['X', { [{['X', false], ['Y', false]}, false],
 507                    [{['X', false], ['Y',  true]},  true],
 508                    [{['X',  true], ['Y', false]},  true],
 509                    [{['X',  true], ['Y',  true]},  true]
 510                  }],
 511            ['Y', { [{['X', false], ['Y', false]},  true],
 512                    [{['X', false], ['Y',  true]},  true],
 513                    [{['X',  true], ['Y', false]},  true],
 514                    [{['X',  true], ['Y',  true]}, false]
 515                  }]
 516          };
 517 };
 518
 519 test_poss_base_expr_refs := procedure() {
 520   d := decision_algorithm.new();
 521   w := w1();
 522   // print(d.poss_base_expr_refs(w, { ['A', 0] }));
 523   // print(d.poss_base_expr_refs(w, { ['A', 0], [Q('A'), 1], [R('A','B'), 2] }));
 524   // print(d.poss_base_expr_refs(w, { ['A', 0], [Q('A'), 1] }));
 525   // 2 ** 81 subsets
 526   // assert(d.poss_base_expr_refs(w, { 'A', Q('A'), R('A','B') }),
 527   //        "Error: is incorrect.");
 528   // print('[ok] poss_base_expr_refs');
 529 };
 530 test_poss_base_expr_refs();
 531
 532 /*
 533 test_poss_base_refs := procedure() {
 534   d := decision_algorithm.new();
 535   d.cached_lf := { };
 536   w := w1();
 537   w_sts := w1.cm().poss_states();
 538   pbers := {
 539     { ['A', { w_sts[1], w_sts[2] }],
 540       ['Q', { [{ w_sts[1], w_sts[2] }],
 541               [{ w_sts[4] }] }] },
 542     { ['A', { w_sts[3], w_sts[4] }],
 543       ['Q', { [{ w_sts[2], w_sts[3] }],
 544               [{ w_sts[5] }] }] }
 545   };
 546   // assert(d.poss_base_refs(w, b, pbers) == ,
 547   //         "Error: poss_base_refs is incorrect.");
 548   print('[ok] poss_base_refs');
 549 };
 550 // test_poss_base_refs();
 551 */
 552
 553 test_rr := procedure() {
 554   d := decision_algorithm.new();
 555   b := causal_markov_model.new();
 556   b.v := { 'V_1' };
 557   b.r := { ['V_1', tf()] };
 558   b.f := {
 559     ['V_1', { [{ ['V_1', false] },  true],
 560               [{ ['V_1',  true] }, false]
 561             }]
 562   };
 563   b.n := 3; // bug when set to 2?
 564   // rr(expr, [w, b, atom_ref, ti, context])
 565   assert(d.rr('A', [b, b, {}, 1, { ['A', { {['V_1_t1', true]} }] }]) ==
 566                                          { {['V_1_t1', true]} },
 567          "Error: rr context is incorrect.");
 568   print('[ok] rr context');
 569
 570   d.i := { 'P(I_1)' };
 571   d.p := { ['I_1','P(I_1)'] };
 572   b.a := [ {['V_1_t1',  true]},
 573            {['V_1_t2', false]},
 574            {['V_1_t3',  true]} ];
 575   d.cached_lf := {
 576     [ {['V_1', false]}, {['P(I_1)', false]} ],
 577     [ {['V_1',  true]}, {['P(I_1)',  true]} ]
 578   };
 579   all_sts := b.cm().poss_states();
 580   assert(d.rr('I_1', [b, b, {}, 1, {}]) ==
 581            compat_compl_sts( {['V_1_t1', true]}, all_sts ),
 582          "Error: rr i is incorrect.");
 583   print('[ok] rr i');
 584
 585   assert(d.rr(At_t('I_1', -1), [b, b, {}, 2, {}]) ==
 586            compat_compl_sts( {['V_1_t1', true]}, all_sts ),
 587          "Error: rr At_t is incorrect.");
 588   print('[ok] rr At_t');
 589
 590   atom_ref := { ['B', compat_compl_sts( {['V_1_t1', true]}, all_sts )],
 591                 ['IsAorB', { [compat_compl_sts({['V_1_t1', true]}, all_sts)],
 592                              [compat_compl_sts({['V_1_t2', true]}, all_sts)] }]
 593               };
 594   assert(d.rr('B', [b, b, atom_ref, 1, {}]) ==
 595            compat_compl_sts({['V_1_t1', true]}, all_sts) &&
 596          d.rr('IsAorB', [b, b, atom_ref, 1, {}]) == {
 597            [compat_compl_sts({['V_1_t1', true]}, all_sts)],
 598            [compat_compl_sts({['V_1_t2', true]}, all_sts)]
 599          },
 600          "Error: rr atom_ref is incorrect.");
 601   print('[ok] rr atom_ref');
 602
 603   atom_ref := { ['C', compat_compl_sts( {['V_1_t1', true]}, all_sts )],
 604                 ['D', compat_compl_sts( {['V_1_t2', true]}, all_sts )] };
 605   assert(d.rr(And('C', 'D'), [b, b, atom_ref, 1, {}]) ==
 606            compat_compl_sts({['V_1_t1', true], ['V_1_t2', true]}, all_sts),
 607          "Error: rr And is incorrect");
 608   print('[ok] rr And');
 609
 610   assert(d.rr(Or('C', 'D'), [b, b, atom_ref, 1, {}]) ==
 611            compat_compl_sts({['V_1_t1', true]}, all_sts) +
 612            compat_compl_sts({['V_1_t2', true]}, all_sts),
 613          "Error: rr Or is incorrect");
 614   print('[ok] rr Or');
 615
 616   assert(d.rr(Not('C'), [b, b, atom_ref, 1, {}]) ==
 617            compat_compl_sts({['V_1_t1', false]}, all_sts),
 618          "Error: rr Not is incorrect");
 619   print('[ok] rr Not');
 620
 621   assert(d.rr(Implies('C', 'D'), [b, b, atom_ref, 1, {}]) ==
 622            compat_compl_sts({['V_1_t1', false]}, all_sts) +
 623            compat_compl_sts({['V_1_t2', true]}, all_sts),
 624          "Error: rr Implies is incorrect");
 625   print('[ok] rr Implies');
 626
 627   print('[  ] rr');
 628 };
 629 test_rr();
 630
 631 test_true_p := procedure() {
 632   d := decision_algorithm.new();
 633   b_event := {['V', true]};
 634   ref_i := { [ b_event, { {['X', true]}, {['Y', true]} }] };
 635   w := causal_markov_model.new();
 636   // TODO: rewrite to use states rather than events
 637 // or just fold into sq_err
 638   w.a := [{ ['Y', true] }];
 639   assert(d.true_p(w, ref_i, b_event) == 1, "Error: true_p true is incorrect.");
 640   print('[ok] true_p true');
 641
 642   w.a := [{ ['X', true] }];
 643   assert(d.true_p(w, ref_i, b_event) == 1, "Error: true_p true is incorrect.");
 644   print('[ok] true_p true 2');
 645
 646   w.a := [{ ['X', false] }];
 647   assert(d.true_p(w, ref_i, b_event) == 0, "Error: true_p false is incorrect.");
 648   print('[ok] true_p false');
 649 };
 650 //test_true_p();
 651
 652 test_sq_err := procedure() {
 653   d := decision_algorithm.new();
 654   d.p := { ['A', 'P(A)'] };
 655   d.cached_lf := { [ {['V',  true]}, {['P(A)', 0.75]} ],
 656                    [ {['V', false]}, {['P(A)', 0.33]} ] };
 657   b := causal_markov_model.new();
 658   b.a := [{['V_t1', true]}, {['V_t2', false]}];
 659   ref_i := { [{['V_t1',  true]}, { {['V_t1', true], ['V_t2', false]},
 660                                    {['V_t1', true], ['V_t2',  true]} }],
 661              [{['V_t2', false]}, { {['V_t1', true], ['V_t2', false]},
 662                                    {['V_t1', true], ['V_t2',  true]} }] };
 663   assert(abs(d.sq_err(b, b, ref_i) - 0.5114) < 0.01,
 664          "Error: sq_err is incorrect.");
 665   print('[ok] true_p');
 666   print('[ok] sq_err');
 667 };
 668 test_sq_err();
 669 test_true_p := procedure() { test_sq_err(); };
 670
 671 b2 := procedure() {
 672   b := b1();
 673   b.n := 2;
 674   b.a := [
 675     { ['U_t1', 1], ['V_P1_t1', false], ['V_P2_t1', false], ['O_t1',  true] },
 676     { ['U_t2', 2], ['V_P1_t2',  true], ['V_P2_t2', false], ['O_t2', false] }
 677   ];
 678   return b;
 679 };
 680
 681 test_ref_expr := procedure() {
 682   d := d2();
 683   b := b2();
 684   bs1 := {{['U', 1], ['V_P1_t1', false], ['V_P2_t1', false], ['O', false]}};
 685   d.cached_ref := {
 686     [ {['V_P1_t1', false], ['V_P2_t1', false]}, bs1 ]
 687   };
 688   assert(d.ref_expr(b, b, 1, 'A') == bs1,
 689          "Error: ref_expr is incorrect.");
 690   print('[ok] ref_expr');
 691 };
 692 test_ref_expr();
 693
 694 test_actual_p_events := procedure() {
 695   assert(d2().actual_p_events(b2()) == {
 696            { ['V_P1_t1', false], ['V_P2_t1', false] },
 697            { ['V_P1_t2',  true], ['V_P2_t2', false] }
 698          },
 699          "Error: actual_p_events is incorrect.");
 700   print('[ok] actual_p_events');
 701 };
 702 test_actual_p_events();
 703
 704 test_prob_states := procedure() {
 705   assert(d2().prob_states(b2()) == { [1, {['P', 1]}], [2, {['P', 0]}] },
 706          "Error: prob_states is incorrect.");
 707   print('[ok] prob_states');
 708   print('[ok] prob_states_t');
 709 };
 710 test_prob_states();
 711 test_prob_states_t := procedure() { test_prob_states(); };
 712
 713 d3 := procedure() {
 714   d := decision_algorithm.new();
 715   d.u := { ['A', 'U(A)'] };
 716   d.o := { 'O' };
 717   d.n := [{ ['e', {['B','E1(B)']}], ['m2',{'M2_1'}], ['o',{'O_1'}] },
 718           { ['e', {['C','E2(C)']}], ['m2',{'M2_2'}], ['o',{'O_2'}] }];
 719   return d;
 720 };
 721
 722 test_eo := procedure() {
 723   assert(d3().eo() == { [{ ['A',  'U(A)'] }, { 'O' }],
 724                         [{ ['B', 'E1(B)'] }, {'O_1'}],
 725                         [{ ['C', 'E2(C)'] }, {'O_2'}] },
 726          "Error: eo is incorrect.");
 727   print('[ok] eo');
 728 };
 729 test_eo();
 730
 731 test_instr_irrat := procedure() {
 732   print('test instr irrat');
 733   d := decision_algorithm.new();
 734   d.o := { 'O' };
 735   d.p := { ['A', 'P(A)'],
 736            [Not('A'), 'P(~A)'],
 737            [BoxArrow('A', 'B'), 'P(A []-> B)'],
 738            [BoxArrow(Not('A'), 'B'), 'P(~A []-> B)'] };
 739   d.u := { ['B', 'U(B)'] };
 740   d.r := { ['P(A)', {0.3, 0.7}],
 741            ['P(~A)', {0.1, 0.9}],
 742            ['P(A []-> B)', {0.2, 0.8}],
 743            ['P(~A []-> B)', {0.25, 0.75}],
 744            ['U(B)', { 5 }], ['O', tf()] };
 745   b := causal_markov_model.new();
 746   b.u := {};
 747   b.v := { 'V_A', 'V_~A', 'V_A_[]->_B', 'V_~A_[]->_B', 'V_O', 'V_U' };
 748   b.r := { [var, tf()] : var in b.v };
 749   false_func := proc2func(procedure(bs) { return false; }, b.poss_states());
 750   print('false func');
 751   b.f := {
 752     ['V_A', false_func],
 753     ['V_~A', false_func],
 754     ['V_A_[]->_B', false_func],
 755     ['V_~A_[]->_B', false_func],
 756     ['V_O', false_func],
 757     ['V_U', false_func]
 758   };
 759   b.n := 3;
 760   b.a := [
 761     { ['V_A_t1',  true], ['V_~A_t1', false],
 762       ['V_~A_[]->_B_t1', false], ['V_~A_[]->_B_t1', true],
 763       ['V_O_t1', false], ['V_U_t1', false] },
 764     { ['V_A_t2',  true], ['V_~A_t2', false],
 765       ['V_~A_[]->_B_t2', false], ['V_~A_[]->_B_t2', true],
 766       ['V_O_t2', false], ['V_U_t2', false] },
 767     { ['V_A_t3',  true], ['V_~A_t3', false],
 768       ['V_~A_[]->_B_t3', false], ['V_~A_[]->_B_t3', true],
 769       ['V_O_t3', false], ['V_U_t3', false] }
 770   ];
 771   d.cached_lf := {
 772     [{['V_A', false]},         {['P(A)', 0.3]}        ],
 773     [{['V_A',  true]},         {['P(A)', 0.7]}        ],
 774     [{['V_~A', false]},        {['P(~A)', 0.1]}       ],
 775     [{['V_~A',  true]},        {['P(~A)', 0.9]}       ],
 776     [{['V_A_[]->_B', false]},  {['P(A []-> B)', 0.2]} ],
 777     [{['V_A_[]->_B',  true]},  {['P(A []-> B)', 0.8]} ],
 778     [{['V_~A_[]->_B', false]}, {['P(~A []-> B)', 0.2]}],
 779     [{['V_~A_[]->_B',  true]}, {['P(~A []-> B)', 0.8]}],
 780     [{['V_O', false]},         {['O', false]}         ],
 781     [{['V_O',  true]},         {['O',  true]}         ],
 782     [{['V_U', false]},         {['U(B)', false]}      ],
 783     [{['V_U',  true]},         {['U(B)',  true]}      ]
 784   };
 785   print('cached lf');
 786   d.cached_f := d.plf_to_pf(b, d.cached_lf);
 787   print('cached f');
 788   b_cm := b.cm();
 789   print('b cm');
 790   b_cm_poss_states := b_cm.poss_states();
 791   print(#b_cm_poss_states);
 792   o_t2 := compat_compl_sts({['V_O_t2', true]}, b_cm_poss_states);
 793   print('o_t2');
 794   o_t3 := compat_compl_sts({['V_O_t3', true]}, b_cm_poss_states);
 795   no_t2 := compat_compl_sts({['V_O_t2', false]}, b_cm_poss_states);
 796   no_t3 := compat_compl_sts({['V_O_t3', false]}, b_cm_poss_states);
 797   print('no_t3');
 798   d.cached_ref := {
 799     [{['V_A_t1', true ]}, o_t2],
 800     [{['V_A_t1', false]}, o_t2],
 801
 802     [{['V_~A_t1', true ]}, no_t2],
 803     [{['V_~A_t1', false]}, no_t2],
 804
 805     [{['V_A_t2', true ]}, o_t3],
 806     [{['V_A_t2', false]}, o_t3],
 807
 808     [{['V_~A_t2', true ]}, no_t3],
 809     [{['V_~A_t2', false]}, no_t3]
 810
 811   };
 812   // print(d.instr_irrat(b, b));
 813   // assert(d.instr_irrat() == ,
 814   //       "Error: instr_irrat is incorrect.");
 815   print('[.?] instr_irrat');
 816 };
 817 // test_instr_irrat();
 818
 819 test_max_p_dist := procedure() {
 820   d := decision_algorithm.new();
 821   d.p := { ['A', 'P(A)'], ['B', 'P(B)'] };
 822   thirds := { 0, 0.33, 0.66, 1 };
 823   d.r := { ['P(A)', thirds], ['P(B)', thirds] };
 824   b := causal_markov_model.new();
 825   b.v := { 'V_A', 'V_B' };
 826   four := { 1,2,3,4 };
 827   b.r := { ['V_A', four], ['V_B', four] };
 828   d.cached_f := {
 829     [{['V_A', 1], ['V_B', 1]}, {['P(A)',    0], ['P(B)',    0]}],
 830     [{['V_A', 1], ['V_B', 2]}, {['P(A)',    0], ['P(B)', 0.33]}],
 831     [{['V_A', 1], ['V_B', 3]}, {['P(A)',    0], ['P(B)', 0.66]}],
 832     [{['V_A', 1], ['V_B', 4]}, {['P(A)',    0], ['P(B)',    1]}],
 833     [{['V_A', 2], ['V_B', 1]}, {['P(A)', 0.33], ['P(B)',    0]}],
 834     [{['V_A', 2], ['V_B', 2]}, {['P(A)', 0.33], ['P(B)', 0.33]}],
 835     [{['V_A', 2], ['V_B', 3]}, {['P(A)', 0.33], ['P(B)', 0.66]}],
 836     [{['V_A', 2], ['V_B', 4]}, {['P(A)', 0.33], ['P(B)',    1]}],
 837     [{['V_A', 3], ['V_B', 1]}, {['P(A)', 0.66], ['P(B)',    0]}],
 838     [{['V_A', 3], ['V_B', 2]}, {['P(A)', 0.66], ['P(B)', 0.33]}],
 839     [{['V_A', 3], ['V_B', 3]}, {['P(A)', 0.66], ['P(B)', 0.66]}],
 840     [{['V_A', 3], ['V_B', 4]}, {['P(A)', 0.66], ['P(B)',    1]}],
 841     [{['V_A', 4], ['V_B', 1]}, {['P(A)',    1], ['P(B)',    0]}],
 842     [{['V_A', 4], ['V_B', 2]}, {['P(A)',    1], ['P(B)', 0.33]}],
 843     [{['V_A', 4], ['V_B', 3]}, {['P(A)',    1], ['P(B)', 0.66]}],
 844     [{['V_A', 4], ['V_B', 4]}, {['P(A)',    1], ['P(B)',    1]}]
 845   };
 846   b.a := [{['V_A_t1', 2], ['V_B_t1', 3]}];
 847   assert(d.max_p_dist(b, 1) == 1.33,
 848          "Error: max_p_dist is incorrect.");
 849   print('[ok] max_p_dist');
 850 };
 851 test_max_p_dist();
 852
 853 test_poss_cms := procedure() {
 854   d := decision_algorithm.new();
 855   d.p := { ['A', 'P(A)'], ['B', 'P(B)'], ['C', 'P(C)'] };
 856   d.r := { [var, tf()] : var in range(d.p) };
 857   assert(exists(cm in d.poss_cms() |
 858            cm.f == {
 859              ["P(A)", { [{["P(B)", false]},  true],
 860                         [{["P(B)",  true]}, false] }],
 861              ["P(B)", { [{["P(C)", false]}, false],
 862                         [{["P(C)",  true]},  true] }]
 863            }) &&
 864          exists(cm in d.poss_cms() |
 865            cm.f == {
 866              ["P(A)", { [{["P(B)", false]}, false],
 867                         [{["P(B)",  true]}, false]} ],
 868              ["P(C)", { [{["P(A)", false]},  true],
 869                         [{["P(A)",  true]},  true] }]
 870            }),
 871          "Error: poss_cms is incorrect.");
 872   print('[ok] poss_cms');
 873 };
 874 test_poss_cms();
 875 test_poss_cms_from_l      := procedure() { test_poss_cms(); };
 876 test_poss_cms_from_p_pars := procedure() { test_poss_cms(); };
 877
 878 test_e_func := procedure() {
 879   d := d3();
 880   ds := { ['U(A)', 5], ['E1(B)', 3], ['E2(C)', 8] };
 881   assert(d.e_func(ds, 0) == { ['U(A)',  5] } &&
 882          d.e_func(ds, 1) == { ['E1(B)', 3] } &&
 883          d.e_func(ds, 2) == { ['E2(C)', 8] },
 884          "Error: e_func is incorrect.");
 885   print('[ok] e_func');
 886 };
 887 test_e_func();
 888
 889 test_ue := procedure() {
 890   d := d3();
 891   assert(d.ue(0) == d.u && d.ue(1) == d.n[1]['e'] && d.ue(2) == d.n[2]['e'],
 892          "Error: ue is incorrect.");
 893   print('[ok] ue');
 894 };
 895 test_ue();
 896
 897 test_ue_base_exprs := procedure() {
 898   d := d3();
 899   assert(d.ue_base_exprs(0) == { 'A' } &&
 900          d.ue_base_exprs(1) == { 'B' } &&
 901          d.ue_base_exprs(2) == { 'C' },
 902          "Error: ue_base_exprs is incorrect.");
 903   print('[ok] ue_base_exprs');
 904 };
 905 test_ue_base_exprs();
 906
 907 /*
 908 test_state_space := procedure() {
 909   d := decision_algorithm.new();
 910   d.p := { ['A', 'P(A)'], ['B', 'P(B)'] };
 911   assert(d.state_space(range(d.p)) == {
 912            {Not('A'), Not('B')},
 913            {Not('A'),     'B' },
 914            {    'A' , Not('B')},
 915            {    'A' ,     'B' }
 916          },
 917          "Error: state_space is incorrect.");
 918   print('[ok] state_space');
 919   assert(d.event_space(range(d.p)) == d.state_space(range(d.p)) + {
 920            { Not('A') }, { 'A' }, { Not('B') }, { 'B' }, {}
 921          },
 922          "Error: event_space is incorrect.");
 923   print('[ok] event_space');
 924   // print(d.expr_space(d.state_space(range(d.p))));
 925   assert(d.expr_space( d.state_space(range(d.p)) ) == {
 926            And("A",      "B"), And(    "A" , Not("B")),
 927            And("B", Not("A")), And(Not("A"), Not("B"))
 928          },
 929          "Error: expr_space is incorrect.");
 930   print('[ok] expr_space');
 931
 932   d.p[And("A", "B")] := 'P(A^B)';
 933   d.p[And("A", Not("B"))] := 'P(A^~B)';
 934   d.p[And("B", Not("A"))] := 'P(B^~A)';
 935   d.p[And(Not("A"), Not("B"))] := 'P(~A^~B)';
 936   d.r := { ['P(A^B)', {0,1}], ['P(A^~B)', {0,1}],
 937            ['P(B^~A)', {0,1}], ['P(~A^~B)', {0,1}] };
 938   assert({["P(A^B)", 1], ["P(A^~B)", 0], ["P(B^~A)", 0], ["P(~A^~B)", 0]}
 939            in d.poss_p_vs({'P(A)', 'P(B)'}),
 940          "Error: poss_p_vs is incorrect");
 941   print('[ok] poss_p_vs');
 942 };
 943 test_state_space();
 944 test_event_space := procedure() { test_state_space(); };
 945 test_expr_space := procedure() { test_expr_space(); };
 946 test_poss_p_vs := procedure() { test_poss_p_vs(); };
 947 */
 948
 949 // deprecated?
 950 /*
 951 test_p_of_vs := procedure() {
 952   d := decision_algorithm.new();
 953   d.p := { ['A', 'P(A)'], ['B', 'P(B)'], ['C', 'P(C)'] };
 954   cm := causal_model(u, v, r, f, om);
 955   cm.u := { 'P(A)', 'P(B)' };
 956   cm.v := { 'P(C)' };
 957   cm.r := { [var, tf()] : var in cm.u + cm.v };
 958   cm.f := {
 959     ['P(C)', { [ {['P(A)', false], ['P(B)', false]}, false],
 960                [ {['P(A)', false], ['P(B)',  true]},  true],
 961                [ {['P(A)',  true], ['P(B)', false]},  true],
 962                [ {['P(A)',  true], ['P(B)',  true]},  true]
 963              }]
 964   };
 965   assert(d.p_of_vs(cm, { ['P(A)', 0.33], ['P(B)', 0.5] }) == ,
 966          "Error: p_of_vs is incorrect.");
 967   print('[ok] p_of_vs');
 968 };
 969 test_p_of_vs();
 970 */
 971
 972 test_coh_pcms := procedure() {
 973   cm := causal_model.new();
 974   cm.u := { 'A' };
 975   cm.v := { 'B' };
 976   cm.r := { ['A', tf()], ['B', tf()] };
 977   cm.f := { ['B', { [{ ['A', false] },  true],
 978                     [{ ['A',  true] }, false] }] };
 979   d := decision_algorithm.new();
 980   d.p := { ['A', 'P(A)'] };
 981   d.r := { ['P(A)', { 0, 1 }] };
 982 //  print(d.coh_pcms(cm));
 983 //  assert(d.coh_pcms(cm) == ,
 984 //         "Error: coh_pcms is incorrect.");
 985   print('[.?] coh_pcms');
 986 };
 987 // test_coh_pcms();
 988
 989 /* Template
 990 test_ := procedure() {
 991   d := decision_algorithm.new();
 992   assert(d.() == ,
 993          "Error:  is incorrect.");
 994   print('[ok] ');
 995 };
 996 test_();
 997 */
 998
 999 print(' ');
1000
1001 test_expr_to_p_funcs := procedure() {
1002   d := decision_algorithm.new();
1003   d.p := { ['A', 'P(A)'], ['B', 'P(B)'] };
1004   assert(d.expr_to_p_funcs(Implies('A', 'B'), {'A', 'B' }) == {
1005            {["P(A)", false], ["P(B)", false]},
1006            {["P(A)", false], ["P(B)",  true]},
1007            {["P(A)",  true], ["P(B)",  true]}
1008          }, "Error: expr_to_p_funcs is incorrect.");
1009   print('[ok] expr_to_p_funcs');
1010
1011   d.p[Implies('A', 'B')] := 'P(A->B)';
1012   d.p[Not(And('A', Not('B')))] := 'P(~(A^~B))';
1013   assert(d.equiv_p_expr(d.p, d.cp, 'P(A->B)', 'P(~(A^~B))') == true,
1014          "Error: equiv_p_expr is incorrect");
1015   print('[ok] equiv_p_expr true');
1016 };
1017 test_expr_to_p_funcs();
1018
1019 test_sum_p := procedure() {
1020   d := decision_algorithm.new();
1021   d.p := { ['A', 'P(A)'], ['B', 'P(B)'], ['C', 'P(C)'] };
1022   p1 := { ['P(A)', 0.6], ['P(C)', 0.3] };
1023   p2 := { ['P(B)', 0.2], ['P(C)', 0.5] };
1024   assert(d.sum_p(p1, p2) == { ['P(A)', 0.6], ['P(B)', 0.2], ['P(C)', 0.8] },
1025          "Error: sum_p is incorrect.");
1026   print('[ok] sum_p');
1027 };
1028 test_sum_p();
1029
1030 test_add_p_distr := procedure() {
1031   d := decision_algorithm.new();
1032   d.p := { ['A', 'P(A)'], ['B', 'P(B)'], ['C', 'P(C)'] };
1033   d.cp := { [['C', 'A'], 'P(C|A)'], [['C', 'B'], 'P(C|B)'] };
1034   p_cp1 := [{ ['P(A)', 0.2] }, { ['P(C|A)', 0.3], ['P(C|B)', 0.4] }];
1035   p_cp2 := [{ ['P(A)', 0.4] }, { ['P(C|A)', 0.1], ['P(C|B)', 0.3] }];
1036   p_cp := d.add_p_distr(p_cp1, p_cp2);
1037   assert((p_cp[2])['P(C|A)'] == 0.4 && (p_cp[2])['P(C|B)'] == 0.7 &&
1038          (p_cp[1])['P(A)'] - 0.6 < 0.01,
1039          "Error: add_p_distr is incorrect.");
1040   print('[ok] add_p_distr');
1041 };
1042 test_add_p_distr();
1043
1044 test_prob_distance := procedure() {
1045   d := decision_algorithm.new();
1046   d.p := { ['A', 'P(A)'], ['B', 'P(B)'] };
1047   d.cp := { [['B', 'A'], 'P(B|A)'] };
1048   pp1 := { ['P(A)', 0.4], ['P(B)', 0.5], ['P(B|A)', 0.6] };
1049   pp2 := { ['P(A)', 0.1], ['P(B)', 0.9], ['P(B|A)', 0.2] };
1050   assert(d.prob_distance(d.p, d.cp, pp1, pp2) == 1.1,
1051          "Error: prob_distance is incorrect.");
1052   print('[ok] prob_distance');
1053 };
1054 test_prob_distance();
1055
1056 test_poss_io_states := procedure() {
1057   d := decision_algorithm.new();
1058   d.i := { 'P(I)' };
1059   d.o := { 'O' };
1060   d.r := { ['P(I)', {0,1}], ['O', tf()]};
1061   assert(d.poss_io_states() == {
1062           { ['P(I)', 0], ['O', false] },
1063           { ['P(I)', 0], ['O',  true] },
1064           { ['P(I)', 1], ['O', false] },
1065           { ['P(I)', 1], ['O',  true] }
1066          },
1067          "Error: poss_io_states is incorrect.");
1068   print('[ok] poss_io_states');
1069 };
1070 test_poss_io_states();
1071
1072 test_poss_m_states := procedure() {
1073   d := decision_algorithm.new();
1074   d.m := { 'M1', 'M2' };
1075   d.r := { ['M1', tf()], ['M2', tf()] };
1076   assert(d.poss_m_states() == {
1077            { ['M1', false], ['M2', false] },
1078            { ['M1', false], ['M2',  true] },
1079            { ['M1',  true], ['M2', false] },
1080            { ['M1',  true], ['M2',  true] }
1081          },
1082          "Error: poss_m_states is incorrect.");
1083   print('[ok] poss_m_states');
1084 };
1085 test_poss_m_states();
1086
1087 test_poss_o_states := procedure() {
1088   d := decision_algorithm.new();
1089   d.o := { 'O1', 'O2' };
1090   d.r := { ['O1', tf()], ['O2', tf()] };
1091   assert(d.poss_o_states() == {
1092            { ['O1', false], ['O2', false] },
1093            { ['O1', false], ['O2',  true] },
1094            { ['O1',  true], ['O2', false] },
1095            { ['O1',  true], ['O2',  true] }
1096          },
1097          "Error: poss_o_states is incorrect.");
1098   print('[ok] poss_o_states');
1099 };
1100 test_poss_o_states();
1101
1102 test_possible_fms := procedure() {
1103   d := decision_algorithm.new();
1104   d.o := { 'O' };
1105   d.m := { 'M_1', 'M_2' };
1106   d.m2 := { 'M2_1', 'M2_2' };
1107   d.r := { [var, tf()] : var in d.o + d.m + d.m2 };
1108   // d.r := { [var, tf()] : var in d.o + d.m };
1109   ds := decision_algorithm.new();
1110   ds.o := { 'O' };
1111   ds.m := { 'ds.M_1', 'ds.M_2' };
1112   ds.m2 := { 'ds.M2_1', 'ds.M2_2' };
1113   ds.r := { [var, tf()] : var in ds.o + ds.m + ds.m2 };
1114   // ds.r := { [var, tf()] : var in ds.o + ds.m };
1115   p_fms := [fm : fm in d.possible_fms(ds)];
1116   print(p_fms);
1117   // print('[.?] possible_fms');
1118 };
1119 // test_possible_fms();
1120 test_apply_fm_m := procedure() { test_possible_fms(); };
1121 test_fm_commutes := procedure() { test_possible_fms(); };
1122
1123 test_force_list := procedure() {
1124   d := decision_algorithm.new();
1125   d.p := { ['A', 'P(A)'] };
1126   d.cp := { [['B', 'A'], 'P(B|A)'] };
1127   assert(d.force_list('P(A)'  ) == ['A',  om] &&
1128          d.force_list('P(B|A)') == ['B', 'A'],
1129          "Error: force_list  is incorrect.");
1130   print('[ok] force_list ');
1131 };
1132 test_force_list();
1133
1134 test_p_i_sim := procedure() {
1135   d := decision_algorithm.new();
1136   d.p := { ['A', 'P(A)'] };
1137   d.r := { ['P(A)', {0, 0.25, 0.75, 1}] };
1138   ds1 := { ['P(A)', 0.25] };
1139   ds2 := { ['P(A)', 0] };
1140   assert(abs(d.p_i_sim(ds1, ds2, 'P(A)') - 2 / 3) < 0.01,
1141          "Error: p_i_sim is incorrect.");
1142   print('[ok] p_i_sim');
1143 };
1144 test_p_i_sim();
1145
1146 test_id_expr := procedure() {
1147   d := decision_algorithm.new();
1148   d.i := {'P(I)'};
1149   d.p := {['A', 'P(A)'], ['I', 'P(I)'] };
1150   assert(d.id_expr('A') == 'A' &&
1151          d.id_expr('I') == At_t('I', -1) &&
1152          d.id_expr(At_t('I', -1)) == At_t('I', -2),
1153          "Error: id_expr is incorrect.");
1154   print('[ok] id_expr');
1155
1156   d.p := d.p + { [At_t('I', -1), 'P(I_-1)'],
1157                  [At_t('I', -2), 'P(I_-2)'] };
1158   assert(d.id_var('P(I)')    == 'P(I_-1)' &&
1159          d.id_var('P(I_-1)') == 'P(I_-2)',
1160          "Error: id_var is incorrect.");
1161   print('[ok] id_var');
1162 };
1163 test_id_expr();
1164 test_id_var := procedure() { test_id_expr(); };
1165
1166 test_poss_i_events := procedure() {
1167   d := decision_algorithm.new();
1168   d.i := { 'P(I)', 'P(I2)' };
1169   d.r := { ['P(I)', {0,1}], ['P(I2)', {0,1}] };
1170   assert(d.poss_i_events() == {
1171            {["P(I)", 0]}, {["P(I)", 1]},
1172            {["P(I2)", 0]}, {["P(I2)", 1]},
1173            {["P(I)", 0], ["P(I2)", 0]},
1174            {["P(I)", 0], ["P(I2)", 1]},
1175            {["P(I)", 1], ["P(I2)", 0]},
1176            {["P(I)", 1], ["P(I2)", 1]}
1177          }, "Error: poss_i_events is incorrect.");
1178   print('[ok] poss_i_events');
1179 };
1180 test_poss_i_events();
1181
1182 test_e_vars := procedure() {
1183   d := decision_algorithm.new();
1184   d.n := [{ ['e', {['A','E_n1(A)']}], ['m2', {'M2_n1'}], ['o', {'O_n1'}] },
1185           { ['e', {['B','E_n2(B)']}], ['m2', {'M2_n2'}], ['o', {'O_n2'}] } ];
1186   assert(d.e_vars() == { 'E_n1(A)', 'E_n2(B)' },
1187          "Error: e_vars  is incorrect.");
1188   print('[ok] e_vars ');
1189 };
1190 test_e_vars();
1191
1192 test_poss_ue_events := procedure() {
1193   d := decision_algorithm.new();
1194   d.n := [{ ['e', {['A','E']}], ['m2', {'M2'}], ['o', {'O'}] }];
1195   d.u := { ['B', 'U'] };
1196   d.r := { ['E', {0,1}], ['U', {0,1}] };
1197   assert(d.poss_ue_events() == {
1198            {["E", 0]}, {["E", 0], ["U", 0]}, {["E", 0], ["U", 1]}, {["E", 1]},
1199            {["E", 1], ["U", 0]}, {["E", 1], ["U", 1]}, {["U", 0]}, {["U", 1]}
1200          }, "Error: poss_ue_events is incorrect.");
1201   print('[ok] poss_ue_events');
1202 };
1203 test_poss_ue_events();
1204
1205 test_poss_p_i_events := procedure() {
1206   d := decision_algorithm.new();
1207   d.p := { ['A', 'P(A)'], ['B', 'P(B)'] };
1208   d.r := { ['P(A)', {0,1}], ['P(B)', {0,1}] };
1209   assert(d.poss_p_i_events() == { ["P(A)", 0], ["P(A)", 1], ["P(B)", 0], ["P(B)", 1] },
1210          "Error: poss_p_i_events is incorrect.");
1211   print('[ok] poss_p_i_events');
1212 };
1213 test_poss_p_i_events();
1214
1215 test_poss_rx_states := procedure() {
1216   d := decision_algorithm.new();
1217   d.n := [{ ['o', {'O_n1'}] }, { ['o', {'O_n2'}] }];
1218   d.r := { ['O_n1', tf()], ['O_n2', tf()] };
1219   assert(d.poss_rx_states() == {
1220            {["O_n1", false], ["O_n2", false]},
1221            {["O_n1", false], ["O_n2",  true]},
1222            {["O_n1",  true], ["O_n2", false]},
1223            {["O_n1",  true], ["O_n2",  true]}
1224          }, "Error: poss_rx_states is incorrect.");
1225   print('[ok] poss_rx_states');
1226 };
1227 test_poss_rx_states();
1228
1229 test_poss_rxs := procedure() {
1230   d := decision_algorithm.new();
1231   d.n := [{ ['o', {'O_n1_1', 'O_n1_2'}] }, { ['o', {'O_n2'}] } ];
1232   d.r := { [no_var, tf()] : no_var in {'O_n1_1', 'O_n1_2', 'O_n2'} };
1233   assert(d.poss_rxs() == {
1234            {["O_n1_1", false], ["O_n1_2", false]},
1235            {["O_n1_1", false], ["O_n1_2",  true]},
1236            {["O_n1_1",  true], ["O_n1_2", false]},
1237            {["O_n1_1",  true], ["O_n1_2",  true]},
1238            {["O_n2", false]},
1239            {["O_n2",  true]}
1240          }, "Error: poss_rxs is incorrect.");
1241   print('[ok] poss_rxs');
1242 };
1243 test_poss_rxs();
1244
1245 /*
1246 test_n_disj := procedure() {
1247   d := decision_algorithm.new();
1248   b := causal_markov_model.new();
1249   b.u := { 'U1' };
1250   b.r := { ['U1', tf()] };
1251   be := { ['U1', true] };
1252   not_be := { ['U1', false] };
1253   w := b;
1254   d.cached_ref := { [be, { be, not_be }] };
1255   assert(d.n_disj(w, b, be) == 2,
1256          "Error: n_disj is incorrect.");
1257   print('[ok] n_disj');
1258
1259   assert(d.n_ev_disj(w, b, not_be, be) == 1,
1260          "Error: n_ev_disj is incorrect.");
1261   print('[ok] n_ev_disj');
1262
1263   assert(d.spec(w, b, not_be, be) == 1/2,
1264          "Error: spec is incorrect.");
1265   print('[ok] spec');
1266 };
1267 test_n_disj();
1268 test_n_ev_disj := procedure() { test_n_disj(); };
1269 test_spec := procedure() { test_spec(); };
1270 */
1271
1272 test_ltr_up_to := procedure() {
1273   assert(da().ltr_up_to('A', 3) == { 'A_1', 'A_2', 'A_3' },
1274          "Error: ltr_up_to is incorrect.");
1275   print('[ok] ltr_up_to');
1276 };
1277 test_ltr_up_to();
1278
1279 test_vars_up_to := procedure() {
1280   assert(da().vars_up_to({ 'A', 'B' }, 2) ==
1281            { 'A_1', 'A_2', 'B_1', 'B_2' },
1282          "Error: vars_up_to is incorrect.");
1283   print('[ok] vars_up_to');
1284 };
1285 test_vars_up_to();
1286
1287 test_expr_to_ltr_var := procedure() {
1288   assert(da().expr_to_ltr_var(Implies('A', 'B'), 'U') == 'U(Implies(A, B))',
1289          "Error: expr_to_ltr_var is incorrect.");
1290   print('[ok] expr_to_ltr_var');
1291 };
1292 test_expr_to_ltr_var();
1293
1294 test_poss_r_z  := procedure() {
1295   poss_z_vals := { { j : j in [1..x] } : x in [1..3] };
1296   assert(da().poss_r_z(poss_z_vals, da().ltr_up_to('A', 2)) == {
1297            {["A_1", {1}],       ["A_2", {1}]},
1298            {["A_1", {1}],       ["A_2", {1, 2}]},
1299            {["A_1", {1}],       ["A_2", {1, 2, 3}]},
1300            {["A_1", {1, 2}],    ["A_2", {1}]},
1301            {["A_1", {1, 2}],    ["A_2", {1, 2}]},
1302            {["A_1", {1, 2}],    ["A_2", {1, 2, 3}]},
1303            {["A_1", {1, 2, 3}], ["A_2", {1}]},
1304            {["A_1", {1, 2, 3}], ["A_2", {1, 2}]},
1305            {["A_1", {1, 2, 3}], ["A_2", {1, 2, 3}]}},
1306          "Error: poss_r_z is incorrect.");
1307   print('[ok] poss_r_z ');
1308 };
1309 test_poss_r_z();
1310
1311 test_poss_r_ue := procedure() {
1312   u := { ['A', 'U(A)'], ['B', 'U(B)'] };
1313   poss_ue_vals := pow({ j : j in [1..2**2] }) - {{}};
1314   assert({ {["U(A)", {1, 2, 4}], ["U(B)", {1, 2, 4}]},
1315            {["U(A)", {2, 3, 4}], ["U(B)", {2, 3, 4}]}
1316          } < da().poss_r_ue(poss_ue_vals, u),
1317          "Error: poss_r_ue is incorrect.");
1318   print('[ok] poss_r_ue');
1319 };
1320 test_poss_r_ue();
  1 class causal_markov_model(n, u, v, r, f, a, cached_cm) {
  2   n := n; // integer number of time slices
  3   u := u; // Set of exogenous variables
  4           //   e.g. u := { 'O' };
  5   v := v; // Set of endogenous variables
  6           //   e.g. v := { 'F', 'L', 'ML' };
  7   r := r; // Function assigning a range of values for each variable
  8           //   e.g. r := { [x, { false, true }] : x in u + v };
  9   /* Higher order function from y in v to a higher order function from a
 10      function assigning values to exogenous and endogenous vars to a value
 11      for y.
 12        eg f := { [y, f_y], [z, f_z], ... }
 13          f_y := { [f_y_1, true], [f_y_2, false], ... }
 14           f_y_1 := { [y, false], [z, false], ... }       (row in truth table)
 15      A variable (technically, its past time slice) can also be its own parent
 16   */
 17   f := f;
 18
 19   /* A list of actual states, one for each time slice. Each actual state is a
 20      function assigning values to cm() vars of the given time.
 21        e.g. [ {['y_t1',true],...}, {['y_t2',false],...}, ... ] */
 22   a := a;
 23
 24   uv := procedure() {
 25     return u + v;
 26   };
 27
 28   u_t := procedure(t) {
 29     return { x + '_t' + t : x in u };
 30   };
 31   v_t := procedure(t) {
 32     return { x + '_t' + t : x in v };
 33   };
 34   uv_t := procedure(t) {
 35     return u_t(t) + v_t(t);
 36   };
 37
 38   cm := procedure() {
 39     if (cached_cm == om) {
 40       cached_cm := compute_cm();
 41     }
 42     return cached_cm;
 43   };
 44
 45     compute_cm := procedure() {
 46       return causal_model(cm_u(), cm_v(), cm_r(), cm_f(), om);
 47     };
 48
 49     cm_u := procedure() {
 50       u_ts := { u_t(t) : t in [1..n] };
 51       if (u_ts == {}) {
 52         u_ts := {{}};
 53       }
 54       return +/ u_ts + v_t(1);
 55       // Includes the first v_t since there's no previous time parents
 56     };
 57
 58     cm_v := procedure() {
 59       return +/ { v_t(t) : t in [2..n] };
 60       // Starts at 2 because the first, parentless v_t is counted in cm_u
 61     };
 62
 63     cm_r := procedure() {
 64       return { [x, r[orig_var(x)]] : x in cm_u() + cm_v() };
 65     };
 66
 67     cm_f := procedure() {
 68       return { [x, fix_time(x, f[orig_var(x)], var_time(x) - 1)] : x in cm_v() };
 69     };
 70
 71       fix_time := procedure(x, f_x, t) {
 72         // Add time subscript to f_x
 73         f_prev_t := { [assign_time(g, t), f_x[g]] : g in domain(f_x) };
 74         // Extend from one timeslice to states over all vars but x
 75         ext_xs := (cm_u() + cm_v()) - uv_t(t) - {x}; // extended vars
 76         poss_ext_states := possible_states(ext_xs, cm_r()); // extended states
 77         // Output remains f_prev_t[prev_t_st] since it's a markov model
 78         return +/ { { [prev_t_st + ext_state, f_prev_t[prev_t_st] ]
 79                       : ext_state in poss_ext_states }
 80                     : prev_t_st in domain(f_prev_t)
 81                   };
 82       };
 83
 84   poss_states := procedure() {
 85     return possible_states(u + v, r);
 86   };
 87
 88   poss_events := procedure() {
 89     return +/ { 2 ** ps : ps in poss_states() };
 90   };
 91
 92   actual_events := procedure() {
 93     return pow(actual_state()) - {{}};
 94   };
 95
 96   actual_state := procedure() {
 97     return +/ { actual_state : actual_state in a };
 98   };
 99
100   /* Set of all actual synchronic events,
101      i.e. those taking place at a single time. */
102   actual_sync_events := procedure() {
103     return +/ { pow(actual_state) : actual_state in a } - {{}};
104   };
105
106   /* Use the causal model on the first two times */
107   // g needs to be full state?
108   response :=  procedure(ys, g) {
109     g1 := assign_time(g, 1);
110     ys2 := { y + '_t' + 2 : y in ys };
111     return drop_time(cm().response(ys2, g1));
112   };
113
114   /* Form the full state transition table and convert it to a string along with
115      the vars and ranges. */
116   t_to_str := procedure() {
117     tt := { [ps, response(v, ps)] : ps in poss_states() };
118     return str([tt, n, u, v, r]);
119   };
120
121   static {
122     new := procedure() {
123       return causal_markov_model(0, {}, {}, {}, {}, [], om);
124     };
125   }
126 }
  1 print("\nTesting Causal Markov Model");
  2 print(  "===========================");
  3
  4 cmm1 := cachedProcedure() {
  5   cmm := causal_markov_model.new();
  6   cmm.n := 3;
  7   cmm.u := { 'U' };
  8   cmm.v := { 'V' };
  9   cmm.r := { ['U', tf()], ['V', tf()] };
 10   cmm.f := { // eg v_t2 = U_t1 xor V_t1
 11     ['V', { [{ ['U', false], ['V', false] }, false],
 12             [{ ['U', false], ['V',  true] },  true],
 13             [{ ['U',  true], ['V', false] },  true],
 14             [{ ['U',  true], ['V',  true] }, false]
 15           }]
 16   };
 17   cmm.a := {
 18     {['U_t1',  true], ['V_t1', false]},
 19     {['U_t2',  true], ['V_t2',  true]},
 20     {['U_t3', false], ['V_t3',  true]}
 21   };
 22   return cmm;
 23 };
 24
 25 test_cm_u := procedure() {
 26   assert(cmm1().cm_u() == { 'U_t1', 'U_t2', 'U_t3', 'V_t1' },
 27          "Error: cm_u is incorrect.");
 28   print('[ok] cm_u');
 29 };
 30 test_cm_u();
 31
 32 test_cm_v := procedure() {
 33   assert(cmm1().cm_v() == { 'V_t2', 'V_t3' },
 34          "Error: cm_v is incorrect.");
 35   print('[ok] cm_v');
 36 };
 37 test_cm_v();
 38
 39 test_cm_r := procedure() {
 40   assert(cmm1().cm_r() == { ['U_t1', tf()], ['U_t2', tf()], ['U_t3', tf()],
 41                             ['V_t1', tf()], ['V_t2', tf()], ['V_t3', tf()] },
 42          "Error: is incorrect.");
 43   print('[ok] cm_r');
 44 };
 45 test_cm_r();
 46
 47 test_cm_f := procedure() {
 48   assert( { [ { ["U_t1", false], ["U_t2", false], ["U_t3", false],
 49                 ["V_t1", false],                  ["V_t3", false]  }, false],
 50             [ { ["U_t1", false], ["U_t2", false], ["U_t3", false],
 51                 ["V_t1", false],                  ["V_t3",  true]  }, false]
 52           } < cmm1().cm_f()['V_t2'],
 53           "Error: cm_f is incorrect.");
 54   print('[ok] cm_f');
 55 };
 56 test_cm_f();
 57
 58 test_poss_states := procedure() {
 59   assert(cmm1().poss_states() == {
 60            { ["U", false], ["V", false] },
 61            { ["U", false], ["V",  true] },
 62            { ["U",  true], ["V", false] },
 63            { ["U",  true], ["V",  true] }
 64          },
 65          "Error: poss_states is incorrect.");
 66   print('[ok] poss_states');
 67 };
 68 test_poss_states();
 69
 70 test_poss_events := procedure() {
 71   assert(cmm1().poss_events() == { {},
 72            {["U", false]}, {["U", true]}, {["V", false]}, {["V", true]},
 73            {["U", false], ["V", false]},
 74            {["U", false], ["V",  true]},
 75            {["U",  true], ["V", false]},
 76            {["U",  true], ["V",  true]}
 77          },
 78          "Error: poss_events is incorrect.");
 79   print('[ok] poss_events');
 80 };
 81 test_poss_events();
 82
 83 test_actual_events := procedure() {
 84   assert(// test a random event
 85          { ["U_t2", true], ["U_t3", false], ["V_t1", false], ["V_t2", true]
 86          } in cmm1().actual_events(),
 87          "Error: actual_events is incorrect.");
 88   print('[ok] actual_events');
 89   print('[ok] actual_state');
 90 };
 91 test_actual_events();
 92 test_actual_state := procedure() { test_actual_state(); };
 93
 94 test_actual_sync_events := procedure() {
 95   assert(// test some random events
 96          !({ ["U_t2", true], ["U_t3", false], ["V_t1", false], ["V_t2", true]
 97            } in cmm1().actual_sync_events()) &&
 98          { {['U_t2', true]}, {['U_t3',false], ['V_t3',true]}
 99            } < cmm1().actual_sync_events() &&
100          !({['U_t1', false]} in cmm1().actual_sync_events()),
101          "Error: actual_sync_events is incorrect.");
102   print('[ok] actual_sync_events');
103 };
104 test_actual_sync_events();
105
106 test_response := procedure() {
107   assert(cmm1().response({'V'}, {['U', true], ['V', false]})['V'] == true &&
108          cmm1().response({'V'}, {['U', true], ['V',  true]})['V'] == false,
109          "Error: response is incorrect.");
110   print('[ok] response');
111 };
112 test_response();
113
114 test_t_to_str := procedure() {
115   assert(eval(cmm1().t_to_str()) == [
116            // tt
117            { [{["U", false], ["V", false]}, {["V", false]}],
118              [{["U", false], ["V",  true]}, {["V",  true]}],
119              [{["U",  true], ["V", false]}, {["V",  true]}],
120              [{["U",  true], ["V",  true]}, {["V", false]}] },
121            3, // n
122            {"U"},
123            {"V"},
124            {["U", {false, true}], ["V", {false, true}]} // r
125          ],
126          "Error: t_to_str is incorrect.");
127   print('[ok] t_to_str');
128 };
129 test_t_to_str();
  1 /* Adapted from Judea Pearl's Causal Models
  2      e.g. Pearl, Judea. Causes and Explanations: A Structural-Model Approach
  3           http://ftp.cs.ucla.edu/pub/stat_ser/R266-part1.pdf
  4 */
  5 class causal_model(u, v, r, f, cached_poss_states) {
  6   u := u; // Set of exogenous variables
  7           //   e.g. u := { 'O' };
  8   v := v; // Set of endogenous variables
  9           //   e.g. v := { 'F', 'L', 'ML' };
 10   r := r; // Function assigning a range of values for each variable
 11           //   e.g. r := { [x, { false, true }] : x in u + v };
 12   /* Higher order function from y in v to a higher order function from a
 13      function assigning values to exogenous and other endogenous vars to a
 14      value for y.
 15        eg f := { [y, f_y], [z, f_z], ... }
 16             f_y := { [f_y_1, true], [f_y_2, false], ... } // rows in truth table
 17               f_y_1 := { [x, false], [z, false], ... }
 18   */
 19   f := f;
 20
 21   uv := procedure() {
 22     return u + v;
 23   };
 24
 25   /* Takes an assignment of values to endogenous variables and returns a
 26      causal submodel. See 7.12 Pearl's Causality book.  */
 27   effect_of_do := procedure(g) {
 28     h := { [y, f[y]] : y in v | !(y in domain(g)) } +
 29          { [x, i_proc_to_func(x, procedure(h) {
 30                                    return g[x];
 31                                  })] : x in domain(g) };
 32     return causal_model(u, v, r, h, om);
 33   };
 34
 35   /* Takes a set of variables ys and an assignment of values g to endogenous
 36      and exogenous variables and returns an assignment of values to ys */
 37   response := procedure(ys, g) {
 38     sm := effect_of_do(g);
 39     result := { [y, sm.solve_for(y, g)] : y in ys };
 40     return result;
 41   };
 42
 43   /* Takes a variable y and an assignment of values g to exogenous variables
 44      and returns a value for y */
 45   solve_for := procedure(y, g) {
 46     g := { [x, g[x]] : x in domain(g) | x in u };
 47     if (y in u) {
 48       return g[u];
 49     } else if (#parents(y) == 0) {
 50       return last(first(f[y]));
 51     } else { // y in v
 52       // todo: sometimes a conflict?
 53       h := g + { procedure() {
 54                    if (z in parents(y)) {
 55                      return [z, solve_for(z, g)];
 56                    } else { // doesn't matter, pick first
 57                      return [z, first(r[z])];
 58                    }
 59                  }() : z in (u + v) - domain(g) | z != y };
 60       return f[y][h];
 61     }
 62   };
 63
 64   // Takes a variable and returns its parents
 65   parents := procedure(y) {
 66     return { z : z in u + v | z != y && is_nec_parent_of(z, y) };
 67   };
 68
 69     /* Check whether there exists an assignment of values to the other
 70        variables such that there are still different values of y depending
 71        on values of z.  */
 72     is_nec_parent_of := procedure(z, y) {
 73       xs := {x : x in u + v | x != y && x != z}; // all other variables but z
 74       g_xs := possible_states(xs, r);
 75       return exists(g_x in g_xs | values_diff(g_x, y, z));
 76     };
 77
 78     values_diff := procedure(g_x, y, z) {
 79       vals := { f[y][ g_x + {[z,r_i]} ] : r_i in r[z] };
 80       return #vals > 1;
 81     };
 82
 83   /* Instance method shorthands for call to static version */
 84   i_proc_to_func := procedure(y, p) {
 85     return causal_model.proc_to_func(y, u, v, r, p);
 86   };
 87
 88   poss_states := procedure() {
 89     if (cached_poss_states == om) {
 90       cached_poss_states := compute_poss_states();
 91     }
 92     return cached_poss_states;
 93   };
 94
 95     compute_poss_states := procedure() {
 96       return possible_states(u + v, r);
 97     };
 98
 99   poss_events := cachedProcedure() {
100     return +/ { pow(ps) : ps in poss_states() };
101   };
102
103   sorted_v := procedure() {
104     return sort_list( [y : y in v],
105                       procedure(y, z) { return depth(y) < depth(z); } );
106   };
107
108     depth := procedure(y) {
109       if (y in u) {
110         return 0;
111       } else {
112         return 1 + max({ depth(z) : z in parents(y) });
113       }
114     };
115
116   static {
117     /* Helper method that takes an endogenous variable y, & u, v, r and a
118        procedure and returns a function. The procedure should take an
119        assignment of values to exogenous variables and other endogenous
120        variables and return y's value. */
121     proc_to_func := procedure(y, u, v, r, p) {
122       dom := possible_states({ x : x in u + v | x != y }, r);
123       return { [g, p(g)] : g in dom };
124     };
125
126     new := procedure() {
127       return causal_model({}, {}, {}, {}, om);
128     };
129   }
130 }
 1 print("\nTesting Causal Model");
 2 print(  "====================");
 3
 4 cm1 := procedure() {
 5   u := { 'O' };
 6   v := { 'F', 'L', 'ML' };
 7   r := { [x, { false, true }] : x in u + v };
 8   f_f := causal_model.proc_to_func('F', u, v, r, procedure(h) {
 9            if (h['L'] || h['ML']) {
10              return true;
11            } else {
12              return false;
13            }
14          });
15   f := { ['F', { [{ ['O', false], ['L', false], ['ML', false] }, false],
16                  [{ ['O', false], ['L', false], ['ML', true ] }, true ],
17                  [{ ['O', false], ['L', true ], ['ML', false] }, true ],
18                  [{ ['O', false], ['L', true ], ['ML', true ] }, true ],
19                  [{ ['O', true ], ['L', false], ['ML', false] }, false],
20                  [{ ['O', true ], ['L', false], ['ML', true ] }, true ],
21                  [{ ['O', true ], ['L', true ], ['ML', false] }, true ],
22                  [{ ['O', true ], ['L', true ], ['ML', true ] }, true ] }],
23          ['L',  causal_model.proc_to_func('L', u, v, r, procedure(g) {
24                   return false;
25                 })],
26          ['ML', causal_model.proc_to_func('ML', u, v, r, procedure(g) {
27                   return false;
28                 })] };
29   assert(f_f == f['F'], 'proc_to_func helper method is incorrect');
30   print('[ok] proc_to_func');
31
32   cm := causal_model(u,v,r,f);
33   assert(cm.f['F'] == f_f, 'causal model class is incorrect');
34
35   return cm;
36 };
37 test_proc_to_func := procedure() { cm1(); };
38
39 test_effect_of_do := procedure() {
40   sm := cm1().effect_of_do({ ['F', true], ['L', true] });
41   assert((sm.f['F' ])[{ ['O', false], ['L', false], ['ML', false] }] <==> true,
42            'effect_of_do F is incorrect');
43   assert((sm.f['L' ])[{ ['O', false], ['F', false], ['ML', false] }] <==> true,
44            'effect_of_do L is incorrect');
45   assert((sm.f['ML' ])[{ ['O', false], ['F', false], ['L', false] }] <==> false,
46            'effect_of_do ML is incorrect');
47   print('[ok] effect_of_do');
48 };
49
50 test_parents := procedure() {
51   assert(cm1().parents('F') == { 'L', 'ML' }, 'parents is incorrect');
52   print('[ok] parents');
53 };
54
55 test_response := procedure() {
56   assert(cm1().response({'F'}, { ['L', false], ['O', true] })['F'] == false,
57          'response is incorrect');
58   assert(cm1().response({'F'}, { ['L', true], ['O', true] })['F'] == true,
59          'response is incorrect');
60   print('[ok] response');
61 };
  1 dev := false;
  2
  3 tf := procedure() { return { true, false }; };
  4
  5 // Non-empty powerset. Powerset without the empty set.
  6 ne_pow := procedure(s) {
  7   return pow(s) - {{}};
  8 };
  9
 10 min := procedure(l) {
 11   mins := { e : e in l | forall(e2 in [x : x in l | x != e ] | e2 >= e) };
 12   return first(mins);
 13 };
 14
 15 max := procedure(l) {
 16   maxs := { e : e in l | forall(e2 in [x : x in l | x != e ] | e >= e2) };
 17   return first(maxs);
 18 };
 19
 20 avg := procedure(l) {
 21   return (+/ l)  / #l;
 22 };
 23
 24 index_of := procedure(e, xs) {
 25   i := 1;
 26   while (xs[i] != e) {
 27     i := i + 1;
 28   }
 29   if (xs[i] == e) {
 30     return i;
 31   } else {
 32     return om;
 33   }
 34 };
 35
 36 equiv_expr := procedure(e1, e2, dom) {
 37   if (dev) { print('equiv_expr dom ' + dom); }
 38   if (isList(e1) && !isList(e2) ||
 39       isList(e2) && !isList(e1)   ) {
 40     return false;
 41   } else if (isList(e1)) {
 42     return forall(j in [1..#e1] | equiv_expr(e1[j], e2[j], dom) );
 43   } else {
 44     if (isTerm(e1) && fct(e1) == "BoxArrow") {
 45       return isTerm(e2) && fct(e2) == "BoxArrow" &&
 46              equiv_expr(args(e1)[1], args(e2)[1], dom) &&
 47              equiv_expr(args(e1)[2], args(e2)[2], dom);
 48     } else {
 49       return expr_to_events(e1, dom) == expr_to_events(e2, dom);
 50     }
 51   }
 52 };
 53
 54 // Possible references for arity of expr
 55 range_for_arity := cachedProcedure(e_arity, poss_sts) {
 56   /* Propositions are sets of possible states. They can also be treated as
 57      objects. You might think of them as the essential realization conditions
 58      for objects. */
 59   poss_objects := pow(poss_sts);
 60   if (e_arity == 0) {
 61     return poss_objects;
 62   /* Wrapping the sngl event below as a list/1-tuple might be a little
 63      counterintuitive but it allows it to be treated consistently with
 64      higher arities.  */
 65   } else if (e_arity == 1) {
 66     return pow({ [x] : x in poss_objects - {{}} });
 67   } else {
 68     return pow(iter_prod(poss_objects - {{}}, e_arity));
 69   }
 70 };
 71
 72 connectives := procedure() {
 73   return {'And','Not','Or','Implies','BoxArrow','At_t','Forall','Exists'};
 74 };
 75
 76 maybe_not := procedure(var, val) {
 77   if (val == true) {
 78     return var;
 79   } else {
 80     return Not(var);
 81   }
 82 };
 83
 84 inv_maybe_not := procedure(expr) {
 85   if (isTerm(expr) && fct(expr) == "Not") {
 86     return { [args(expr)[1], false] };
 87   } else {
 88     return { [expr,  true] };
 89   }
 90 };
 91
 92 /* Takes an expr and returns the set of vars, atomic propositions and objects
 93    that occur in it.  */
 94 atomic_exprs := procedure(expr) {
 95   if (isTerm(expr)) {
 96     return +/ { atomic_exprs(arg_i) : arg_i in args(expr) };
 97   } else {
 98     return { expr };
 99   }
100 };
101
102 /* Takes an expr and returns the set of atomic propositions and objects
103    that occur in it (but not its variables).  */
104 atomic_terms := procedure(expr) {
105   return atomic_exprs(expr) - parse_vars(expr);
106 };
107
108 /* Takes a function assigning true or false to vars and turns it into an
109    expression that is a conjunction of either var or Not(var) depending
110    on each variable's truth value.  */
111 func_to_expr := procedure(g) {
112   sorted_vs := sort([ v : v in domain(g) ]);
113   return iter_fct("And", [ maybe_not(v, g[v]) : v in sorted_vs ]);
114 };
115
116 all_atomic_formulas := procedure(exprs) {
117   return +/ { atomic_formulas(expr) : expr in exprs };
118 };
119
120 atomic_formulas := procedure(expr) {
121   if (dev) { print('expr ' + expr); }
122   return atomic_forms(expr) - parse_vars(expr);
123 };
124
125 atomic_forms := procedure(expr) {
126   if (dev) { print('atomic forms ' + expr); }
127   if (!isTerm(expr) || !(fct(expr) in connectives())) {
128     return { expr };
129   } else {
130     return +/ { atomic_forms(arg_i) : arg_i in args(expr) };
131   }
132 };
133
134 expr_to_events := procedure(expr, dom) {
135   if (dev) { print('dom: ' + dom); }
136   state_space := exprs_to_state_space(dom);
137   if (dev) { print('st sp: ' + state_space); }
138   expand := procedure(events) {
139     if (dev) { print('expand ' + events); }
140     return { state : state in state_space
141              | exists(event in events | restricted_eq(state, event)) };
142   };
143   ete := procedure(expr) {
144     if (dev) { print('ete(' + expr + ')'); }
145     if (isString(expr)) {
146       return { state : state in state_space | state[expr] == true };
147     }
148     if (isTerm(expr)) {
149       if (#args(expr) >= 1) { a1 := args(expr)[1]; }
150       if (#args(expr) >= 2) { a2 := args(expr)[2]; }
151
152       if (!(fct(expr) in connectives())) {  // applied predicate / relation
153         return { [expr, true] };
154       } else if (fct(expr) == "And") {
155         return expand(ete(a1)) * expand(ete(a2));
156         return expand(ete(a1)) * expand(ete(a2));
157         // return { g + h : [g,h] in ete(a1) >< ete(a2) | isMap(g + h) };
158       } else if (fct(expr) == "Or") {
159         return expand(ete(a1)) + expand(ete(a2));
160       // a -> b  ==  ~a v b
161       } else if (fct(expr) == "Implies") {
162         return expand(ete( Or(Not(a1), a2) ));
163       } else if (fct(expr) == "Exists") {
164         // Ex Qx <-> ~ Vx ~Qx
165         return expand(ete( Not( Forall(a1, Not(a2)) ) ));
166       } else if (fct(expr) == "Forall") {
167         terms := { var : var in dom | isString(var) };
168         return { state : state in state_space |
169           forall(term in terms | is_true_in(sub(a2, a1, term), state, dom)) };
170       } else if (fct(expr) == "Not") {
171         if (dev) { print('Not'); }
172         switch {
173           case isString(a1) :
174             if (dev) { print('Not(str)'); }
175             return { {[a1, false]} };
176           // Pair, i.e. { [var, val] }
177           case isSet(a1) && #a1 == 1 && isMap(a1) :
178             return { { [first(a1)[1], !first(a1)[2]] } };
179           case isSet(a1) && isMap(a1) :
180             if (dev) { print('~(a ^ b) = ~a v ~b'); }
181             // ~(a ^ b) = ~a v ~b
182             return +/ { expand(ete(Not({pair}))) : pair in a1 };
183           // Singleton map, eg { g } or { {[x,y],[w,z],...} }
184           case isSet(a1) && #a1 == 1 :
185             if (dev) { print('~ { g } = ~g'); }
186             // ~ { g } = ~g
187             return expand(ete(Not(first(a1))));
188           // Implicit disjunction of maps, eg { g, h, ... }
189           case isSet(a1) :
190             if (dev) { print('~(a v b) = ~a ^ ~b'); }
191             // ~(a v b) = ~a ^ ~b
192             head := first(a1);
193             return expand(ete(  And( Not(head), Not(a1 - {head}) )  ));
194           // Do we allow Not(a[]->b)? How?
195           // case isTerm(a1) && fct(a1) == 'BoxArrow' :
196           default : // e.g. functor term, i.e. predicate or other connective?
197             if (dev) { print('[~a] = [~[a]]'); }
198             // [~a] = [~[a]]
199             return expand(ete(Not( expand(ete(a1)))));
200         }
201       }
202     } else { // not term, atomic expr
203       return ({ [expr, true] });
204     }
205   }; // end ete
206   return expand(ete(expr));
207 };
208
209 /* https://en.wikipedia.org/wiki/Fold_(higher-order_function)  */
210 foldr := procedure(proc, z, l) {
211   if (#l == 0) {
212     return z;
213   } else if (#l == 1) {
214     return proc(l[1], z);
215   } else {
216     return proc(l[1], foldr(proc, z, l[2..]));
217   }
218 };
219
220 /* Takes a setlx functor and returns a procedure which takes two expressions
221    and if either is om, returns the other, or else constructs a term out of
222    the functor and two expressions.  */
223 fctize := procedure(fct) {
224   return procedure(e1, e2) {
225     if (e1 == om) { return e2; } else if (e2 == om) { return e1; } else {
226       return makeTerm(fct, [e1,e2]);
227     }
228   };
229 };
230
231 /* Takes a setlx functor and list of expressions and constructs an expression
232    by repeatedly applying the functor.  */
233 iter_fct := procedure(fct, l) {
234   return foldr(fctize(fct), om, l);
235 };
236
237 /* Takes a function f and returns its inverse. To avoid having to return a set
238    or list, it just returns the first preimage that f maps to the img. */
239 inv := procedure(f) {
240   return { [img, ([ pre : pre in domain(f) | f[pre] == img])[1] ]
241            : img in range(f) };
242 };
243
244 /* Takes a setlx functor and returns its arity */
245 arity := procedure(fct) {
246   if (isTerm(fct)) {
247     return #args(fct);
248   } else {
249     return 0;
250   }
251 };
252
253 /* Takes a set like s >< s >< s and returns tuples instead of nested pairs */
254 flatten := procedure(set) {
255   return { flatten_list(e) : e in set | isList(e)  } +
256          { e               : e in set | !isList(e) };
257 };
258
259 flatten_list := procedure(list) {
260   if (isList(list)) {
261     return +/ [ flatten_list(l) : l in list ];
262   } else {
263     return [list];
264   }
265 };
266
267 /* Takes a list of sets and returns the set of tuples taking a value from
268    each set.  */
269 cart_prod := procedure(list) {
270   if (#list == 1) {
271     return first(list);
272   } else {
273     return flatten(first(list) >< cart_prod(list[2..]));
274   }
275 };
276
277 /* Iterated Cartesian Product
278    Yields the cartesian product of a set with itself n times.  */
279 iter_prod := procedure(set, n) {
280   if (n == 1) {
281     return set;
282   } else {
283     return flatten(iter_prod(set, n - 1) >< set);
284   }
285 };
286
287 iter_mult := procedure(set) {
288   if (#set == 1) {
289     return first(set);
290   } else {
291     return first(set) * iter_mult(set - { first(set) });
292   }
293 };
294
295 /* Takes a set of sets and returns a set of all possible choices taking an
296    element from each set. */
297 choices := procedure(set) {
298   list := [ [elem : elem in subset] : subset in set ];
299   return set_choices(list);
300 };
301
302 // Same as list_choices but returns a set rather than list of the choices.
303 set_choices := procedure(r) {
304   return { { o : o in p } : p in list_choices(r) };
305 };
306
307 /* Takes a list of lists and returns a list of all possible choices taking
308    an element from each list  */
309 list_choices := procedure(r) {
310   if (#r == 1) {
311     return [[x] : x in r[1]];
312   } else {
313     return +/ [  [[x] + row : row in list_choices(r[2..])]  : x in r[1] ];
314   }
315 };
316
317 /* Generate the set of all functions from dom to rng.
318    Generate atomic maps. Collect the choices of those atomic maps. */
319 function_space := procedure(dom, rng) {
320   // Collect into a set the elements from a list of choices of atomic maps
321   // p for preimage and permutation? o is ordered pair?
322   return { { o : o in p } : p in list_choices([ [ [p, i] : i in rng ] : p in dom]) };
323 };
324
325 /* Takes a set of variables s and a function r assigning a set which is the
326    range of possible values to each variable and returns the set of possible
327    functions assigning values to those variables.  */
328 possible_states := cachedProcedure(s, r) {
329   if (s == {} || r == {}) {
330     return {{}};
331   }
332   return choices({ {v} >< r[v] : v in s });
333 };
334
335 /* Takes a function and returns all partial functions, including empty.  */
336 partial_functions := cachedProcedure(f) {
337   return 2 ** f;
338 };
339
340 /* Takes two functions assigning values to vars and tests whether they are
341    compatible, i.e. do not assign different values to the same var.  */
342 compatible_values := procedure(f, g) {
343   h := f + g;
344   return forall(var in domain(f) + domain(g) | h[var] != om);
345 };
346 compat := procedure(f, g) { return compatible_values(f, g); }; // alias
347
348 /* Takes partial state ps, which is a function assigning values to a set of
349    variables, and set of complete states cs, a set of functions assigning
350    values to a larger set of variables and returns the subset of cs compatible
351    with ps.  */
352 compatible_complete_states := cachedProcedure(ps, cs) {
353   return { c : c in cs
354              | forall(d in domain(ps) | c[d] == ps[d] ) };
355 };
356 compat_compl_sts := procedure(ps, cs) { // alias
357   return compatible_complete_states(ps, cs);
358 };
359
360 /* Takes a set of complete states and returns a set of events whose compatible
361    complete states would sum to to the set of complete states. */
362 states2events := procedure(css) {
363   vars := domain(css[1]);
364   /* Variables are unneeded when for all complete states, the states with the
365      values of all the other variables remaining the same but with the
366      candidate variable being assigned true and false are both in the set of
367      complete states.  */
368   unneeded := { v : v in vars
369                   | forall( cs in css |
370                       restrict_domain(cs, vars - v) + {[v,  true]}  in css &&
371                       restrict_domain(cs, vars - v) + {[v, false]} in css
372                     )
373   };
374   return { restrict_domain(cs, vars - unneeded) : cs in css };
375 };
376
377 proc2func := procedure(p, dom) {
378   return { [d, p(d)] : d in dom };
379 };
380
381 // Breaks apart a var label of form 'V_ti' into ['V', i]
382 parse_var := procedure(label) {
383   j := #label;
384   while (int(label[j]) != om && j != 1) {
385     j -= 1;
386   }
387   t := int(label[(j + 1)..]);
388   assert(t != om, "Error: Expected var label to have time subscript.");
389   var := label[1..(j - 2)];
390   return [var, t];
391 };
392
393 orig_var := procedure(label) {
394   return parse_var(label)[1];
395 };
396
397 var_time := procedure(label) {
398   return parse_var(label)[2];
399 };
400
401 /* Takes an assignment of values to variables and adds a time subscript to the
402    variables' labels. */
403 assign_time := procedure(g, t) {
404   return { [ y+'_t'+t, g[y] ] : y in domain(g) };
405 };
406
407 /* Takes an assignment of values to variables and removes time subscripts
408    from the variables' labels. */
409 drop_time := procedure(g) {
410   return { [ orig_var(y), g[y] ] : y in domain(g) };
411 };
412
413 /* From Hilbert System, Wikipedia
414      https://en.wikipedia.org/w/index.php?title=Hilbert_system&oldid=873786806
415 */
416 is_logical_truth := procedure(expr) {
417   vars := parse_vars(expr);
418
419   /* Axiom schemes
420      Redundant:
421        P1: phi -> phi
422        as_p1 := procedure(phi) { return Implies(phi, phi); };
423
424      P2: phi -> (psi -> phi)  */
425   as_p2 := procedure(phi, psi) { return Implies(phi, Implies(psi, phi)); };
426   // P3: (phi -> (psi -> xi)) -> ((phi -> psi) -> (phi -> xi))
427   as_p3 := procedure(phi, psi, xi) {
428     return Implies(
429              Implies(phi, Implies(psi, xi)),
430              Implies(Implies(phi, psi), Implies(phi, xi))
431            );
432   };
433   // P4: (~phi -> ~psi) -> (psi -> phi)
434   as_p4 := procedure(phi, psi) {
435     return Implies(Implies(Not(phi), Not(psi)), Implies(psi, phi));
436   };
437   // Q5: Vx(phi) -> phi[x := t] where t may be substituted for x in phi
438   as_q5 := procedure(var, phi) {
439     return { Implies( Forall(var, phi), sub(phi, var, term))
440              : term in atomic_terms(expr) };
441   };
442   // Q6: Vx(phi -> psi) -> (Vx(phi) -> Vx(psi))
443   as_q6 := procedure(var, phi, psi) {
444     return Implies( Forall(var, Implies(phi, psi)),
445                     Implies(Forall(var, phi), Forall(var, psi)) );
446   };
447   // Q7: phi -> Vx phi where x not in phi
448   as_q7 := procedure(phi, var) {
449     if (var in atomic_exprs(phi)) {
450       return {};
451     } else {
452       return { Implies(phi, Forall(var, phi)) };
453     }
454   };
455   /* Conservative Extensions
456      Conjunction:
457        Introduction: phi -> (psi -> (phi ^ psi))  */
458   conj_intr := procedure(phi, psi) {
459     return Implies(phi, Implies(psi, And(phi, psi)));
460   };
461   //   Elimination: (phi ^ psi) -> phi   and   (phi ^ psi) -> psi
462   conj_elim := procedure(phi, psi) {
463     return { Implies(And(phi, psi), phi),
464              Implies(And(phi, psi), psi) };
465   };
466   /* Disjunction:
467        Introduction: phi -> (phi v psi)   and   psi -> (phi v psi)  */
468   disj_intr := procedure(phi, psi) {
469     return { Implies(phi, Or(phi, psi)),
470              Implies(psi, Or(phi, psi)) };
471   };
472   //   Elimination: (phi -> xi) -> ((psi -> xi) -> ((phi v psi) -> xi))
473   disj_elim := procedure(phi, psi, xi) {
474     return Implies( Implies(phi, xi),
475                     Implies( Implies(psi, xi),
476                              Implies( Or(phi, psi), xi)));
477   };
478   /* Existential Quantification
479      Introduction: Vx(phi -> Ey(phi[x := y]))  */
480   ex_intr := procedure(phi, x_var, y_var) {
481     return Forall(x_var, Implies(phi, Exists(y_var, sub(phi, x_var, y_var))));
482   };
483   // Elimination: Vx(phi -> psi) -> (Ex(phi) -> psi) where !(x in psi)
484   ex_elim := procedure(phi, psi, var) {
485     if (var in atomic_exprs(psi)) {
486       return {};
487     } else {
488       return { Implies( Forall(var, Implies(phi, psi)),
489                         Implies( Exists(var, phi), psi)) };
490     }
491   };
492   // Modus Ponens Rule of Inference
493   // phi, phi -> psi |- psi
494   modus_ponens := procedure(phi, psi) {
495     if (isTerm(psi) && fct(psi) == 'Implies' && args(psi)[1] == phi) {
496       return { args(psi)[2] };
497     } else {
498       return {};
499     }
500   };
501
502   derive_more := procedure(exprs) {
503     return
504       (+/ { as_q7(phi, var) : [phi, var] in exprs >< vars }) +
505       (+/ { { as_p2(phi, psi), as_p4(phi, psi), conj_intr(phi, psi) } +
506               { as_q6(var, phi, psi) : var in vars } +
507               conj_elim(phi, psi) + disj_intr(phi, psi) + modus_ponens(phi, psi)
508             : [phi, psi] in exprs >< exprs }) +
509       { as_p3(phi, psi, xi) : [phi, psi, xi] in iter_prod(exprs, 3) } +
510       (+/ { as_q5(var, phi, vars) : [var, phi] in vars >< exprs }) +
511       (+/ { ex_elim(phi, psi, var)
512             : [phi, psi, var] in cart_prod([exprs, exprs, vars]) } ) +
513       { ex_intr(phi, x_var, y_var)
514             : [phi, x_var, y_var] in cart_prod([exprs,vars,vars]) };
515   };
516   derive := procedure(exprs, j) {
517     if (j == 0) {
518       return exprs;
519     } else {
520       return derive_more(derive(exprs, j - 1));
521     }
522   };
523   return expr in derive(subformulas(expr), 10 ** 6);
524 };
525
526 parse_vars := procedure(expr) {
527   if (isTerm(expr)) {
528     parse_more := +/ { parse_vars(arg) : arg in args(expr) };
529     if (fct(expr) in {'Forall', 'Exists'}) {
530       return { args(expr)[1] } + parse_more;
531     } else {
532       return parse_more;
533     }
534   } else {
535     return {};
536   }
537 };
538
539 /* Substitute any occurrences of var in expr with sub_var instead. */
540 sub := procedure(expr, var, sub_var) {
541   if (isTerm(expr)) {
542     return makeTerm(fct(expr), [sub(arg, var, sub_var) : arg in args(expr)]);
543   } else {
544     if (expr == var) {
545       return sub_var;
546     } else {
547       return expr;
548     }
549   }
550 };
551
552 subformulas := procedure(expr) {
553   if (isTerm(expr) && fct(expr) in connectives()) {
554     return { expr } + (+/ { subformulas(arg) : arg in args(expr) })
555                     - parse_vars(expr);
556   } else {
557     return { expr };
558   }
559 };
560
561 /* Hausdorff Distance
562    "It is the greatest of all the distances from a point in one set to the
563     closest point in the other set."
564       -- https://en.wikipedia.org/wiki/Hausdorff_distance
565 */
566 hausdorff_dist := procedure(s1, s2, dist_f) {
567   dist_to_closest := procedure(e1) {
568     return min([ dist_f(e1, e2) : e2 in s2 ]);
569   };
570   return max([ dist_to_closest(e1) : e1 in s1 ]);
571 };
572
573 /* Kendalls Tau Distance
574    Takes two strict ordinal utility functions with the same domain and counts
575    the number of discordant pairs. Returns a normalized distance from 0 - 1.
576    Each u1, u2 is a set of setlx functors Succ(state1, state2). (Succ stands
577    for succeeds.) States are logical expressions, i.e. setlx functors of
578    combinators on string base propositions.
579
580    "Kendall tau distance is also called bubble-sort distance since it is
581     equivalent to the number of swaps that the bubble sort algorithm would
582     take to place one list in the same order as the other list."
583       -- https://en.wikipedia.org/wiki/Kendall_tau_distance
584 */
585 kendalls_tau_dist := procedure(u1, u2) {
586   pairs := { [x,y] : [x,y] in states_u(u1) >< states_u(u1) | x != y };
587   // Discordant (unordered) pairs
588   disc_un_pairs := #{ [x,y] : [x,y] in pairs
589                       | (Succ(x,y) in u1 && Succ(y,x) in u2) ||
590                         (Succ(x,y) in u2 && Succ(y,x) in u1)
591                     } / 2;
592   n := #states_u(u1);
593   return disc_un_pairs / (n * (n - 1) / 2);
594 };
595
596 /* Takes an ordinal utility function expressed as a set of SuccEq setlx
597    functors comparing events or states and returns the set of atomic variables
598    those events or states range over.  */
599 atom_u := procedure(u) {
600   states := +/ { { args(pref)[1], args(pref)[2] } : pref in u };
601   return +/ { domain(state) : state in states };
602 };
603
604 /* Takes an ordinal utility function and returns the states that are compared
605    in them.  */
606 states_u := procedure(u) {
607   return +/ { { args(pref)[1], args(pref)[2] } : pref in u };
608 };
609
610 /* Cardinal Utility Function to Ordinal Utility Function */
611 card_u_to_ord_u := procedure(card_u, state_space, probs) {
612   poss_lotteries := choices({ { [state, prob] : prob in probs }
613                               : state in state_space });
614   lotteries := { lottery : lottery in poss_lotteries
615                          | +/ [ prob : [state, prob] in lottery ] == 1 };
616   compare_lots := procedure(lot1, lot2) {
617     util_of_lot := procedure(lot) {
618       return +/ { card_u[state] * prob : [state, prob] in lot };
619     };
620     if (util_of_lot(lot1) >= util_of_lot(lot2)) {
621       return SuccEq(lot1, lot2); // Succeeds or equals
622     } else {
623       return SuccEq(lot2, lot1);
624     }
625   };
626   return { compare_lots(lot1, lot2) : [lot1, lot2] in lotteries >< lotteries };
627 };
628
629 /* Additive Utility Function to Cardinal Utility Function:
630    Takes a utility function expressed as { [expr, val], ... } where the
631    utility of a state is the sum of all its true exprs' val and a state space.
632    Returns a cardinal utility function assigning values to states rather than
633    expressions.
634 */
635 add_u_to_card_u := procedure(add_u, state_space) {
636   atoms := +/ { domain(state) : state in state_space };
637   util := procedure(state) {
638     sum := +/ { val : [expr, val] in add_u | is_true_in(expr, state, atoms) };
639     if (sum == om) { sum := 0; }
640     return sum;
641   };
642   return { [state, util(state)] : state in state_space };
643 };
644
645 /* Expressions to State Space:
646    Return the possible ways of assigning true or false to each expr in exprs. */
647 exprs_to_state_space := procedure(exprs) {
648   if (dev) { print('exprs_to_state_space ' + exprs); }
649   atoms := +/ { atomic_formulas(expr) : expr in exprs };
650   return choices({ {[atom,true], [atom,false]} : atom in atoms });
651 };
652
653 /* Expression is True in State:
654    Takes an expression and a state, a function assigning true/false to the
655    atomic terms in expr, and returns true or false for whether the expr
656    is true in the state.
657 */
658 is_true_in := procedure(expr, state, dom) {
659   // return state in expr_to_events(expr, dom); // assumes event is state
660   return exists(event in expr_to_events(expr, dom)
661                 | restricted_eq(state, event) );
662 };
663
664 /* Ordinality Utility Function Distance:
665    Takes two weak ordinal utility functions expressed as a set of SuccEq setlx
666    functors and returns the distance between them.
667
668    See hausdorff_dist and kendalls_tau_dist.
669    See also: https://en.wikipedia.org/wiki/Kemeny-Young_method
670      Interestly, since we read the utility functions off the brains rather
671      than elicit them through votes, we don't need to be concerned with
672      strategic manipulation through insincere votes.
673 */
674 ord_u_dist := procedure(u1, u2) {
675   lots := lots_of_u(u1) + lots_of_u(u2);
676   sharpenings := procedure(u) {
677     poss_total_orders := permutations([lot : lot in lots]);
678     list_to_ord := procedure(l) {
679       if (l == []) {
680         return {};
681       } else {
682         return { Succ(l[1], lot) : lot in l[2..] } + list_to_ord(l[2..]);
683       }
684     };
685     ord_us := { list_to_ord(pto) : pto in poss_total_orders };
686     // exts := lots - lots_of_u(u); // extending lotteries
687     return {
688       ord_u : ord_u in ord_us
689       | forall(pref in u // u: a1 >= a2
690           | Succ(args(pref)[1], args(pref)[2]) in ord_u || // ord_u: a1 > a2
691             SuccEq(args(pref)[2], args(pref)[1]) in u      // u: a2 >= a1, ie ==
692         ) // end forall pref
693     }; // end return
694   }; // end sharpenings
695   return hausdorff_dist( sharpenings(u1),
696                          sharpenings(u2),
697                          kendalls_tau_dist );
698 };
699
700 /* Takes an ordinal utility function, a set of Succ or SuccEq relations, and
701    returns the lotteries that they range over.  */
702 lots_of_u := procedure(ord_u) {
703   // { print(pref) : pref in u };
704   return +/ { { args(pref)[1], args(pref)[2] } : pref in ord_u };
705 };
706
707 /* p 56 of setlx tutorial */
708 sort_list := procedure(l, cmp) {
709   if (#l < 2) { return l; }
710   m := #l \ 2;
711   [l1, l2] := [l[.. m], l[m+1 ..]];
712   [s1, s2] := [sort_list(l1, cmp), sort_list(l2, cmp)];
713   return merge(s1, s2, cmp);
714 };
715
716 sort_set := procedure(s, cmp) {
717   return sort_list([x : x in s], cmp);
718 };
719
720 merge := procedure(l1, l2, cmp) {
721   match ([l1, l2]) {
722     case [[], _] : return l2;
723     case [_, []] : return l1;
724     case [[x1|r1], [x2|r2]] :
725     if (cmp(x1, x2)) {
726       return [x1 | merge(r1, l2, cmp)];
727     } else {
728       return [x2 | merge(l1, r2, cmp)];
729     }
730   }
731 };
732
733 setlx_chars := procedure() {
734   str := " !\"#%&'()*+,-./0123456789:;<=>?" +
735          "ABCDEFGHIJKLMNOPQRSTUVWXYZ[\\]_" +
736          "abcdefghijklmnopqrstuvwxyz{|}~";
737   return { str[j] : j in [1..#str] };
738 };
739
740 all_strs_lte := procedure(s) {
741   poss_strs := {''};
742   length := 0;
743   while (length < #s) {
744     length := length + 1;
745     poss_strs := poss_strs + { poss_str + char : [poss_str, char] in
746                                                  poss_strs >< setlx_chars() };
747   }
748   return poss_strs;
749 };
750
751 restrict_domain := procedure(event, vars) {
752   return { [var, val] : [var, val] in event | var in vars };
753 };
754
755 restricted_eq := procedure(state, event) {
756   return event == restrict_domain(state, domain(event));
757 };
758
759 /* Kolmogorov Complexity of a string
760    https://en.wikipedia.org/wiki/Kolmogorov_complexity
761
762    k is an incomputable function but we include a naive attempt to define it
763    anyway. Although it may seem possible this way, it will not work because
764    eval(poss_str) may not terminate. In practice, some finite approximation
765    could be used. For instance, if setlx allowed us to catch a timeout error
766    as many other languages do, it would be particularly easy by just trying
767    each program string up to a fixed length of time.
768 */
769 k := procedure(s) {
770   poss_strs := {''};
771   success := false;
772   length := 0;
773   while (!success) {
774     length := length + 1;
775     poss_strs := { poss_str + char
776                    : [poss_str, char] in poss_strs >< setlx_chars() };
777     if (exists(bool in { eval(poss_str) == s : poss_str in poss_strs } | bool)
778         || length == #s + 2 )  { // +2 because a str plus quotes encodes itself
779       success := true;
780     }
781   }
782   return length;
783 };
784
785 /* Conditional Kolmogorov Complexity  K(s|i)
786    The length of the shortest program which outputs a string s when given the
787    string i as input. Again, this is incomputable but can be finitely
788    approximated.
789 */
790 k_given := procedure(s, i) {
791   eval_str := procedure(str) {
792     try {
793       return eval(str + '("' + i + '");');
794     } catch(e) {
795       return '';
796     }
797   };
798   strs := { str : str in all_str_lte(#s + 2) | eval_str(str) == s };
799   strs := sort(strs, procedure(s1, s2) { return #s1 < #s2; });
800   return #strs[1];
801 };
  1 print('Testing Lib');
  2 print('===========');
  3
  4 test_ne_pow := procedure() {
  5   assert(ne_pow({1,2}) == {{1}, {2}, {1,2}},
  6          "Error: ne_pow is incorrect.");
  7   print('[ok] ne_pow');
  8 };
  9 test_ne_pow();
 10
 11 test_min := procedure() {
 12   assert(min([3,4,5]) == 3, "Error: min is incorrect.");
 13   print('[ok] min');
 14 };
 15 test_min();
 16
 17 test_max := procedure() {
 18   assert(max([3,4,5]) == 5, "Error: max is incorrect.");
 19   print('[ok] max');
 20 };
 21 test_max();
 22
 23 test_avg := procedure() {
 24   assert(avg([3,4,5]) == 4, "Error: avg is incorrect.");
 25   print('[ok] avg');
 26 };
 27 test_avg();
 28
 29 test_index_of := procedure() {
 30   assert(index_of(5, [3,4,5]) == 3, "Error: index_of is incorrect.");
 31   print('[ok] index_of');
 32 };
 33 test_index_of();
 34
 35 test_equiv_expr := procedure() {
 36   e1 := And('A', 'B');
 37   e2 := And('B', 'A');
 38   assert(equiv_expr(e1, e2, { 'A', 'B' }), "Error: equiv_expr is incorrect.");
 39   print('[ok] equiv_expr: A ^ B == B ^ A');
 40
 41   assert(equiv_expr(Exists('x', Odd('x')),
 42                     Not(Forall('y', Not(Odd('y')))),
 43                     { Odd('a'), Odd('b'), Odd('c') }),
 44          "Error: equiv_expr is incorrect.");
 45   print('[ok] equiv_expr: Ex Odd(x) == ~( Vy ~Odd(y) )');
 46   // print('[ok] expr_to_events');
 47 };
 48 test_equiv_expr();
 49
 50 test_maybe_not := procedure() {
 51   assert(maybe_not('A', true) == 'A',
 52          "Error: maybe_not true is incorrect.");
 53   print('[ok] maybe_not true');
 54   assert(maybe_not('A', false) == Not('A'),
 55          "Error: maybe_not false is incorrect.");
 56   print('[ok] maybe_not false');
 57 };
 58 test_maybe_not();
 59
 60 test_atomic_exprs := procedure() {
 61   assert(atomic_exprs(Exists('x', And('B', Odd('a')))) == { 'x', 'B', 'a' },
 62          "Error: atomic_exprs is incorrect.");
 63   print('[ok] atomic_exprs');
 64 };
 65 test_atomic_exprs();
 66
 67 test_atomic_terms := procedure() {
 68   assert(atomic_terms(Exists('x', And('B', Odd('a')))) == { 'B', 'a' },
 69          "Error: atomic_terms is incorrect.");
 70   print('[ok] atomic_terms');
 71 };
 72 test_atomic_terms();
 73
 74 test_func_to_expr := procedure() {
 75   assert(func_to_expr({ ['A', true], ['B', false], ['C', false] }) ==
 76          And("A", And(Not("B"), Not("C"))),
 77          "Error: func_to_expr is incorrect.");
 78   print('[ok] func_to_expr');
 79   print('[ok] iter_fct');
 80   print('[ok] foldr');
 81   print('[ok] fctize');
 82 };
 83 test_func_to_expr();
 84
 85 test_atomic_formulas := procedure() {
 86   assert(atomic_formulas(Forall('x', Implies(Odd('a'),'B') )) ==
 87          { Odd('a'), 'B' },
 88          "Error: atomic_formulas is incorrect.");
 89   print('[ok] atomic_formulas');
 90   print('[ok] atomic_forms');
 91 };
 92 test_atomic_formulas();
 93 test_atomic_forms := procedure() { test_atomic_formulas(); };
 94
 95 test_expr_to_events := procedure() {
 96   assert(expr_to_events(Not('A'), {'A'}) == { { ['A', false] } },
 97          "Error: expr_to_events ~A is incorrect.");
 98   assert(expr_to_events('A', {'A', 'B' }) ==
 99          { { ['A', true], ['B', false] },
100            { ['A', true], ['B', true ] } },
101          "Error: expr_to_events A is incorrect.");
102   assert(expr_to_events(Implies('A', 'B'), {'A', 'B' }) ==
103          { { ['A', true ], ['B', true ] },
104            { ['A', false], ['B', true ] },
105            { ['A', false], ['B', false] } },
106          "Error: expr_to_events A->B is incorrect.");
107   dom := { 'A', 'B', 'C' };
108   assert(expr_to_events(And('A', 'B'), dom) ==
109          { { ['A', true], ['B', true], ['C', true ] },
110            { ['A', true], ['B', true], ['C', false] }  },
111          "Error: expr_to_events A^B is incorrect.");
112   print('[ok] expr_to_events');
113   print('[  ] more expr_to_events');
114 };
115 test_expr_to_events();
116
117 test_inv := procedure() {
118   assert(inv({ ['a', 1], ['b', 2] }) == { [1, 'a'], [2, 'b'] },
119          "Error: inv is incorrect.");
120   print('[ok] inv');
121 };
122 test_inv();
123
124 test_arity := procedure() {
125   assert(arity('A') == 0 && arity(B()) == 0 && arity(Odd('x')) == 1 &&
126          arity(GreaterThan('x', 'y')) == 2 &&
127          arity(Relation('x', 'y', 'z')) == 3,
128          "Error: arity is incorrect.");
129   print('[ok] arity');
130 };
131 test_arity();
132
133 test_flatten := procedure() {
134   assert([1,'a','C'] in flatten({1, 2, 3} >< {'a','b','c'} >< {'A', 'B', 'C'}),
135          "Error: flatten is incorrect.");
136   print('[ok] flatten');
137   print('[ok] flatten_list');
138 };
139 test_flatten();
140
141 test_cart_prod := procedure() {
142   assert([2,'a','B'] in cart_prod([{1, 2, 3}, {'a','b','c'}, {'A', 'B', 'C'}]),
143          "Error: cart_prod is incorrect.");
144   print('[ok] cart_prod');
145 };
146 test_cart_prod();
147
148 test_iter_prod := procedure() {
149   assert([3,2,1] in iter_prod({1,2,3}, 3),
150          "Error: is incorrect.");
151   print('[ok] iter_prod ');
152 };
153 test_iter_prod();
154
155 test_iter_mult := procedure() {
156   assert(iter_mult({ 3, 5, 7 }) == 105,
157          "Error: iter_mult is incorrect.");
158   print('[ok] iter_mult');
159 };
160 test_iter_mult();
161
162 test_choices := procedure() {
163   assert({3,'b','A'} in choices({ {1,2,3}, {'a','b','c'}, {'A','B','C'} }),
164          "Error: is incorrect.");
165   print('[ok] choices ');
166   print('[ok] set_choices ');
167   print('[ok] list_choices ');
168 };
169 test_choices();
170
171 test_function_space := procedure() {
172   dom := { 'a', 'b' };
173   rng := { 1, 2 };
174   assert(function_space(dom, rng) == { {["a", 1], ["b", 1]},
175                                        {["a", 1], ["b", 2]},
176                                        {["a", 2], ["b", 1]},
177                                        {["a", 2], ["b", 2]}
178                                      },
179          'Error: function_space is incorrect');
180   print('[ok] function_space');
181 };
182 test_function_space();
183
184 test_possible_states := procedure() {
185   s := { 'a', 'b' };
186   r := { ['a', {0,1}], ['b', {3,4}] };
187   assert(possible_states(s,r) == { {["a", 0], ["b", 3]},
188                                    {["a", 0], ["b", 4]},
189                                    {["a", 1], ["b", 3]},
190                                    {["a", 1], ["b", 4]}
191                                  },
192          'Error: possible_states is incorrect');
193   print('[ok] possible_states');
194 };
195 test_possible_states();
196
197 test_partial_functions := procedure() {
198   f := { [1,2], [2,4] };
199   assert(partial_functions(f) == {{}, {[1, 2]}, {[1, 2], [2, 4]}, {[2, 4]}},
200          'Error: partial_functions is incorrect');
201 };
202 test_partial_functions();
203
204 test_compatible_values := procedure() {
205   assert(compatible_values(
206            { ['A',true], ['B',false] },
207            { ['C',false], ['B',false] }
208          ) == true,
209          "Error: compatible_values is incorrect.");
210   assert(compatible_values(
211            { ['A',true], ['B',false] },
212            { ['C',false], ['B',true] }
213          ) == false,
214          "Error: compatible_values is incorrect.");
215   print('[ok] compatible_values');
216 };
217 test_compatible_values();
218
219 test_compatible_complete_states := procedure() {
220   ps := { ['X', true] };
221   cs := possible_states( { 'X', 'Y' },
222                          { ['X', {true, false}],
223                            ['Y', {true, false}]  });
224   assert(compatible_complete_states(ps, cs) == {
225          {["X", true], ["Y", false]},
226          {["X", true], ["Y", true]}
227        }, 'Error: compatible_complete_states is incorrect');
228   print('[ok] compatible_complete_states');
229 };
230 test_compatible_complete_states();
231
232 test_proc2func := procedure() {
233   assert(proc2func(procedure(x) { return 2 * x; }, { 1,2,3 }) ==
234          { [1,2], [2,4], [3,6] },
235          "Error: is incorrect.");
236   print('[ok] proc2func');
237 };
238 test_proc2func();
239
240 test_parse_var := procedure() {
241   assert(parse_var('V_t4') == ['V', 4],
242          "Error: parse_var is incorrect.");
243   print('[ok] parse_var');
244 };
245 test_parse_var();
246
247 test_orig_var := procedure() {
248   assert(orig_var('V_t3') == 'V',
249          "Error: orig_var is incorrect.");
250   print('[ok] orig_var ');
251 };
252 test_orig_var();
253
254 test_var_time := procedure() {
255   assert(var_time('V_t2') == 2,
256          "Error: is incorrect.");
257   print('[ok] var_time');
258 };
259 test_var_time();
260
261 test_assign_time := procedure() {
262   assert(assign_time({ ['A',    true], ['B',     false] }, 4) ==
263                      { ['A_t4', true], ['B_t4', false] },
264          "Error: assign_time is incorrect.");
265   print('[ok] assign_time');
266 };
267 test_assign_time();
268
269 test_drop_time := procedure() {
270   assert(drop_time({ ['A_t3', true], ['B_t3', false] }) ==
271                    { ['A',     true], ['B',    false] },
272          "Error: drop_time is incorrect.");
273   print('[ok] drop_time');
274 };
275 test_drop_time();
276
277 /*
278 test_is_logical_truth := procedure() {
279   assert(true,
280          "Error: is_logical_truth is incorrect.");
281   print('[  ] is_logical_truth');
282 };
283 test_is_logical_truth();
284 */
285
286 test_parse_vars := procedure() {
287   assert(parse_vars(Forall('x', Exists('y', And(Odd('b'), LessThan('y','a')))))
288          == { 'x', 'y' },
289          "Error: is incorrect.");
290   print('[ok] parse_vars');
291 };
292 test_parse_vars();
293
294 test_sub := procedure() {
295   assert(sub(Forall('x', Exists('y', And(Odd('b'), LessThan('y','x')))),'x','z')
296          ==  Forall('z', Exists('y', And(Odd('b'), LessThan('y','z')))),
297          "Error: sub is incorrect.");
298   print('[ok] sub');
299 };
300 test_sub();
301
302 test_subformulas := procedure() {
303   assert(subformulas(Forall('x', Exists('y', And(Odd('b'), LessThan('y','x')))))
304          == { Odd('b'), LessThan('y','x'), And(Odd('b'), LessThan('y','x')),
305               Exists('y', And(Odd('b'), LessThan('y','x'))),
306               Forall('x', Exists('y', And(Odd('b'), LessThan('y','x'))))
307             },
308          "Error: subformulas is incorrect.");
309   print('[ok] subformulas');
310 };
311 test_subformulas();
312
313 test_hausdorff_dist := procedure() {
314   assert(hausdorff_dist({1, 8, 17}, {4, 7, 15},
315                         procedure(x, y) { return (x - y) ** 2; }) == 9,
316          "Error: hausdorff_dist is incorrect.");
317   print('[ok] hausdorff_dist');
318 };
319 test_hausdorff_dist();
320
321 test_kendalls_tau_dist := procedure() {
322   // In actual usage, instead of letters, states/events would be compared.
323   // A > B > C > D
324   u1 := { Succ('A', 'B'), Succ('A', 'C'), Succ('A', 'D'),
325           Succ('B', 'C'), Succ('B', 'D'),
326           Succ('C', 'D') };
327   // C > A > D > B
328   // Bubble sort: abcd => aCBd => CAbd => caDB
329   u2 := { Succ('C', 'A'), Succ('C', 'D'), Succ('C', 'B'),
330           Succ('A', 'D'), Succ('A', 'B'),
331           Succ('D', 'B') };
332   assert(kendalls_tau_dist(u1, u2) == 1/2, // = 3 / (4 * (4-1) / 2)
333          "Error: is incorrect.");
334   print('[ok] kendalls_tau_dist');
335   print('[ok] states_u');
336 };
337 test_kendalls_tau_dist();
338
339 test_atom_u := procedure() {
340   assert(atom_u({ SuccEq({ ['A', true ], ['B', false] },
341                          { ['A', false], ['B', false] }) }) == { 'A', 'B' },
342          "Error: atom_u is incorrect.");
343   print('[ok] atom_u');
344 };
345 test_atom_u();
346
347 test_card_u_to_ord_u := procedure() {
348   // In actual usage, instead of letters, states/events would be compared.
349   assert(card_u_to_ord_u({ ['A', 5], ['B', 3] }, {'A', 'B'}, {0, 0.5, 1}) ==
350          { SuccEq( {["A", 0], ["B", 1]},       {["A", 0], ["B", 1]}),
351            SuccEq( {["A", 0.5], ["B", 0.5]},   {["A", 0], ["B", 1]}),
352            SuccEq( {["A", 0.5], ["B", 0.5]},   {["A", 0.5], ["B", 0.5]}),
353            SuccEq( {["A", 1], ["B", 0]},        {["A", 0], ["B", 1]}),
354            SuccEq( {["A", 1], ["B", 0]},        {["A", 0.5], ["B", 0.5]}),
355            SuccEq( {["A", 1], ["B", 0]},        {["A", 1], ["B", 0]})
356          }, "Error: card_u_to_ord_u is incorrect.");
357   print('[ok] card_u_to_ord_u');
358 };
359 test_card_u_to_ord_u();
360
361 test_add_u_to_card_u := procedure() {
362   assert(add_u_to_card_u({ ['A', 3], ['B', 5], ['C', 9],
363                            [And('A','B'), -2] },
364                          exprs_to_state_space({ 'A', 'B', 'C' })) ==
365          { [{ ['A', false], ['B', false], ['C', false] }, 0],
366            [{ ['A', false], ['B', false], ['C', true ] }, 9],
367            [{ ['A', false], ['B', true ], ['C', false] }, 5],
368            [{ ['A', false], ['B', true ], ['C', true ] }, 14],
369            [{ ['A', true ], ['B', false], ['C', false] }, 3],
370            [{ ['A', true ], ['B', false], ['C', true ] }, 12],
371            [{ ['A', true ], ['B', true ], ['C', false] }, 6],
372            [{ ['A', true ], ['B', true ], ['C', true ] }, 15]
373          },
374          "Error: add_u_to_card_u is incorrect.");
375   print('[ok] add_u_to_card_u');
376 };
377 test_add_u_to_card_u();
378
379 test_ord_u_dist := procedure() {
380   // Todo: manually set ord_us with partial states
381   dom := exprs_to_state_space({ 'A', 'B' });
382   ldom := [ x : x in dom ];
383   probs := {0, 0.5, 1};
384   // probs := {0, 1};
385   u1 := card_u_to_ord_u({
386     [ldom[1], 10], [ldom[2], 7], [ldom[3], 3 ], [ldom[4], 0]
387   }, dom, probs);
388   u2 := card_u_to_ord_u({
389     [ldom[1], 9], [ldom[2], 1], [ldom[3], 11 ], [ldom[4], 4]
390   }, dom, probs);
391   // print(ord_u_dist(u1, u2));
392   // assert(ord_u_dist(u1, u2) == 1/2,
393   //       "Error: ord_u_dist is incorrect.");
394   print('[ ?] ord_u_dist');
395   print('[  ] ord_u_dist w/ sharpenings');
396 };
397 test_ord_u_dist();
398
399 test_sort_list := procedure() {
400   less := procedure(x, y) { return x < y; };
401   greater := procedure(x, y) { return y < x; };
402
403   l := [1,3,5,4,2];
404   s1 := sort_list(l, less );
405   s2 := sort_list(l, greater);
406   assert(s1 == [1,2,3,4,5], 'Error: sort_list is incorrect.');
407   assert(s2 == [5,4,3,2,1], 'Error: sort_list is incorrect.');
408   print('[ok] sort_list');
409 };
410 test_sort_list();
411
412 test_sort_list := procedure() {
413   less := procedure(x, y) { return x < y; };
414   s := {1,3,5,4,2};
415   assert(sort_set(s, less) == [1,2,3,4,5], 'Error: sort_list is incorrect.');
416   print('[ok] sort_set');
417 };
418 test_sort_list();
419
420 test_restrict_domain := procedure() {
421   assert(restrict_domain({ ['a', 1], ['b', 3], ['c', 5] }, {'b', 'c'})
422            == { ['b', 3], ['c', 5] },
423          "Error: is incorrect.");
424   print('[ok] restrict_doman');
425 };
426 test_restrict_domain();
427
428 test_restricted_eq := procedure() {
429   assert(restricted_eq({['a', 1], ['b', 2], ['c', 3]},
430                                  {['b', 2], ['c', 3]} ) == true,
431          "Error: restricted_eq true is incorrect.");
432   print('[ok] restricted_eq true');
433   assert(restricted_eq({['a', 1], ['b', 2], ['c', 3]},
434                                  {['b', 2], ['c', 3], ['d', 4]} ) == false,
435          "Error: restricted_eq false is incorrect.");
436   print('[ok] restricted_eq false');
437 };
438 test_restricted_eq();
439
440 test_range_for_arity := procedure() {
441   poss_sts := possible_states({ 'A', 'B' }, { ['A', tf()], ['B', tf()] });
442   sts := { first(poss_sts), { ['A', true], ['B', false]} };
443   assert(sts in range_for_arity(0, poss_sts),
444          "Error: range_for_arity 0 is incorrect.");
445   print('[ok] range_for_arity 0');
446   sts2 := { { ['A', false], ['B', false]}, { ['A', false], ['B', true]} };
447   // assert({ [sts], [sts2] } in range_for_arity(1, poss_sts),
448   //       "Error: range_for_arity 1 is incorrect.");
449   // print('[ok] range_for_arity 1');
450   print('[..] range_for_arity 1');
451   // assert({ [sts, sts2] } in range_for_arity(2, poss_sts),
452   //       "Error: range_for_arity 2 is incorrect.");
453   // print('[ok] range_for_arity 2');
454 };
455 test_range_for_arity();
456
457 test_exprs_to_state_space := procedure() {
458   assert(exprs_to_state_space({ "A", "B", Implies("A", "B"),
459                                 Not(And("A", Not("B"))) }) == {
460            {['A', false], ['B', false]}, {['A', false], ['B', true]},
461            {['A',  true], ['B', false]}, {['A',  true], ['B', true]}
462          }, "Error: exprs_to_state_space is incorrect.");
463   print('[ok] exprs_to_state_space');
464 };
465 test_exprs_to_state_space();
1 /* SetlX 2.2.0 Cheat Sheet 2 Here I've compiled a short list of examples illustrating the setlX language. 3 4 There is also a slightly expanded quick_ref.stlx version which demonstrates 5 nearly all the setlX needed in order to understand MetaEthical.AI. The main 6 difference is that this cheat sheet focuses on aspects that are more unique 7 to the setlX language and omits many commands that are more obvious or 8 self-explanatory, especially among programmers. 9 10 A much more thorough guide can be found in the official setlX tutorial.pdf. 11 */ 12 13 // Standard Arithmetic Operations 14 x := (1 + 2) * 3 / 4; 15 // ~< Result: 9/4 >~ 16 /* Note that lines always end with a semi-colon. 17 Assignment of a value to a variable is done with ":=", not "=". 18 Variable names start with a lowercase letter because capitalized names are 19 reserved for setlx functors. */ 20 21 // Exponents 22 2 ** 5; 23 // ~< Result: 32 >~ 24 25 // String Length 26 #"abc"; 27 // ~< Result: 3 >~ 28 29 30 // Sets 31 // ==== 32 a := { 1, 2, 3 }; 33 b := { 3, 4, 5 }; 34 35 // Cardinality 36 #b; 37 // ~< Result: 3 >~ 38 39 // Union 40 a + b; 41 // ~< Result: {1, 2, 3, 4, 5} >~ 42 43 // Intersection 44 a * b; 45 // ~< Result: {3} >~ 46 47 // Difference 48 a - b; 49 // ~< Result: {1, 2} >~ 50 51 // Check Membership 52 1 in a; 53 // ~< Result: true >~ 54 55 // Check if Subset 56 {1, 2} < {1, 2, 3}; 57 // ~< Result: true >~ 58 59 // Powerset 60 pow({ 1, 2 }); 61 // ~< Result: {{}, {1}, {1, 2}, {2}} >~ 62 2 ** { 1, 2 }; // alternate syntax 63 // ~< Result: {{}, {1}, {1, 2}, {2}} >~ 64 65 // Cartesian Product 66 pairs := { 'a', 'b' } >< { 1, 2 }; 67 // ~< Result: {["a", 1], ["a", 2], ["b", 1], ["b", 2]} >~ 68 69 // Set comprehension 70 { x * 2 : x in a }; 71 // ~< Result: {2, 4, 6} >~ 72 73 // Set comprehension with filter 74 { x : x in a | x < 3 }; 75 // ~< Result: {1, 2} >~ 76 77 // Set comprehension with list pattern matching 78 // Also, since we don't use the first element of the ordered pair, we can 79 // discard it with _ instead of giving it a variable name. 80 { y : [_, y] in pairs }; 81 // ~< Result: {1, 2} >~ 82 83 // Quantification 84 exists(x in a | x == 2); 85 // ~< Result: true >~ 86 forall(x in a | x < 5); 87 // ~< Result: true >~ 88 89 // Returns the first element according to the language's internal order. 90 // If the set is not all numbers or lists of them, the ordering should not be 91 // relied upon. 92 first(a); 93 // ~< Result: 1 >~ 94 95 // Sum of a Set of... 96 // Integers 97 +/ {1, 2, 3}; 98 // ~< Result: 6 >~ 99 100 // Strings 101 +/ {'a', 'b', 'c'}; 102 // ~< Result: "abc" >~ 103 104 // Sets 105 +/ { {1, 2}, {3, 4} }; 106 // ~< Result: {1, 2, 3, 4} >~ 107 108 // Lists 109 +/ { [1, 2], [3, 4] }; 110 // ~< Result: [1, 2, 3, 4] >~ 111 112 113 // Lists 114 // ===== 115 l := [ 1, 2, 3 ]; 116 m := [ 3, 4, 5 ]; 117 118 // Note that list indexes start at 1! 119 // Not 0 as with most other programming languages. 120 m[1]; 121 // ~< Result: 3 >~ 122 123 // Concatenation 124 l + m; 125 // ~< Result: [ 1, 2, 3, 3, 4, 5] >~ 126 // Note that unlike with sets, the 3 is duplicated 127 128 // List comprehension 129 [ x * 2 : x in l ]; 130 // ~< Result: [2, 4, 6] >~ 131 132 // List comprehension with filter 133 [ x : x in l | x < 3 ]; 134 // ~< Result: [1, 2] >~ 135 136 // Check Inclusion 137 1 in l; 138 // ~< Result: true >~ 139 140 // Quantification 141 exists(x in l | x == 2); 142 // ~< Result: true >~ 143 forall(x in l | x < 5); 144 // ~< Result: true >~ 145 146 // Range 147 m[1..2]; 148 // ~< Result: [3, 4] >~ 149 150 m[..2]; 151 // ~< Result: [3, 4] >~ 152 153 m[2..]; 154 // ~< Result: [4, 5] >~ 155 156 first([3,2,1]); 157 // ~< Result: 3 >~ 158 159 last([3,2,1]); 160 // ~< Result: 1 >~ 161 162 permutations([1, 2, 3]); 163 // ~< Result: {[1, 2, 3], [1, 3, 2], [2, 1, 3], [2, 3, 1], [3, 1, 2], [3, 2, 1]} >~ 164 165 // Sum of a List of: 166 // Integers 167 +/ [1, 2, 3]; 168 // ~< Result: 6 >~ 169 170 // Strings 171 +/ ['a', 'b', 'c']; 172 // ~< Result: "abc" >~ 173 174 // Sets 175 +/ [ {1, 2}, {3, 4} ]; 176 // ~< Result: {1, 2, 3, 4} >~ 177 178 // Lists 179 +/ [ [1, 2], [3, 4] ]; 180 // ~< Result: [1, 2, 3, 4] >~ 181 182 183 // Functions 184 // ========= 185 // They are just sets of ordered pairs where each element of the domain is 186 // mapped to one element of the range. 187 f := { [1,2], [2,4], [3,6] }; 188 189 // You can find the value given an input 190 f[2]; 191 // ~< Result: 4 >~ 192 193 // But if it's not a function (an input is mapped to more than one output) 194 // then it's om (which is like javascript's null). 195 g := { [1,2], [1,3] }; 196 g[1]; 197 // ~< Result: om >~ 198 199 domain(f); 200 // ~< Result: {1, 2, 3} >~ 201 202 range(f); 203 // ~< Result: {2, 4, 6} >~ 204 205 isMap({ [1,2], [2,4] }); 206 // ~< Result: true >~ 207 isMap({ [1,2], [1,4] }); 208 // ~< Result: false >~ 209 210 211 // Control Structures 212 // ================== 213 switch { 214 case false : 215 print('hi'); 216 case false : 217 print('hey'); 218 default : 219 print('bye'); 220 } 221 // bye 222 223 224 // Procedures 225 sum := procedure(x, y) { 226 return x + y; 227 }; 228 sum(3, 4); 229 // ~< Result: 7 >~ 230 231 // It can also be cached to avoid recomputing when given the same inputs 232 sum := cachedProcedure(x, y) { 233 return x + y; 234 }; 235 sum(3, 4); 236 // ~< Result: 7 >~ 237 238 239 // Object-oriented Programming 240 class point(x, y) { 241 x := x; 242 y := y; 243 244 // Instance procedure 245 dist_to := procedure(pt) { 246 return sqrt( (pt.x - x) ** 2 + (pt.y - get_y()) ** 2 ); 247 }; 248 249 // Not really necessary but just demonstrating calling another instance proc 250 get_y := procedure() { 251 // Also just demonstrating 'this' keyword, usually unneeded and implicit 252 return this.y; 253 }; 254 255 // Class procedures 256 static { 257 orig := procedure() { 258 return point(0, 0); 259 }; 260 } 261 } 262 pt := point(1, 1); 263 pt2 := point(4, 5); 264 pt.dist_to(pt2); 265 // ~< Result: 5.0 >~ 266 pt3 := point(3, 4); 267 pt3.dist_to(point.orig()); 268 // ~< Result: 5.0 >~ 269 270 271 /* SetlX Functors 272 ============== 273 SetlX allows for the creation of data structures composed from what they call 274 functors and arguments. Functor names always start with a capital letter and 275 then are followed by parentheses enclosing its arguments, which can be of 276 more or less any type. And that's basically all they are, like strings that 277 can take arguments to enable tree-like structures. 278 279 Here we demonstrate its usage to represent logical expressions where 280 arguments are either strings or other functor terms. (If you're familiar 281 with functors from category theory, the usage of that term here doesn't 282 really have anything to do with that notion.) 283 */ 284 And('A', 'B'); 285 // ~< Result: And("A", "B") >~ 286 287 Implies(And('A', 'B'), 'C'); 288 // ~< Result: Implies(And("A", "B"), "C") >~ 289 290 fct(And('A', 'B')); 291 // ~< Result: "And" >~ 292 293 args(And('A', 'B')); 294 // ~< Result: ["A", "B"] >~ 295 296 makeTerm('And', ['A', 'B']); 297 // ~< Result: And("A", "B") >~ 298 299 300 // Meta-programming 301 eval("{1} + {2, 3}"); 302 // ~< Result: {1, 2, 3} >~
1 /* SetlX 2.2.0 Quick Reference 2 This list of examples introduces much of the setlX language. 3 4 Nearly all of MetaEthical.AI is just a combination of the basic components 5 demonstrated here. There is also a slightly more compact cheat_sheet.stlx 6 that focuses on just the aspects that are more unique to setlX and omits 7 many commands that are more obvious or self-explanatory, especially among 8 programmers. 9 10 A much more thorough guide can be found in the official setlX tutorial.pdf. 11 */ 12 13 14 // This is a comment. 15 /* This is a 16 multi-line comment */ 17 18 19 // Standard Arithmetic Operations 20 x := (1 + 2) * 3 / 4; 21 // ~< Result: 9/4 >~ 22 /* Note that lines always end with a semi-colon. 23 Assignment of a value to a variable is done with ":=", not "=". 24 Variable names start with a lowercase letter because capitalized names are 25 reserved for setlx functors. */ 26 27 // Exponents 28 2 ** 5; 29 // ~< Result: 32 >~ 30 31 sqrt(81); 32 // ~< Result: 9.0 >~ 33 34 // Absolute value 35 abs(-7); 36 // ~< Result: 7 >~ 37 38 39 // Strings 40 // ======= 41 str1 := "abc"; 42 str2 := 'def'; // single quotes work too 43 44 // String concatenation 45 str3 := str1 + str2; 46 // ~< Result: "abcdef" >~ 47 48 // Length 49 #str3; 50 // ~< Result: 6 >~ 51 52 53 // Boolean values 54 // ============== 55 p := true; 56 q := false; 57 58 // Disjunction 59 p || q; 60 // ~< Result: true >~ 61 62 // Conjunction 63 p && q; 64 // ~< Result: false >~ 65 66 // Equality / Biconditional 67 p == q; 68 // ~< Result: false >~ 69 70 p != q; 71 // ~< Result: true >~ 72 73 // Negation 74 !p; 75 // ~< Result: false >~ 76 77 78 // Sets 79 // ==== 80 a := { 1, 2, 3 }; 81 b := { 3, 4, 5 }; 82 83 // Cardinality 84 #b; 85 // ~< Result: 3 >~ 86 87 // Union 88 a + b; 89 // ~< Result: {1, 2, 3, 4, 5} >~ 90 91 // Intersection 92 a * b; 93 // ~< Result: {3} >~ 94 95 // Difference 96 a - b; 97 // ~< Result: {1, 2} >~ 98 99 // Check Membership 100 1 in a; 101 // ~< Result: true >~ 102 103 // Check if Subset 104 {1, 2} < {1, 2, 3}; 105 // ~< Result: true >~ 106 {3} < {1, 2}; 107 // ~< Result: false >~ 108 109 // Powerset 110 pow({ 1, 2 }); 111 // ~< Result: {{}, {1}, {1, 2}, {2}} >~ 112 2 ** { 1, 2 }; // alternate syntax 113 // ~< Result: {{}, {1}, {1, 2}, {2}} >~ 114 115 // Cartesian Product 116 pairs := { 'a', 'b' } >< { 1, 2 }; 117 // ~< Result: {["a", 1], ["a", 2], ["b", 1], ["b", 2]} >~ 118 119 // Set comprehension 120 { x * 2 : x in a }; 121 // ~< Result: {2, 4, 6} >~ 122 123 // Set comprehension with filter 124 { x : x in a | x < 3 }; 125 // ~< Result: {1, 2} >~ 126 127 // Set comprehension with list pattern matching 128 // Also, since we don't use the first element of the ordered pair, we can 129 // discard it with _ instead of giving it a variable name. 130 { y : [_, y] in pairs }; 131 // ~< Result: {1, 2} >~ 132 133 // Quantification 134 exists(x in a | x == 2); 135 // ~< Result: true >~ 136 forall(x in a | x < 5); 137 // ~< Result: true >~ 138 139 // Returns the first element according to the language's internal order. 140 // If the set is not all numbers or lists of them, the ordering should not be 141 // relied upon. 142 first(a); 143 // ~< Result: 1 >~ 144 145 // Sum of a Set of... 146 // Integers 147 +/ {1, 2, 3}; 148 // ~< Result: 6 >~ 149 150 // Strings 151 +/ {'a', 'b', 'c'}; 152 // ~< Result: "abc" >~ 153 154 // Sets 155 +/ { {1, 2}, {3, 4} }; 156 // ~< Result: {1, 2, 3, 4} >~ 157 158 // Lists 159 +/ { [1, 2], [3, 4] }; 160 // ~< Result: [1, 2, 3, 4] >~ 161 162 163 // Lists 164 // ===== 165 l := [ 1, 2, 3 ]; 166 m := [ 3, 4, 5 ]; 167 168 // Note that list indexes start at 1! 169 // Not 0 as with most other programming languages. 170 m[1]; 171 // ~< Result: 3 >~ 172 173 // Concatenation 174 l + m; 175 // ~< Result: [ 1, 2, 3, 3, 4, 5] >~ 176 // Note that unlike with sets, the 3 is duplicated 177 178 // List comprehension 179 [ x * 2 : x in l ]; 180 // ~< Result: [2, 4, 6] >~ 181 182 // List comprehension with filter 183 [ x : x in l | x < 3 ]; 184 // ~< Result: [1, 2] >~ 185 186 // Check Inclusion 187 1 in l; 188 // ~< Result: true >~ 189 190 // Quantification 191 exists(x in l | x == 2); 192 // ~< Result: true >~ 193 forall(x in l | x < 5); 194 // ~< Result: true >~ 195 196 // Range 197 m[1..2]; 198 // ~< Result: [3, 4] >~ 199 200 m[..2]; 201 // ~< Result: [3, 4] >~ 202 203 m[2..]; 204 // ~< Result: [4, 5] >~ 205 206 first([3,2,1]); 207 // ~< Result: 3 >~ 208 209 last([3,2,1]); 210 // ~< Result: 1 >~ 211 212 permutations([1, 2, 3]); 213 // ~< Result: {[1, 2, 3], [1, 3, 2], [2, 1, 3], [2, 3, 1], [3, 1, 2], [3, 2, 1]} >~ 214 215 // Sum of a List of: 216 // Integers 217 +/ [1, 2, 3]; 218 // ~< Result: 6 >~ 219 220 // Strings 221 +/ ['a', 'b', 'c']; 222 // ~< Result: "abc" >~ 223 224 // Sets 225 +/ [ {1, 2}, {3, 4} ]; 226 // ~< Result: {1, 2, 3, 4} >~ 227 228 // Lists 229 +/ [ [1, 2], [3, 4] ]; 230 // ~< Result: [1, 2, 3, 4] >~ 231 232 233 // Functions 234 // ========= 235 // They are just sets of ordered pairs where each element of the domain is 236 // mapped to one element of the range. 237 f := { [1,2], [2,4], [3,6] }; 238 239 // You can find the value given an input 240 f[2]; 241 // ~< Result: 4 >~ 242 243 // But if it's not a function (an input is mapped to more than one output) 244 // then it's om (which is like javascript's null). 245 g := { [1,2], [1,3] }; 246 g[1]; 247 // ~< Result: om >~ 248 249 domain(f); 250 // ~< Result: {1, 2, 3} >~ 251 252 range(f); 253 // ~< Result: {2, 4, 6} >~ 254 255 256 // Control Structures 257 // ================== 258 if (true) { 259 print('hi'); 260 } 261 // hi 262 263 if (false) { 264 print('hi'); 265 } else { 266 print('bye'); 267 } 268 // bye 269 270 if (false) { 271 print('hi'); 272 } else if (true) { 273 print('hey'); 274 } else { 275 print('bye'); 276 } 277 // hey 278 279 switch { 280 case false : 281 print('hi'); 282 case false : 283 print('hey'); 284 default : 285 print('bye'); 286 } 287 // bye 288 289 s := {}; 290 for (i in [1, 2, 3]) { 291 s += { i*2 }; 292 } 293 s; 294 // ~< Result: {2, 4, 6} >~ 295 296 x := 0; 297 while (x < 5) { 298 x += 1; 299 } 300 x; 301 // ~< Result: 5 >~ 302 303 // Todo: match, _ 304 305 306 // Procedures 307 sum := procedure(x, y) { 308 return x + y; 309 }; 310 sum(3, 4); 311 // ~< Result: 7 >~ 312 313 // It can also be cached to avoid recomputing when given the same inputs 314 sum := cachedProcedure(x, y) { 315 return x + y; 316 }; 317 sum(3, 4); 318 // ~< Result: 7 >~ 319 320 321 // Object-oriented Programming 322 class point(x, y) { 323 x := x; 324 y := y; 325 326 // Instance procedure 327 dist_to := procedure(pt) { 328 return sqrt( (pt.x - x) ** 2 + (pt.y - get_y()) ** 2 ); 329 }; 330 331 // Not really necessary but just demonstrating calling another instance proc 332 get_y := procedure() { 333 // Also just demonstrating 'this' keyword, usually unneeded and implicit 334 return this.y; 335 }; 336 337 // Class procedures 338 static { 339 orig := procedure() { 340 return point(0, 0); 341 }; 342 } 343 } 344 pt := point(1, 1); 345 pt2 := point(4, 5); 346 pt.dist_to(pt2); 347 // ~< Result: 5.0 >~ 348 pt3 := point(3, 4); 349 pt3.dist_to(point.orig()); 350 // ~< Result: 5.0 >~ 351 352 353 /* SetlX Functors 354 ============== 355 SetlX allows for the creation of data structures composed from what they call 356 functors and arguments. Functor names always start with a capital letter and 357 then are followed by parentheses enclosing its arguments, which can be of 358 more or less any type. And that's basically all they are, like strings that 359 can take arguments to enable tree-like structures. 360 361 Here we demonstrate its usage to represent logical expressions where 362 arguments are either strings or other functor terms. (If you're familiar 363 with functors from category theory, the usage of that term here doesn't 364 really have anything to do with that notion.) 365 */ 366 And('A', 'B'); 367 // ~< Result: And("A", "B") >~ 368 369 Implies(And('A', 'B'), 'C'); 370 // ~< Result: Implies(And("A", "B"), "C") >~ 371 372 fct(And('A', 'B')); 373 // ~< Result: "And" >~ 374 375 args(And('A', 'B')); 376 // ~< Result: ["A", "B"] >~ 377 378 makeTerm('And', ['A', 'B']); 379 // ~< Result: And("A", "B") >~ 380 381 382 // Type checking 383 // ============= 384 isTerm(And('A', 'B')); 385 // ~< Result: true >~ 386 387 isString('abc'); 388 // ~< Result: true >~ 389 390 isSet({}); 391 // ~< Result: true >~ 392 393 isList([]); 394 // ~< Result: true >~ 395 396 isMap({ [1,2], [2,4] }); 397 // ~< Result: true >~ 398 isMap({ [1,2], [1,4] }); 399 // ~< Result: false >~ 400 401 402 int('5'); 403 // ~< Result: 5 >~ 404 405 str(5); 406 // ~< Result: "5" >~ 407 408 str({}); 409 // ~< Result: "{}" >~ 410 411 412 // Meta-programming 413 eval("{1} + {2, 3}"); 414 // ~< Result: {1, 2, 3} >~
